Document Overview
This document describes the Alereon AL4512 UWB Hub.
1.0
WIRELESS USB/ULTRA-WIDEBAND OVERVIEW
The AL4512 Hub allows Ultra-wideband (UWB) wireless data transfer and interoperability with other
Certified Wireless USB devices. Certified Wireless USB is the new wireless extension to USB,
combining the speed and security of wired USB technology with the connivance and ease-of-use of
wireless. Certified Wireless USB supports robust high-speed wireless connectivity by utilizing the
common WiMedia UWB radio platform developed by the WiMedia Alliance. UWB technology offers a
solution for high bandwidth, low cost, and low power consumption. Certified Wireless USB is the first
high-speed wireless personal interconnect technology to meet the needs of multimedia consumer
electronics, PC peripherals, and mobile devices. Certified Wireless USB preserves the functionality of
wired USB while eliminating the tangle of cable connections.
2.0
PACKAGE CONTENTS
Your AL4512 Hub Solution package should contain all the items shown in
will be a CD containing all software (including drivers) and documentation for the AL4512 Hub. See
Table 1
for package contents.
Rev. 0.1
May 3, 2007
Figure 1. AL4512 Hub and Accessories
2
1
5
AL4512 Hub
Draft Version 0.1
Figure
1. In addition, there
3
4
Alereon Confidential
User Guide
Advertisement
Table of Contents
Summary of Contents for Alereon AL4512
- Page 1 Your AL4512 Hub Solution package should contain all the items shown in Figure 1. In addition, there will be a CD containing all software (including drivers) and documentation for the AL4512 Hub. See Table 1 for package contents. Figure 1. AL4512 Hub and Accessories Rev.
- Page 2 Under ideal circumstances and with properly configured Certified Wireless USB devices (such as the AL4504 USB dongle), the AL4512 Hub is capable of significantly longer ranges, but these are not guaranteed. Likewise, in environments with heavy EMF shielding or significant radio frequency (RF) noise, the hub and other Certified Wireless USB devices may need to be placed closer together for optimal performance.
- Page 3 3. Follow the on-screen instructions to install the driver and software for the hub. 4. Attach the hub to the PC by plugging it into the USB port. 5. Attach the included antenna to the AL4512 by screwing it into the antenna connector on the side of the hub.
- Page 4 Check to see that the drivers for the Card have been installed. Right-click on the “My Computer” icon on your desktop. Choose “Properties” and navigate to the “Device Manager” and see if your AL4512 Hub is listed without any errors. If an error is indicated, contact Alereon technical support, as indicated in Section 6.0.
- Page 5 Alereon's products are not designed, intended, authorized or warranted for use as components in systems intended for surgical implant into the body, or in other applications intended to support or sustain life, or in any other application in which the failure of Alereon's product could create a situation where personal injury, death, or severe property or environmental damage may occur.
