Summary of Contents for Curv RV01
- Page 1 All manuals and user guides at all-guides.com CURVRV01 Instructions...
-
Page 2: Main Features
Wireless Radiator Valve All manuals and user guides at all-guides.com Designed for independent controlled heating with remote monitoring via smart phone (requires Cürv gateway) and can be fitted to new or existing thermostatic radiator valves (TRV). Main Features • 7 days independent programming •... -
Page 3: Technical Specification
Technical Specification All manuals and user guides at all-guides.com Thermostat Type Programmable electronic radiator valve controller Power Supply 2 x 1.5V AA alkaline batteries Battery Life Up to 1 year (Lithium batteries recommended) Ambient Temperature 0°C ~ 50°C Storage Temperature Range -10°C ~ 60°C Accuracy ±0.5°C... - Page 4 Dimensions / Buttons and Display All manuals and user guides at all-guides.com 22.0 C...
- Page 5 Dimensions / Buttons and Display All manuals and user guides at all-guides.com Auto / Manual mode switch button Program / Date / Time set button Comfort / Economic temperature setting button Raise the temperature / time setting Lower the temperature / time setting Show when the controller is in Auto mode Show when the controller is in manual setting or holiday mode Show when the controller is in program setting mode...
- Page 6 Fitting the Radiator Valve All manuals and user guides at all-guides.com Inserting / replacing the batteries (Please note: before you change the batteries, keep the valve completely open). Remove the battery cover and insert the two batteries. Ensure that the batteries are correctly inserted before use.
- Page 7 Mounting the RA and Caleffi adapter Tighten the RA adaptor All manuals and user guides at all-guides.com using the screw. Tighten the Caleffi adaptor by hand. Screw the thermostat onto the adaptor and hand tighten (max.4.5mm).
- Page 8 The Wireless Thermostat has been designed for independent zone controlled heating with remote monitoring via smart phone, if paired with Curv Gateway CURVWG01. It must be used in conjunction with existing thermostatic radiator valves (TRV). Default Temperature And Time Settings...
-
Page 9: Factory Reset
Factory Reset All manuals and user guides at all-guides.com Press ‘PROG’ then hold ‘+’ and ‘-’ for 3 seconds. All programs will reset and the display will show ‘dEF’. This will reset all user settings to factory default. Low Battery Indicator When the battery is low, the screen will show “... -
Page 10: Program Settings
Program Settings All manuals and user guides at all-guides.com You can set 2 high ( ) temperature modes and 2 low ( ) temperature modes for each day of the week that are numbered from 1 to 7 (Monday to Sunday) in the timer program. 1 - 7 To make the same setting for all 7 days of the week press the “PROG”... -
Page 11: Manual Operation
Manual Operation All manuals and user guides at all-guides.com Press the “AUTO/MANU” button to switch to manual mode, press ‘+’ and ‘-’ to set the temperature. Press the “AUTO/MANU” button again to return to automatic mode. Temporary Override In auto operation, if you want to change the current program setting temperature press the “+”... -
Page 12: Open Window Function
Open Window Function All manuals and user guides at all-guides.com If you open a window the temperature will drop dramatically. The TRV closes the valve to save energy. The screen will show the message “OPEN”, the radiator controller will reopen the valve when the temperature rises again or after 45 minutes. - Page 13 Download The Free APP From All manuals and user guides at all-guides.com Full Smart Control For smart control access, please combine this product with the Cürv Gateway CURVWG01. Power...
- Page 14 All manuals and user guides at all-guides.com...
