HomeLink CB2GTX2HL3 Owner's Manual

Universal

The Owners Manual for the Homelink® series Universal Garage Door Opener is reproduced

here.

HomeLink

Universal Transceiver

The HomeLink

Universal Transceiver in your vehicle provides a convenient way to replace up to three hand-

held transmitters with a single built-in component. This innovative feature will learn the radio frequency

codes of most current transmitters used to activate devices such as garage doors, entry door locks, estate

gates, security systems, and home or office lighting. For additional information on HomeLink and/or

HomeLink compatible products, call

www.homelink.jci.com

Precautions

When programming the HomeLink Universal Transceiver to a garage door opener or entry

gate, make sure that people and objects are out of the way to prevent potential harm or

damage.

Do not use the HomeLink Universal Transceiver with any garage door opener that

lacks the safety stop and reverse feature as required by federal safety standards. (This

includes any garage door opener model manufactured before April 1, 1982.) A garage

door opener which cannot detect an object, signaling the door to stop and reverse, does

not meet current federal safety standards. Using a garage door opener without these

features increases risk of serious injury or death. For more information, call

1-800-355-3515 or on the internet at www.homelink.jci.com.

Retain the original transmitter for future programming procedures (i.e., new vehicle

purchase). It is also suggested that upon the sale of the vehicle, the programmed

HomeLink Universal Transceiver buttons be erased for security purposes (follow step

1 in the "Programming" portion of this text).

HomeLink

Universal Transceiver

Suggested Owner's Manual Text

March 2002

1-800-355-3515

or refer to the HomeLink web site at

Table of Contents

Do you have a question about the CB2GTX2HL3 and is the answer not in the manual?

Page 1 This innovative feature will learn the radio frequency codes of most current transmitters used to activate devices such as garage doors, entry door locks, estate gates, security systems, and home or office lighting. For additional information on HomeLink and/or HomeLink compatible products, call...
Page 2 If, after 20 seconds, the indicator light does not flash rapidly, release both the HomeLink and the hand-held transmitter buttons and repeat steps two through four. However, position the hand-held transmitter at a different length and/or angle until the indicator light begins to flash rapidly.
Page 3 Continue to press and hold the desired HomeLink button (note steps 3 through 5 in the “Programming” portion of this text) while you “cycle” your hand-held transmitter until the frequency signal has been learned. The indicator light will flash slowly and then rapidly upon successful training.
Page 4 The previous device has now been erased and the new device can be activated by pushing the HomeLink button that has just been programmed. This procedure will not affect any other programmed HomeLink buttons.
