LavvieBot S Manual
※ LavvieBot S is a new type of home appliance that has not been intorudced to
the market before. Therefore, users of this product must read the entire manual
and follow instructions accordingly.
● This manual contains important information about the product. Please keep it
where you or other users can read at any time.
● LavvieBot S is for household use and is not for commercial use. If used as
commercial use, a seller of this product cannot guarantee both repair and
warranty.
※ Automatic Litter Box does NOT mean "You Don't Have To Do Anything"
● This product automatically "scoops out solid waste of cats".
● There is no automatic litter box that does not require owners' maintenance and
care such as cleaning and removing the scooped wastes and clumps.
● A seller of LavvieBot S is NOT responsible for any fuctional error due to users
using incorrect cat litter types or poor quality litter.
● There may be changes of an exterior, a button control, or product features of a
product without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LavvieBot S and is the answer not in the manual?

Questions and answers

Related Manuals for PurrSong LavvieBot S

Summary of Contents for PurrSong LavvieBot S

  • Page 1 LavvieBot S Manual ※ LavvieBot S is a new type of home appliance that has not been intorudced to the market before. Therefore, users of this product must read the entire manual and follow instructions accordingly. ● This manual contains important information about the product. Please keep it where you or other users can read at any time.
  • Page 2 Maximum 2 cats for one single LavvieBot S LavvieBot S is designed for 1 to 2 cats use only. The product may not perform auto cleaning properly and cause a serious contamination. Such condition may significantly shorten its lifespan or cause frequent malfunction.
  • Page 3 27 page・・・・・ How to Detach a Separator 28 page・・・・・ How to Attach a Separator 29 page・・・・・ [SEPARATE] Indicator Light & Status 30 page・・・・・ How to Clean LavvieBot S 32 page・・・・・ Application & LavvieBot S Registration ・・・・・ Acclimating Your Cat 34 page・・・・・ Emergency Stop Function 35 page・・・・・...
  • Page 4 Components Exterior Top Cover (Top Lid) Step Mat Waste Drawer Following accessories are inside a Waste Drawer Step Mat Power Adapter Deodorizer Waste Bag 2 EA (1 Set) 10 EA...
  • Page 5 Separator Litter Tray Waste Drawer Please contact the seller or PurrSong immediately if you find any damaged part (cracked or broken parts) upon arrival. ● Please contact a seller you purchased from for defective product or parts. ● Please contact a seller you purchased from for return or refund.
  • Page 6 Warning and Precautions for Safety ex) Pellets, Silica gel, etc ex) Bentonite, Natural litters ex) lightweight bentonite, wheat natural litter Make sure your cat is not inside the LavvieBot is designed to use only machine when operating. Any LavvieBot c l u m p i n g l i t t e r o f m e d i u m - s i z e d operation with your cat inside can cause particles.
  • Page 7 The LavvieBot should be placed on a firm Handle the LavvieBot with care. Cleaning and flat level floor. Placing the LavvieBot the product with water is prohibited as on uneven or unstable surfaces can the machine consists of metal as and result in malfunction or damage to the electronic components.
  • Page 8 Warning and Precautions for Safety Safety sensors are located at the Do not put pressure on LavvieBot by entrance. Always keep the side door placing heavy objects on top of the closed, except when cleaning. Leaving machine or applying excessive force to t h e d oo r o pe n o r o pe n i n g d u r i n g the buttons, which can result in damage.
  • Page 9 Never let an infant or a child go inside Do not try to dry the machine using a LavvieBot. hairdryer and putting a candle inside to remove bad odors. These attempts can cause electric shock, a fire, or damage to the product. 10℃~35℃...
  • Page 10 ● LavvieBot S is an automatic cat litter box. Please use it for product purpose only. ● This product is for household use and indoors only. It is NOT for commercial use.
  • Page 11 ● Do not use or store this product in a humid place or near water like outdoors or bathroom. ● If this product is damaged, left outside, accidently watered or soaked, do not use it and contact customer service for assistance. ●...
  • Page 12 A cat or a person is near LavvieBot S Blue A cat is in a litter tray inside LavvieBot S An error including main motor overload occurred. *In this case, check your litter tray whether it needs cleaning or has too much litter in it.
  • Page 13 Loading for BLE connection Disassemble Parts for Cleaning The [SEPARATE] button is used to detach inside parts to clean LavvieBot S. 1. Litter Tray SEPARATE Mode: Press the [SEPARATE] button once and the [SEPARATE] LED will turn blue. You can see the separator being lifted toward the entrance.
  • Page 14 Indicator Lights and Button Functions Litter Storage Status & Auto-Refill [STORAGE] LED displays the status of a litter storage. Light Status Solid Blue Litter storage is full No light Litter storage has enough litter Blinking Red Litter storage has no litter or just a little bit Blinking Red on Litter stoage has enough litter, but no auto-clean has both[STORAGE] and...
  • Page 15 Litter Type - Choose the type of cat litter that you will use for LavvieBot S by pressing the [LITTER] button. Select BENTONITE when using bentonite cat litter and NATURAL for natural litters made of tofu, corn or other botanical materials.
  • Page 16 5 Steps Before Power On 1. Accessories Following accessories can be found in a waste drawer. Step Mat Power Adapter Deodorizer Waste Bag 2 EA (1 Set) 10 EA 2. Deodorizers Replace used deodorizers with new ones for every two months. Do not eat the block inside the deodorizer.
  • Page 17 3. Step Mat Insert the step mat into the 4 (four) holes inside of the entrance. You may find these four holes as shown below. 4. Waste Bag Use a waste bag provided as an accessory. Place the liner by hooking its tip to Fix the rest part of the liner on the the narrow holes on the side of a waste bag holes in front of a waste...

  • Page 18: How To Use Settings

    How to Use (Settings) 1.Plug in the power adapter to turn- 2. [SEPARATE] will turn red as the s e p a r a t o r i s s e t t o a s e p a r a t o r on the unit.
  • Page 19 10. Push the [SEPARATE] button. The litter you selected on the LITTER TYPE separator will change to Basic Mode to of LavvieBot S for auto-refill later. dispense litter to keep or more than the litter level. When this auto-refill is done,...

  • Page 20: How It Works

    Wait Time Setting & Automatic Cleaning 1. Push the ▼ and ▲ buttons to set the wait time for the auto-clean time after your cat uses LavvieBot S. You can set the time by 10 minutes scale from 10 to 60min.
  • Page 21 Automatic Cleaning - Manual Mode You can activate auto-clean manually as well. You can use this function not just for scooping the waste away, but to flatten the litter surface in the tray. ● Please be cautious as the sensor for safety measures is NOT on during this manual operation.
  • Page 22 Waste Drawer Notification ● Scooped out wastes will be collected in a waste drawer located on the bottom of the unit, below the entrance. When the wastes are collected in the waste drawer, the [WASTE] LED whill turn blue. ● When more wastes are collected and the waste drawer gets full, the blue light will blink once every second.
  • Page 23 Automatic Refilling ● LavvieBot S automatically dispenses litter from the litter storage when a certain amount of litter in the tray gets lessened than the litter level (standard amount). 1. During auto-refill, the [STORAGE] 2 . A f t e r i t r e f i l l e d t h e l i t t e r, t h e LED blinks blue twice every second.
  • Page 24 Automatic Refilling - Manual Mode 1. If you press and hold the [STORAGE] button, it begins dispensing the litter until you release the button. However, it will not dispense or stop refilling if the litter tray alreay reached the maximum amount of litter inside. The separator will be operated to flatten the litter after auto-refill is done.
  • Page 25 <Solid Blue> It shows that there is enough litter in the storage. <Blinking Blue twice every one second> LavvieBot S refilling litter automatically. <Blinking Red once every one second> The storage is running out of litter during auto-refill operation. If you add litter to the storage, it will continue to dispense litter.
  • Page 26 Separator & Separator Modes ● Following is an explanation about how to operate a separator of LavvieBot S. Basic Mode: A separator is on a standby position, meaning this is where the separator is usually sitting and for a cat to use.
  • Page 27 How to Detach a Separator ● Following is an explanation about how to detach and attach the separator. Please refer to the instructions below to clean the separator. 1. Press and hold the [SEPARATE] 2. Turn the coupler to the left as button.
  • Page 28 How to Attach a Separator 1. Please check if there is a red light 2. If you don't see a red light, press on [SEPARATE]. and hold the [SEPARATE] button. R E D Press and hold 3. Put the separator back as shown 4.
  • Page 29 It is Separator SEPARATE mode where the separator can be detached. The separator will be in this position when R E D you first receive LavvieBot S. Position: Towards the entrance Indicator lights: Solid Blue In this position, the litter tray can be taken out and also the discharging all the litter operation can be performed.
  • Page 30 ● Avoid using water depending on which part you clean and wash. You must clean at least once every month because using LavvieBot S without cleaning may cause a malfunction or a damage. Please note that when a product is sent out for repair, there will be additional cleaning fees if a product is badly contaminated.
  • Page 31 Detach a Waste Drawer Detach a Step Mat Pull the waste drawer out slowly to Carefully lift up a step mat to take out. take out. Detach a Waste Drawer Cover and Deodorizers 1. Easily detach the waste drawer cover 2.

  • Page 32: Acclimating Your Cat

    LavvieBot S. Acclimating Your Cat 1. Place a litter tray of LavvieBot S on the same location where the previous litter box was sitting. It is important to hide the previous litter box from cats and make sure they don’t find it.
  • Page 33 4. Click the registered 5. After finishing connecting the Wi-Fi, LavvieBot S for Wi-Fi go to [IoT] and click [UPDATE] of connection. LavvieBot S you just registered for firmware update. Litter...

  • Page 34: Emergency Stop Function

    Emergency Stop Function ● LavvieBot S has a sensor to stop a separator when a cat comes near. ● This sensor also detects people who come close to the product. ● It resumes its automatic operation when nothing is near, but please avoid making the product repeat stop and resume operations unnecessarily.
  • Page 35 I cannot connect to Wi-Fi on my phone! ● Type in a correct password of your Wi-Fi router. ● Make sure to register LavvieBot S on PurrSong application first. If there is any change made to your Wi-Fi router, please change the information on the application.
  • Page 36 FAQs Q. What should I do if my cat’s stool is watery or mushy? A. If your cat’s stool is watery or mushy, it might take a while for the litter to be hardened. In this case, set up the Wait Time to a longer period to give enough time for litter to be hardened so that LavvieBot can clean the clumping.
  • Page 37 (ex. pushing the litter tray with hands, etc.) or leaning towards the it 3. When opening and closing the door of LavvieBot S * The blue light of [STATUS] will be gone after 7 min or you can press the [RESET] button.
  • Page 38 Cleaning fees (50$) may also be charged if the Lavviebot S is returned and has not been properly cleaned. Please make sure the Lavviebot S is cleaned and carefully packaged and...

  • Page 39: Warranty North-America

    Warranty North-America Your Lavviebot S is covered by a 1 year warranty starting from the date ・ of shipment. This warranty covers all parts and labor for manufacturer defects and is taken care of by a RobotShop certified repair center.
  • Page 40 (2) This device ・ Product Name: Smart Automatic Cat Litter Box must accept any interference received, including interference ・ Model Name: LavvieBot S that may cause undesired operation. ・ Input: DC 12V ・ CAUTION: Changes or modifications not expressly approved by ・...
