MicroLink
101-0032
HART Protocol Modem
USB Interface
DIN Rail Mount
Installation
Operation
& Specifications
Manual
General Description
The MicroLink 101-0032 is a USB to HART® protocol modem featuring standard
DIN rail moun ng. It provides the hardware interface between Highway
Addressable Remote Transducer devices (HART) and a Windows® PC with a
USB interface.
MicroLink is used for commissioning, diagnos cs, monitoring, and tes ng HART
fi eld devices. Communica ons direc on control is handled internally so there
is no need to control tricky request-to-send (RTS) handshake ming, greatly
simplifying so ware development.
Virtual serial port drivers allow the USB MicroLink modem to appear as an
RS-232 com port to Windows and your HART so ware for increased
compa bility.
The DIN rail moun ng clip is compa ble with widely used 35 mm EN 50022
rails. It can be snap mounted and removed from the moun ng rail without tools
for quick installa on and servicing. A status LED provides confi rma on of the
transmi ed and received HART packets to help you quickly troubleshoot your
system and verify opera on. Power is provided by the USB port so no external
power supply is required.
620-0011 R2 © Microfl ex 2013-2021
Advertisement
Table of Contents
Summary of Contents for Microflex MicroLink 101-0032
- Page 1 & Specifications Manual General Description The MicroLink 101-0032 is a USB to HART® protocol modem featuring standard DIN rail moun ng. It provides the hardware interface between Highway Addressable Remote Transducer devices (HART) and a Windows® PC with a USB interface.
- Page 2 Driver Pre-Installation The USB drivers should be installed before the MicroLink HART modem is connected to the PC’s USB port. A er the drivers are installed, Windows will automa cally detect the modem when it is connected to the USB port and complete the setup.
- Page 3 Driver inf file - Manually Installed To manually install the driver inf fi le... 1. Connect the Converter to the USB port. 2. Open the Windows Device Manager. 3. The New Device Wizard will have added the converter under Ports (COM & LPT) and will appear as MicroLink HART Protocol Modem (COMx).
- Page 4 Using Windows Device Manager The assigned COM port number can be found using Windows Device Manager. Open Device Manager and select View > Devices by Type You may need to expand the Device Manager tree under Ports (COM and LPT) see the converter.
- Page 5 Software Setup Make sure your HART so ware is set to use the same serial COM port number that the MicroLink modem is assigned to. There are no hardware se ngs required by the MicroLink modem and modem power is provided by the USB port. All other se ngs, such as BAUD rate and parity, are taken care of by your HART so ware.
- Page 6 (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Microflex could void the user’s authority to oper- ate this equipment. Emissions EN55022: 1998...
- Page 7 Specifications 2.568 1.705 65.22 mm 43.31 mm 1.580 1.091 40.13 mm HART 27.71 mm STATUS LED USB-B 35 mm DIN RAIL CLIP Enclosure Polycarbonate plas c with Stainless Steel Cover Weight ..................5 ounces Connector .................. USB-B Compa bility ........... USB 1.1, USB 2.0, and USB 3 Ac ve Current ..............30mA Max Suspend Current ..........Less than 600μA Typical HART...
- Page 8 RIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF MICROFLEX SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER. MICROFLEX, LLC WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITIES THEREOF.
