LIGMAN LA-30013 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Lightaik wall washer floodlights RGBW.
Model. LA-30013 and LA-30014
Product drawing (dimensions)
113
20
Ø6
65
50
MOUNTING DETAIL
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-5 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504 sales.cz@ligman.com
|
www.ligman.com
606 OR 1200
485 OR 560
LA-30013,LA-30014
1
Torque :3.0Nm.
3
Torque :4.3Nm.
