Exibel SO52-UK Instruction Manual

Paper Shredder
Art.no 18-8052 Model SO52-UK
38-1376 SO52
Please read the entire instruction manual before using the product
and save it for future reference. We reserve the right for any errors
in the text or images and any necessary changes made to technical
data. If you have any questions regarding technical problems please
contact our Customer Services.

Safety

• Place the machine as close to a wall outlet as possible.
• Always remove the plug from the wall socket before moving or
cleaning the shredder.
• Always remove the plug from the wall socket before emptying the
waste collection bin. Empty the collector bin regularly in order to
avoid jamming the machine because of the container being over
full.
• Never open the casing. If you should have problems with the
shredder, contact Customer Services.
• The product is designed exclusively for domestic use. The
machine is not designed for commercial use.
Warning symbols
General warning symbol.
Read the instructions before use.
This product is not a toy and must not be used by children.
Never leave the shredder unattended when in operation.
Keep your hands away from the feeder opening.
Keep your hands away from the feeder opening.
Your fingers may be pulled in and become injured.
Keep loose hanging objects, like clothes, ties, jewellery
away from the feeder opening. They may be pulled in and
damaged.
DO NOT use sprays when cleaning the shredder's interior
or exterior. DO NOT use flammable substances in the near
vicinity of the product. DO NOT use sprays directly in or in
the vicinity of the feeder opening.
GREAT BRITAIN - CUSTOMER SERVICE Contact number: 08545 300 9799, e-mail: customerservice@clasohlson.co.uk, internet: www.clasohlson.com/uk
English
Remove all paper clips and staples before running them
through the shredder.
Keep loose hanging jewellery away from the feeder
opening. They may be pulled in and damaged.

Getting started

1. Place the shredder unit onto the waste container. The shredder
unit is extendable on one side which means it can be used
together with 275–380 mm wide waste containers.
2. Place the waste container on an even and stable surface.
3. Connect the plug to a wall outlet with 220–240 V AC voltage rating.

Operation

The control switch has 3 settings:
• ON/AUTO
Automatic start. When the switch is in this mode the shredder
will start automatically when the paper is placed in the feeder
opening. When the paper is fed through the machine will turn
off automatically. If it does not turn off, make sure that the waste
container is not full or that there are no paper remnants stuck in
the shredder.
• REV
Reverse function. Used to remedy a paper jam. If you notice that
the shredder is overloaded and starts to struggle or stop, you
must immediately set the control switch in REV mode. This allows
the blades to rotate backwards and the paper can be fed back
out of the feeder opening.
• FWD
Forward function. Used to clear the blades from paper remnants
and dispose of them in the waste container. You can even use
the FWD and REV modes to try to remove trapped remnants from
the blades.

Capacity

• The shredder can process up to 5 sheets (A4, 80 g) at one time.
The resulting strips will be 7 mm wide. If you run thicker paper
stock the number of sheets the shredder can process is reduced.
The maximum width of the paper should be 21.8 cm (A4).
• If you want to shred smaller sheets of paper, you should feed them
in the centre of the shredder. Otherwise, the shredder will not start
automatically.

Avoiding overloading and jamming

The shredder is equipped with overload protection. When activated
the shredder shuts off when, for example, trying to feed more than
5 sheets in at a time.
To reset the shredder after the overload protection has tripped:
1. Remove the plug from the wall socket and let the shredder cool
for 30 min. Clear the blades of any paper remnants.
2. Connect the plug to a wall socket and set the control switch to
REV mode. Excess paper remnants will exit through the feeder
opening. Remove the plug from the wall outlet and remove any
paper remnants from the blades.
3. Set the switch to ON/AUTO mode.

Care and Maintenance

• Always unplug the machine from the wall socket before cleaning.
• The blades need no maintenance and do not need lubrication.
• Clear the blades from paper remnants using a sharp object.
• Dry the exterior and container using a dry cloth.
• Never use flammable cleaning agents.
• Empty the waste container regularly. A full waste container can
contribute to a diminished functioning of the shredder.

Disposal

Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product, please
contact your municipality.

Specifications

Strip-cut
Type
Strip width Approx. 7 mm
Capacity 5 sheets (80 g) simultaneously, 2.5 m/min.
Feeder width 218 mm
Shredder size Approx. 314 × 115 × 76 mm
Power supply 220–240 V AC, 50 HZ, 0.5 A
Power 115 W
