Frigidaire FRS23SM4A Factory Parts Catalog

Frigidaire FRS23SM4A Factory Parts Catalog

Side by side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS23SM4AW0
FRS23SM4A
MARKET
North America
WIRING DIAGRAM - 240389604
OWNER'S GUIDE - 240389303
SERVICE DATA SHEET - 240389604
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995368106
020312
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23SM4A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS23SM4A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS23SM4A

Summary of Contents for Frigidaire FRS23SM4A

  • Page 1 PRODUCT NO. BASE MODEL NO. FRS23SM4AW0 FRS23SM4A MARKET North America WIRING DIAGRAM - 240389604 OWNER’S GUIDE - 240389303 SERVICE DATA SHEET - 240389604 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a white SIDE BY SIDE...

  • Page 2: Freezer Door

    Publication No. FRS23SM4AW0 5995368106 FREEZER DOOR 03/02...
  • Page 3 POS. NO 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 FREEZER DOOR PART NO DESCRIPTION 240390604 Gasket-door,white 240367301 Bin-door,frzr-upper 240359001 Bin-door 240451880 Door-frzr,white ,complete assy 240456902 Door Stop,white ,frzr 218762701 Handle-door,white 5308016566 Screw,hex washer head ,8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625 240328202...

  • Page 4: Refrigerator Door

    Publication No. FRS23SM4AW0 5995368106 REFRIGERATOR DOOR 03/02...
  • Page 5 POS. NO 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390603 Gasket-refr door,white ,magnetic 240363701 Bin-door,2-liter 240338303 Door,dairy ,clear 240456901 Door Stop,white ,ref 240451947 Door-refr,white ,complete assy 218762701 Handle-door,white 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625...
  • Page 6 Publication No. FRS23SM4AW0 5995368106 CABINET 03/02...
  • Page 7 POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 CABINET PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240413601 Switch,light/lamp ,rocker 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. FRS23SM4AW0 5995368106 SHELVES 03/02...
  • Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 SHELVES PART NO DESCRIPTION 240434601 Trim-basket 240338801 Shelf-freezer,flip-up 240338701 Shelf-freezer,fixed wire 240338703 Shelf-freezer,fixed wire 240355211 Shelf-"Spill-Safe",fixed 240354501 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240354601 Cover-crisper pan,lower 240354705 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240351101 Control-humidity 240354807 Pan-crisper,lower...
  • Page 10 Publication No. FRS23SM4AW0 5995368106 CONTROLS 03/02...
  • Page 11 POS. NO 13 # 23 # 115* 137# # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315803 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436701...
  • Page 12 Publication No. FRS23SM4AW0 5995368106 SYSTEM 03/02...
  • Page 13 POS. NO 6* # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 SYSTEM PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240315901 Harness-wiring 240439901...
  • Page 14 Publication No. FRS23SM4AW0 5995368106 DISPENSER 03/02...
  • Page 15 POS. NO 38A# # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 DISPENSER PART NO DESCRIPTION 218976405 Tube-water inlet 218976901 Tube-water inlet, inlet valve to ice maker 218976904 Tube-water inlet,valve to filter 218976907 Tube-water inlet,valve to door 5304421822 Cover-module,white 5304422030 Module-dispenser 5304421626 Spring-torsion...

  • Page 16: Ice Container

    Publication No. FRS23SM4AW0 5995368106 ICE CONTAINER 03/02...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 ICE CONTAINER PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. FRS23SM4AW0 5995368106 ICE MAKER 03/02...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # 55*# 55*# # = Fast-moving Parts * = Non-Illustrated Parts FRS23SM4AW0 ICE MAKER PART NO DESCRIPTION 218976405 Tube-water inlet 218976901 Tube-water inlet,inlet valve to ice maker 218976904 Tube-water inlet,valve to filter 218976907...

  • Page 20: Wiring Schematic

    Publication No. FRS23SM4AW0 5995368106 WIRING SCHEMATIC 03/02...

  • Page 21: Wiring Diagram

    FRS23SM4AW0 Publication No. 5995368106 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
