Frigidaire FRS23LH5D Factory Parts Catalog

Frigidaire FRS23LH5D Factory Parts Catalog

Side-by-side refrigerator
Hide thumbs Also See for FRS23LH5D:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Use and Care Manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FACBBB4.eps N58RACBBB7.eps N58BAAAAA0.eps
N58SJCAAB1.eps N58TAAAAA4.eps N58CAAAAC0.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRS23LH5DB0 FRS23LH5DQ0 FRS23LH5DS0 FRS23LH5DW0
R134a
R134a
R134a
black
bisque
stainless
115
115
115
241526901
241526901
241526901
241581300
241581300
241581300
North America North America
North America North America
241538736
241538736
241538736
240389616
240389616
Publication No.
5995412334
04/06/28
(EN/SERVICE/KHB)
357
R134a
white
115
241526901
241581300
241538736
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23LH5D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS23LH5D

Summary of Contents for Frigidaire FRS23LH5D

  • Page 1 241526901 241526901 241581300 241581300 241581300 North America North America North America North America 241538736 241538736 241538736 240389616 240389616 SIDE-BY-SIDE REFRIGERATOR FRS23LH5D Publication No. 5995412334 04/06/28 (EN/SERVICE/KHB) © Copyright R134a white 241526901 241581300 241538736 240389616 Model No. 2004 Electrolux Home Products, Inc.

  • Page 2: Freezer Door

    Publication No: 5995412334 FRS23LH5D FREEZER DOOR 06/04...
  • Page 3 218490901 240352102 240552101 5303918256 # Functional Parts * Non-Illustrated Parts FRS23LH5D FREEZER DOOR A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A - C - Gasket-frzr door, black, magnetic - B - D Gasket-frzr door, white...

  • Page 4: Refrigerator Door

    Publication No: 5995412334 06/04 FRS23LH5D REFRIGERATOR DOOR N58RACBBB7...
  • Page 5 37A* 215782300 240324502 218490901 # Functional Parts * Non-Illustrated Parts FRS23LH5D REFRIGERATOR DOOR A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A - C - Gasket-refr door, black, magnetic - B - D Gasket-refr door, white, magnetic...
  • Page 6 Publication No: 5995412334 FRS23LH5D CABINET 06/04...
  • Page 7 240368701 240396801 240481601 5303305345 5303305324 # Functional Parts * Non-Illustrated Parts FRS23LH5D CABINET A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Cover-air duct A B C D Cover-evap coil, lower A B C D...
  • Page 8 Publication No: 5995412334 FRS23LH5D SHELVES 06/04...
  • Page 9 218867405 218867406 240430501 240389616 241538736 # Functional Parts * Non-Illustrated Parts FRS23LH5D SHELVES A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Shelf-freezer, flip-up A B C D Shelf-freezer, fixed wire A B C D...
  • Page 10 Publication No: 5995412334 FRS23LH5D CONTROLS 06/04...
  • Page 11 240545201 240331607 240394102 240376002 # Functional Parts * Non-Illustrated Parts FRS23LH5D CONTROLS A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Fan Blade, red, evaporator fan A B C D Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995412334 FRS23LH5D SYSTEM 06/04...
  • Page 13 5304421068 240553501 240409302 5303918213 5303918222 # Functional Parts * Non-Illustrated Parts FRS23LH5D SYSTEM A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Condenser A B C D Block-evap coil, styrofoam, (2) A B C D...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995412334 FRS23LH5D ICE & WATER DISPENSER 06/04...
  • Page 15 5304421622 5304421621 5304421615 5303918256 # Functional Parts * Non-Illustrated Parts FRS23LH5D ICE & WATER DISPENSER A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Tube-water A B C D Tube-water inlet, inlet valve, to ice maker...

  • Page 16: Ice Container

    Publication No: 5995412334 FRS23LH5D ICE CONTAINER 06/04...
  • Page 17 5304404361 5304404363 5304404331 240323808 240507202 # Functional Parts * Non-Illustrated Parts FRS23LH5D ICE CONTAINER A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Auger-ice A B C D Cam-drive A B C D...

  • Page 18: Ice Maker

    Publication No: 5995412334 FRS23LH5D ICE MAKER 06/04...
  • Page 19 5303001343 5303001193 5308000133 240387101 # Functional Parts * Non-Illustrated Parts FRS23LH5D ICE MAKER A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Tube-water A B C D Tube-water inlet, inlet valve, to ice maker...
  • Page 20 Publication No: 5995412334 FRS23LH5D ICE MAKER 06/04...
  • Page 21 218737900 5303001549 218888001 240352411 # Functional Parts * Non-Illustrated Parts FRS23LH5D ICE MAKER A FRS23LH5D (FRS23LH5DB0) B FRS23LH5D (FRS23LH5DQ0) C FRS23LH5D (FRS23LH5DS0) D FRS23LH5D (FRS23LH5DW0) DESCRIPTION A B C D Valve-water, triple solenoid A B C D Screw, hex head, 10-32 x 0.500...

  • Page 22: Wiring Schematic

    Publication No: 5995412334 FRS23LH5D WIRING SCHEMATIC 06/04...

  • Page 23: Wiring Diagram

    FRS23LH5D Publication No: 5995412334 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
