Summary of Contents for EDAC 315
- Page 1 EDAC Electronics Ltd EDAC 315 Quick Start Guide Document Version 1.0 For v5 Hardware and Firmware from v2.11.0 www.edacelectronics.com © 2007 EDAC Electronics Ltd...
-
Page 2: Power Supply
The EDAC 315 is a cost effective, cellular based remote monitoring control and logging system. Based off the tried and true EDAC 300 series product the EDAC 315 integrates all of the features of the SMS 300 as well as adding some new ones. -
Page 3: Dc Power Input
The EDAC 315 has an internal power supply selection ‘jumper’ which designates which type of supply the 315 is set up to run from, either AC or DC. It is very important that the power supply selection jumper is set correctly for the type of supply that is to be used. - Page 4 SIM cards. The SIM must be fitted into the unit before the EDAC 315 will operate. To do this the unit must be powered down and end plate must be removed to expose the SIM connector. Remove the connector blocks from the end plate (the end the aerial connects to) and remove the screws securing the end plate as detailed in Fig 3.1a.
- Page 5 The EDAC 315 is configured using ‘EDAC 300 Series Configuration Manager’, a software interface custom designed for the 315. This software runs on a Windows based P.C. and connects to the 315 via a RS-232 (Serial) connection. The ‘Configuration Manager’ is used to configure all aspects of the unit’s functionality.
-
Page 6: Diagnostics Interface
Select the baud rate for the connection form the ‘Baud Rate’ list. Note that by default the COM port on the 315 is set to work at 9600. This setting should not be changed unless the COM port on the 315 has been configured to work at a different speed. - Page 7 BER (or ‘Bit error Rate’) gives an indication of the quality of the received signal. It gives an indication of the level of errors encountered when transmitting digital data. A BER reading of zero should normally be encountered. www.edacelectronics.com © 2007 EDAC Electronics Ltd...
- Page 8 For further information on configuring and using the EDAC 315 please see the user manual supplied on the CD-ROM with the product. www.edacelectronics.com www.edacelectronics.com © 2007 EDAC Electronics Ltd...
