ELCOS RO-405 Quick Start Manual

14.5
THREADED HOLE
THREADED HOLE
OPERATION
The heater, once it has been mounted in contact with
the engine oil sump, prevents the temperature of the oil
from falling below a certain set value.
This value is maintained via the internal thermostat.
All of the electrical connections are rendered easy by the
presence of a cable.
ORDERING INFORMATION
Type RO-405 230V 350W code 00706017
Type RO-803/00 230V 700W
ELCOS SRL - Parma - RO-405 RO-803/00 - EN
TYPE RO-405 RO-803/00
TYPE RO-405 TYPE RO-405 TYPE RO-405
TIYPE RO-803/00
code 00706016
OIL HEATERS
MOUNTING AND CONNECTING
230 V
TECHNICAL CHARACTERISTICS
- Power supply
- Insulation voltage
- Dielectric strength between
terminals and contactor
- Power absorbed
- Service
- Work thermostat
- disengaged heating
- engaged heating
- Silicone cable LD-PE
- Degree of protection
- Temperature range
- Weight
HOLES TO FIX SUMP
OIL SUMP
CABLE LENGTH
3m
YELLOW/
GREEN
230 VAC (± 10%) 50÷60 Hz
250 V
2000 VAC x 1 minute
RO-405
RO-803/00 700 W
continuous
non-adjustable
at 72°C ± 10%
at 57°C ± 10%
with braiding
IP 54
-20 ÷ +120°C
RO-405
RO-803/00 3600 g
350 W
1500 g
