Summary of Contents for RedPort Halo Pro
- Page 1 Halo Pro Long Range Wi-Fi Extender System Quick Start Guide...
-
Page 2: Table Of Contents
Introduction to the Halo Pro Wi-Fi Extender System..3 Safety...................4 Product Specifications............5 Physical Setup..............7 Operating Halo Pro Using the Halo Wi-Fi App....10 Operating Halo Pro Using a Mac or PC......13 Using Halo Pro with Captive Portal Mac and PC....16 Product Warranty Information...........17 Product Support Information..........18... -
Page 3: Introduction To The Halo Pro Wi-Fi Extender System
Introduction to the Halo Pro Wi-Fi Extender System Thank you for your recent purchase of a RedPort Halo Pro Long Range Wi-Fi Extender System. Halo Pro keeps you connected to remote 2.4GHz and 5GHz Wi-Fi sources at long distances. This Quick Start Guide will cover a basic overview and set of procedures to start operating your RedPort Halo Pro system. -
Page 4: Safety
PoE networking equipment to the Optimizer and does not warranty any resultant damage. Component Damage Warning Hard wiring the Halo Pro Extender and associ- ated equipment into the vessel electrical system should be accomplished by a certified electrician. Proposition 65... -
Page 5: Product Specifications
Product Specifications Optimizer Compliance Regulatory FCC, CE, RoHS Hardware Router Dimension, L x W x H 4 9/16” x 3 3/8” x 1” Router Weight 0.4 lbs or 0.18 kg Chipset MT7620A for 2T2R 300Mbps Reset and WPS button 1 button 256 MB Flash 32 MB... - Page 6 Extender Antenna Compliance Regulatory CE, FCC, IC, EAC, ROHS Hardware Height 22 in or 55.88 cm Diameter 2 in or 5.08 cm Weight 2 lbs or 0.91 kg 64 MB Flash 16 MB Power Supply and Consumption PoE In Passive PoE PoE in input Voltage 10-30 V Number of DC inputs...
-
Page 7: Physical Setup
Wi-Fi source. Run Ethernet cable from the Ex- tender to Optimizer. Vessel Mounting: Halo Pro can be installed in many dif- ferent locations on board. For best results, mount the Wi- Fi Extender 15-25 feet above the water line. This will in- crease the chances of capturing Wi-Fi via line-of-site. - Page 8 RJ-45 port of the Wi-Fi Extender. Step 3. Connect the Ethernet base mount coupling to the base of the Halo Pro Extender and line the screw holes up Step 4. Attach the base coupling to the Extender base us- ing the three provided screws and a flathead screwdriver (not provided).
- Page 9 2. 12V 4A DC Car Charger (sold separately) with 10M Eth- ernet cable run to the Extender. Note: The Halo Pro Extender is a part of a system and not intended for separate use. The only way to power the unit is...
-
Page 10: Operating Halo Pro Using The Halo Wi-Fi App
Available on the Apple App Store & Google Play Store. Use of the Halo Wi-Fi App is the RECOMMENDED way to setup and use your Halo Pro Long Range Wi-Fi Extender. iOS Halo Wi-Fi App Installation and Setup Step 1. - Page 11 Step 4. Open Halo Wi-Fi App - Click <Halo WiFi App> icon on your device. Step 5. Configure Halo Wi-Fi - There are two ways to con- figure the Halo Wi-Fi. 1. You can click <Press Here to Search for Networks> or 2. You can click <WiFi> at the bottom of the Halo Wi-Fi App “Home”...
- Page 12 Step 6. Select Wi-Fi Source - Connect to the Wi-Fi network of your choice by clicking <”network name”>. If required, enter the password for the selected network, then click <Join>. Optionally, you can click <Rescan> to force a new search and you can sort found networks by Wi-Fi strength;...
-
Page 13: Operating Halo Pro Using A Mac Or Pc
Operating Halo Pro Using a Mac or PC NOTE: Using the Halo App is the recommended process for installation and setup (see page 10). However, setup us- ing a computer and a web browser is easy using Halo Pro’s simple user interface. Step 1. - Page 14 “Enable Halo Pro WiFi Extender Setup”. Step 4. You will be redirected to 192.168.89.1 to access the Halo Pro Extender Portal You will be brought to the dashboard, where you will see a list of the available Wi-Fi sources in your area.
- Page 15 Step 5. Click on the Wi-Fi you intend to connect to. In this case, we are going to connect to the third in the list. Click on it and if it is password protected, a password field will appear below the name of the Wi-Fi source. Fill this in and click <Connect>.
-
Page 16: Using Halo Pro With Captive Portal Mac And Pc
Click on the Wi-Fi source of your choice and click <Connect>. Step 4. If there is a captive portal, the Halo Pro will detect it and allow you to choose whether you would like to <Login> or <disconnect> to the Captive Portal. -
Page 17: Product Warranty Information
• Using accessories, parts or components not sup- plied by RedPort. • Products with missing or altered service tags or se- rial numbers • Products for which RedPort has not received pay- ment • Normal wear and tear... -
Page 18: Product Support Information
Product Support Information RedPort agrees to provide initial customer assistance, up to thirty (30) minutes at no charge. It is recommended that a customer has reasonable knowledge of basic computer and software setup procedures for the initial installation. Support Type...
