Installation Manual for Outdoor Unit AU042FNERA AU052FNERA No. 0150546441 • This product must only be installed or serviced by qualified personnel. Please read this manual carefully before installation. Keep this operation manual for future reference. Original instructions...
User Manual Contents All the products are in conformity with the following Product Features ............1 European provision: -Low voltage Directive Safety ................1 -Electomagnetic Compatibility Transportation and Lifting ..........3 Installation instruction ............ 4 Electric wiring and the application ....... 13 Warning Installation and debugging...........
Product Features • The outdoor uint adopts "simultaneous control" type, all indoors should be heating or cooling simultaneously. • To protect compressor,before startup,the unit should be electrified for 12 hours.If the unit is not used for a long time, please cut off the power to save energy, or the unit will consume the power. This manual describes the installation and installation of outdoor units.
Page 4
Safety • The maintenance cover plate of the indoor or outdoor machine is forbidden when the main circuit power supply is not cut off. • The leakage of refrigerant can cause the air to be thin and difficult to breathe. In case of refrigerant leakage, close the main valve, extinguish any flame and contact the local distributor immediately.
Transportation and Lifting Lifting In front of the unit shipped from unpacking location as close as possible. Over 60 degrees rope CAUTION 0.7~1.0 meters • Do not place anything on the device. • Two ropes shall be used for lifting the outdoor unit. Hoisting method Hoisting to ensure that the level of outdoor machine, slowly lifting.
Combination Total indoor capacity Model Indoor qty (100W) type (100W) total indoor branch pipe capacity AU042FNERA Single 61-157 (optional) (100W) AU052FNERA Single 70-182 Notice: less than 335 FQG-B335A • Total capacities of indoor units being used ≤ 100% of rated capacities of outdoor unit.
Page 7
Installation instruction Note: 1. In snowy area, install the unit under the bracket or the snow-proof cover against the accumulative snow on the unit. 2. Do not install the unit at the place where the flammable gas will leak. 3. Install the unit at the strong enough place. 4.
Page 8
Installation instruction (3) Multi-unit installation in front and back (unit: in.(mm)) The top and two side surfaces must be exposed to open space, and barriers on at least one side of the front and back shall be lower than the outdoor unit. •...
Page 9
• After punching the knock-out hole, the the min. thickness. application of repair-type paint on the 3. The branch pipe must be from Haier. surface around the edge sections is 4. When installing the stop valve, refer to the relative operation instruction.
Page 10
3. Pipe "c" diameter ( outdoor pipe diameter) Copper pipe selection: hardness softness Model Gas pipe (mm) Liquid pipe (mm) Outer diameter (mm) Ø6.35 Ø9.52 Ø12.7 Ø15.88 AU042FNERA Ø15.88 Ø9.52 Min. thickness (mm) AU052FNERA Ø15.88 Ø9.52 hardness Half-hardness Note: Outer diameter (mm) Ø19.05 Ø22.22 Ø25.24 Ø28.58 When the distance from outdoor to the longest indoor is Min.
Page 11
Installation instruction Long pipe and high drop 1. Allowable pipe length and height difference Outdoor unit First branch piping Indoor unit Length of the longest piping L Length of the longest piping after the h≤10m first branch piping L(*) Maximal length and drop height permissible of refrigerant piping Permissible value Piping part Total length of piping (actual length)
Page 12
Installation instruction Note: 1. When connecting the pipe and the outdoor, please pay attention to the outdoor pipe dimension. 2. When adjusting the diameter among pipes and among the units, please must execute at the branch pipe side. 3. When welding with hard solder, please must blow nitrogen. If not, a number of oxide will be produced and cause heavy damage.Besides,to prevent water and dust into the pipe, please make the brim as outer roll.
Page 13
Installation instruction • Weld the pipe at the same time charge the nitrogen. Or it will cause a number Seal the pipe end with of impurity (a film of oxidation) to clog the capillary and the expansion valve, adhesive tape or the stopper further cause the deadly failure.
Page 14
Installation instruction Because the unit is with refrigerant R410A, the below issues should be paid attention: • To prevent the different oil into the pipe, please use the special tool for R410A, especially for gauge manifold and charging hose. • To prevent the compressor oil into the refrigerant cycle, please use the anti-counter-flow adapter. (8) Check vale operation Open/close method: •...
Electric wiring and the application WARNING Inspect • Switch off the main power switch of the indoor • To ensure that the electrical equipment used on the installation and outdoor machine for more than 1 minutes site (main power switch, circuit breaker, wire, conduit and wiring before the wiring or regular inspection.
Page 16
Section source Ground fault interruptor (mA) Screw response time (S) Model AU042FNERA 32A 30mA below 0.1S 1PH, 220-240V~, 50/60Hz AU052FNERA 40A 30mA below 0.1S • Power cable must be fixed firmly. • To avide electrical shock, make sure to disconnect the power supply 1 minute or more before servicing the electrical parts.Even after 1 minute,always measure the voltage at the terminals of main circuit capacitors or electrical parts and...
Page 17
Electric wiring and the application • When power cable exceeds the range, thichen it appropriately. • The appliance shall be installed in accordance with national wiring regulations. • All wiring must be performed by an authorized electrician. • Be sure to install an earth leakage circuit breaker in accordance with applicable legislation.Failure to do so many cause electrical shock.
Installation and debugging 1. Installation and debugging method of outdoor machine SW01 SW02 Seven segment digital tube display content Outdoor machine fault code The machine units are not locked and no fault, in turn cycle "in the machine number, power supply type".
Page 19
Installation and debugging SW01 SW02 Seven segment digital tube display content Forced heat alternating display "HHH" (according to Start 5 seconds to enter, all the internal mechanism of hot running, press Stop to exit for 5 seconds). Communication shows the program version (1 decimal), or "---" The machine type: (0:common indoor machine;...
Page 20
Installation and debugging 2. Outdoor unit PCB dipswitch setting, attention the different PCB version. In the following table, 1 is ON, 0 is OFF. BM1 introduction Begin to search indoor BM1_1 Indoor searching after startup Stop searching indoor and lock the quantity Note: Either indoor unit unlocked or the locked quantity different with actual connecting number, it cannot run.
Failure code Inverter outdoor unit failure code Digital tube indication on Failure code definition Failure description Remarks master unit Defrosting temp.sensor Te AD value is below 11(open circuit) or over 1012(short circuit) failure for 60seconds, in cooling mode, if the sensor is abnormal, Resumable the unit does not deal with it, besides, in defrosting and Defrosting temp.sensor Tc...
Page 22
Failure code Digital tube indication on Failure code definition Failure description Remarks master unit 3 times in an hour, confirm CT current is too low or 3 minutes after recovery failure; once current sensor fault confirmation, un-resumable Cannot receive valve plate module signal in 200 continuous Valve plate module rounds or receive wrong data,recover automatically when Resumable...
Page 23
Failure code Digital tube indication on Failure code definition Failure description Remarks master unit Transient over current in IPM Transient over current in IPM module rectifier side software module rectifier side software Current detection circuit Current detection circuit abnormality abnormality 3 times in an IPM modular over current, in short circuit, over heat, voltage hour, confirm...
Page 24
Failure code When there is no failure, if the starting condition can not be met, digital tube on master unit will display stand-by code: Standby state of capacity When the ratio of indoor horse power and outdoor horse power is 555.0 overmatch less than 50% or more than 130%, the system is in standby mode.
Trial operation and the performance Confirm the type of outdoor machine and the number of inside machine • After installation, please confirm that the outdoor computer board BM1_1 is in the 0 state, and then to the unit power, observe the digital display. If the number of the indoor machine and the outdoor machine type, the power supply voltage is correct, then the BM1_1 dial to 1 of the state, if it is not correct, please check the dial machine communication code and models, do not force the BM1_1 dial to 1 of the state, it may cause failure of the system.
Page 26
Trial operation and the performance Trial operation • Before trial operation: Before being electrified, measure the resistor between power terminal block (live wire and neutral wire) and the earthed point with a multimeter, and check if it is over 1MΩ. If not, the unit can not operate. To protect compressor, electrify the outdoor unit for at least 12 hours before the unit runs.If the crankcase heater is not electrified for 6 hours, the compressor will not work.
Move and scrap the air conditioning • When moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support. • In the composition material of air conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers are not more than 0.1% (mass fraction) and cadmium is not more than 0.01% (mass fraction).
Page 28
Qingdao Haier Air Conditioner Electric Co.,Ltd. Haier Industrial Park,Qianwangang Road,Eco-Tech Development Zone,Qingdao 266555, Shandong,P.R.C.
