The SPEED CLEAN
with START TIME pad, a delayed Self-Cleaning cycle may also be programmed. This feature allows for any Self-
Cleaning cycle times from 2 hours (using Speed Clean), 3 hours (using Clean) to 4 hours (using Maxx Clean).
During the Self-Cleaning cycle, the outside of the range can become very hot to the touch. DO NOT leave
small children unattended near the appliance.
DO NOT force the oven door open. This can damage the automatic door locking system. Use care when
opening the oven door after the Self-Cleaning cycle. Stand to the side of the oven when opening the door to allow hot air or
steam to escape. The oven may still be VERY HOT.
INSTRUCTIONS
To start an immediate Self-Cleaning cycle or to set a delay
start time of 9:00 o'clock and shut off automatically (example
provided is a default 3 hour Self-Clean cycle):
1. Be sure the clock is set with the correct time of day, the oven is
empty and the oven door is closed.
2. Press . "CLEAN" will flash and "3:00" (hours) will show in
the display (See Fig. 1). Note: 2 hours of Self-Cleaning time
may be choosen by pressing
at this time.
3. Press .The "DOOR LOCKED" icon will flash; "CLEAN"
and the letters "CLn" will remain on in the display (Fig. 2).
4. As soon as the control is set, the motor driven oven door lock
will begin to close automatically. Once the door has been
locked the "DOOR LOCKED" indicator light will quit flashing
and remain on(Fig. 3).
NOTE: If the optional delay Self-Clean feature is needed, finish steps 5-7. If Self-Clean is started immediately skip the remaining
steps and continue with "When the Self-Clean cycle is done" on the following page.
5. Press (See Fig. 4). Enter the desired Self-Clean starting
time using the number pads
6. Press . "CLn" icon will turn off; "DELAY", "DOOR
LOCKED" and "CLEAN" icons will remain on.
7. The control will calculate forward from the set start time to
determine when the Self-Cleaning cycle should end. The Self-
Cleaning cycle will turn on automatically at the set time. At that
time the icon "DELAY" will go out; the oven icon will come on,
the start time, "CLEAN" and "CLn" will remain in the display
(See Fig. 6).
Self-Cleaning
, CLEAN and MAXX CLEAN
or 4 hours by pressing the
(See Fig. 5).
pads are used to start a Self-Cleaning cycle. When used
PRESS
or
, optional.
27
DISPLAY
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
