Dwyer Instruments MM10 Series Operating Instructions

SERIES MM10 DIGITAL MULTIMETER

SAFETY INFORMATION

The following safety information must be observed to insure
maximum personal safety during the operation of this meter.
Do not use the meter if the meter or test leads look damaged, or
if you suspect that the meter is not operating properly.
Never ground yourself when taking electrical measurements. Do
not touch exposed metal pipes, outlets, fixtures, etc., which might
be a ground potential. Keep your body isolated from ground by
using dry clothing, rubber shoes, rubber mats, or any approved
insulating material.
Turn off power to the circuit under test before cutting,
unsoldering, or breaking the circuit. Small amounts of current
can be dangerous.
Use caution when working above DC 60V or AC 30Vrms. Such
voltages pose a shock hazard.
When using the probes, keep your fingers behind the finger
guards on the probes.
Measuring voltage which exceeds the limits of the multimeter
may damage the meter and expose the operator to a shock
hazard. Always recognize the meter voltage limits as stated on
the front of the meter.

GENERAL SPECIFICATIONS

Display: 3-1/2 digit liquid crystal display (LCD) with a maximum
reading of 1999.
Polarity: Automatic, positive implied, and (-) for negative polarity
indication.
Overload: (1) or (-1) is displayed on LCD.
Low Battery Indication: When "
needs to be replaced.
Sampling Rate: 2.5 times per second.
Operating Environment: 0°C~40°C 80% RH.
Storage Temperature: -10°C~60°C 0~80% RH with battery
removed from meter.
Power: One 006P 9V standard battery.
Battery Life: 150 hours approx.
Dimension: 125 mm (H) x 68 mm (W) x 25 mm (D).
Weight: 150g approx. including battery.
Accessory: Instruction manual, test leads, (1) 9V battery.

SPECIFICATIONS

DCV
Range Resolution
2V 1mV 0.5% + 1 dgt
20V 10mV
200V 100mV 1.5% + 1 dgt
600V 1V
OPERATING INSTRUCTIONS
" shows on LCD, battery
Input
Accuracy
Impedance
10MΩ
ACV
Range
200V
600V
DCA
Range
2mA
20mA
200mA
10A
Resistance (Ω)
Range
200Ω
2KΩ
20KΩ
200KΩ
2MΩ
20MΩ
Diode Test
Range
Continuity Test
Range
Transistor hFE
Range
NPN
PNP
LED
Range
LED
Overload
Protection
DC 600V
AC 600V
rms
Resolution Accuracy
2% + 3 dgt
100mV (40 Hz-
500 Hz)
1V 2.5% + 3 dgt
Resolution Accuracy
1μA
10μA 1.5% + 1 dgt
100μA
10mA 2% + 1 dgt
Resolution Accuracy
0.1Ω 2% + 2 dgt
1Ω
10Ω
1.5% + 2 dgt
100Ω
1KΩ
10KΩ 2.5% + 2 dgt
Test
Resolution
Current
1mV 1mA
Resolution Sound
0.1Ω <30Ω
Measuring Test
Scope Voltage
0-1000 <3.2V
Measuring Test
Scope Voltage
1.5-3V 3V
Input Overload
Impedance Protection
DC 600V
4.5MΩ AC 600V
rms
Input Overload
Impedance Protection
0.5A Fuse
0.3V
& Diodes
0.7V
Open Overload
Voltage Protection
2.8V
DC/AC
500V
0.3V rms
Open Overload
Voltage Protection
DC/AC
≈2.8V
500V rms
Open Overload
Voltage Protection
AC/DC
<≈2.8V
500V rms
Test Overload
Current Protection
IB≈10μA
Test Overload
Current Protection
≈25mA
