Sentryus ECO EIR35-F4840 Operational Manual

EIR35-F4840
EIR35-F4860
EIR35-F4840P
EIR35-F4860P

FEATURES

1/3" Sony CCD
480 TV Lines
IR distance up to 100ft / 30m
EIR35-F4840: 4.0mm Lens
EIR35-F4860: 6.0mm Lens

SPECIFICATIONS

PIC
Model
TV System
Image Sensor
Picture Elements
Sync System
Scanning System
Horizontal Resolution
Minimum Illumination
IR LED
IR Distance
Wavelength
Lens
Signal to Noise Ratio
Electronic Shutter
White Balance Control
AGC
BLC
IP Rating
Video Output Signal
Operating Temperature
Power
Power Consumption
Dimension
Weight
Copyright © 2010. All Rights Reserved.
REV12072010
Please read the Operational Manual
before attempting to use this product.
Operational Manual
35 IR Day & Night Weatherproof Color Camera
I-305
EIR35-F4840
NTSC
768(H) x 494(V)
4.0mm Lens
1/60 ~ 1/10,000sec 1/50 ~ 1/10,000sec
448mA max @ IR "on" / 127mA @ IR "off"
35 IR LED
0 Lux @ IR "on"
IP67 Rating
12V DC, 448mA max @ IR "on" / 127mA @ IR "off"
EIR35-F4840P EIR35-F4860
PAL
1/3" Sony CCD
752(H) x 582(V)
768(H) x 494(V)
Internal
2:1 Interlace
480 TV Lines
0 Lux @ IR "on"
35 IR LED
Up to 100ft / 30m
850nm
Max 48dB
1/60 ~ 1/10,000sec
Auto
On
Off
IP67
1.0 V p-p Composite Video Output, 75Ω
23°F ~ 140°F / -5°C ~ 60°C
12V DC
4.8" x 3.23" x 3.43" / 122 x 82 x 87mm
1.54 lbs / 700g
1
Wall Mount Bracket Included
I-306
EIR35-F4860P
NTSC
752(H) x 582(V)
6.0mm Lens
1/50 ~ 1/10,000sec
*Specifications are subject to change without notice
PAL
EIR35-F4840_I-305
EIR35-F4860_I-306
