Copyright Notices
The information contained in the user's manual and all accompanyied
documentation are copyrighted and all rights are reserved. This publica-
tion may not in whole or in parts, be reproduced, transcribed, stored in a
retrieval system translated into any languages or transmitted in any form
without the prior written consent from the manufacturer, except for copies
retained by the purchasers for their personal archival purposes.
Trademarks
Award Modular BIOS is a registered trademark of Award Software Inc.
Microsoft and Windows 95/98/NT are registered trademarks of Microsoft
Corporation.
Intel Pentium, Pentium II, Pentium III, Celeron and Slot1 are registered
trademarks of Intel Corporation.
All other product names mentioned herein are used for identification pur-
poses only and may be the trademarks of their respective companies.
Technical Support
If you need technical assistance, our technical support engineers will be
glad to assist you with all technical difficulties, you can reach them by
dialing our toll-free service and technical support number : 1-877-DELTA-
2K/1-877-335-8225 (USA / CANADA Only ). Not only you will get to speak
with our experience technical support team, we also provide web-site
address (http://pc.delta.com.tw), product ,sales and RMA/warranty
information. Our skillful technical engineers will be available between 8:
00AM to 5:00PM, PST (Pacific Standard Time).
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M694X-MX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta Electronics M694X-MX Series

  • Page 1 Copyright Notices The information contained in the user’s manual and all accompanyied documentation are copyrighted and all rights are reserved. This publica- tion may not in whole or in parts, be reproduced, transcribed, stored in a retrieval system translated into any languages or transmitted in any form without the prior written consent from the manufacturer, except for copies retained by the purchasers for their personal archival purposes.

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction................3 Checklist................3 Hardware Specifications and Features........4 2. Hardware Installation.............6 Installation Steps..............6 Motherboard Layout Map............7 Pre-Installation Procedure............9 Install the Motherboard in a Case..........20 3. BIOS Setup Utility..............37 Standard CMOS Features............38 Advanced BIOS Features............42 Advanced Chipset Features..........47 Integrated Peripherals............50 Power Management Setup.............53 PnP / PCI Configurations............57 PC Health Status..............59...

  • Page 3: Introduction

    After unpacking, make sure that you have everything and that individual components are not damaged. If you find any component missing or damaged, contact your retailer immediately. M694X-MX series Motherboard User’s Manual Driver and Utility CD FDD Ribbon Cable Assembly...

  • Page 4: Hardware Specifications And Features

    Hardware Specifications and Features Chipset M694X-MX series motherboard consists of the VIA VT82C694X system controller into a single 510-Pin BGA package and VT82C686A PCI to ISA bridge into a single 324-Pin BGA package. SIS 900 10Base-T / 100Base-TX Ethernet onboard (Optional) Digital link sound with AC’97 Codec onboard...
  • Page 5 1. Introduction One mini DIN-6 PS/2 mouse port One mini DIN-6 PS/2 keyboard port One IR (Infrared) I/O compliant connector (Optional) One 10Base-T / 100Base-TX Ethernet RJ-45 port (Optional) One game / MIDI port Three audio jacks (Line-in, Line-out, Microphone) BIOS Support Award Plug and Play flash BIOS Soft power-down and Suspend-to-DRAM...

  • Page 6: Hardware Installation

    2. Hardware Installation This chapter provides information that you should be familiar with before in- stall the system. It describes how to install on a step-by-step guide and explains how to use your motherboard to build a powerful system. Installation Steps Before install your system.

  • Page 7: Motherboard Layout Map

    2. Hardware Installation Motherboard Layout Map Use the following illustration and key to identify the major components on the motherboard. Location Function K/B & MS (Upper) PS/2 Mouse port K/B & MS (Lower) PS/2 Keyboard port USB1 & LAN (Upper) RJ-45 Ethernet port (Optional) USB1 &...
  • Page 8 14 AMR1 One AMR (Audio Modem Riser) slot 15 J8 Infrared connector (Optional) 16 ISA1 One 8/16-bit ISA expansion slot 17 FSP1 Connectors for panel switches and indicators 18 JP2 Jumper to set clock ratio 19 PWR LED Power LED for monitoring power state 20 BZ1 Warning and judging the system state by buzzer 21 JP4...

  • Page 9: Pre-Installation Procedure

    2. Hardware Installation Pre-Installation Procedure Before you install your motherboard into a chassis, it’s convenient to install the CPU, install the memory modules, and set all the jumpers to correct settings. Jumpers Setting Explain This motherboard has jumpers that need to be set correctly. You can use a jumper cap to connect two adjacent pins.
  • Page 10 3-Pin jumper with 3-Pin jumper with a 3-Pin jumper with pins 2-3 SHORT single jumper cap pins 1-2 SHORT Locate the Jumpers on the Motherboard JP4: Clear CMOS Memory Jumper Use this jumper to clear the contents of the CMOS memory. The setup utility is stored in CMOS, so you might need to clear this memory if incorrect setup data is stopping your system from starting, or your system can not boot-up because you forgot password and the system BIOS has been updated.
  • Page 11 2. Hardware Installation J5: Wake-Up on LAN Connector This connector that used for remote wake up system through a network. If you have install a network adapter add-on card, you can cable the card to the J5 connector. If you enable the wake on LAN setting in the BIOS setup, incoming network traffic can resume the system from a power-saving mode or software power down.
  • Page 12 Replace only with the same or equivalent type, we recommend by the manufacturer or retailer. BZ1: Buzzer It is a 5 volts buzzer when system has any abnormally state or fatal error that you will hear a series of audible beep. J8: Infrared Connector (Optional) This connector supports the optional wireless transmitting and receiving infrared module.
  • Page 13 2. Hardware Installation SWDIP4: CPU FSB Setting This option settings the clock generator what frequency to send to the CPU, SDRAM, and VIA VT82C694X chipset. This allows the selection of the CPU’s FSB. Depending on your CPU type, select the appropriate SDRAM speed along with the CPU speed.
  • Page 14 JP1, 6, 7: CPU Type Setting Find the CPU manufacture then configure the jumpers according to the tables below. Setting CPU Type Intel SHORT Pins 1-2 OPEN Pins 1-2 OPEN Pins 1-2 VIA Cyrix SHORT Pins 2-3 SHORT Pins 1-2 SHORT Pins 1-2 JP8: VIA CyrixIII 133MHz FSB CPU setting The jumper settings the 133MHz FSB for VIA CyrixIII CPU only.
  • Page 15 2. Hardware Installation case adjacent to the slot you are going to use (keep the removed blanking plate for future use). Insert the cable assembly and drive a screw through the metal bracket on the edge of the cable assembly to secure it in place. Plug the connector of the cable assembly into the USB2 connector on the motherboard.
  • Page 16 Follow the procedure below to install the PGA370 type CPUs. On the motherboard, locate Pin-1 on the CPU is denoted by a small dot on one of the corners and Pin-1 on the PGA370 socket is denoted by an angled corner. Alignment Edge Then open the locking lever when the CPU is insert into the PGA370 socket.
  • Page 17 2. Hardware Installation Locate the cooling fan connector J9 on the motherboard. Plug the CPU’s cooling fan cable into the cooling fan connector on the motherboard. J9,10: CPU, Chassis FAN Connector This connector support cooling fan of 500mA (6W) or less. Orientate the fan so that the heatsink fins allow airflow to go across the onboard heatsink.
  • Page 18 When the system goes into sleep state, the fan should be shut down to eliminate audible noise and reduce power consumption. You can monitor the fan speed and the fan must come with a tachometer output. The CPU and / or motherboard will overheat if there is no airflow across the CPU and onboard heatsink.
  • Page 19 2. Hardware Installation Follow the procedure below to install the SDRAM memory module. On the motherboard, locate the DIMM socket. Open the plastic clips on both end of a desired DIMM socket. To install your SDRAM memory module, align your module up so that the pins fit into the socket.

  • Page 20: Install The Motherboard In A Case

    To remove your SDRAM simply pull the clips back, and pull up on the modules. Then place the SDRAM memory module in an anti-static bag as soon as you remove them to avoid static damage. Keep it in a location with little dust, low humidity environment.
  • Page 21 2. Hardware Installation motherboard onto the mounting brackets inside the case. The motherboard has six holes drilled through it, and you should be able to drive a screw through some of these holes into the mounting brackets in the case. Connecting Front Panel I/O This motherboard connectors to the front panel I/O are located an jumper block FSP1.
  • Page 22 power to the cabinet IDE devices or IDE activity LED. Read and write activity by devices connected to the Primary or Secondary IDE ports will cause the LED to light up. SPEAKER (Speaker, Pins 19, 21, 23, 25) : The connector connects to the case-mounted speaker.
  • Page 23 2. Hardware Installation Installing Add-on Card This motherboard has one AGP slot, two 32-bit PCI slots, one AMR slot and one 8/16-bit ISA slot The AGP (Accelerated Graphics Port) is a PCI-based interface which was designed specifically for demands of 3D graphics applications. The 32- bit AGP channel directly links the graphics controller to the main memory.
  • Page 24 Follow the procedure below to install the add-on card. Locate the expansions slots on the motherboard. Select which slot you plan to use according to the kind of add-on card you are going to install. In the system case, remove the blanking plate from the opening in the case adjacent to the slot you are going to use.
  • Page 25 2. Hardware Installation Install the IDE Devices The motherboard has two IDE channel connectors, the Primary IDE channel and the Secondary IDE channel. Each IDE channel can support two devices. IDE devices include hard disk drives, CD-ROM drives, and removable media drives such as ZIP drives and LS-120 drives.
  • Page 26 Follow the procedure below to install the IDE devices. Install the IDE device(s) into a suitable drive bay in your system case. Locate the Primary IDE channel connector on the motherboard. The connector is named IDE1(Blue). Plug one end connector (Blue) of the IDE ribbon cable into IDE1.
  • Page 27 2. Hardware Installation relationship. The MASTER device has priority over the SLAVE device (refer to illustration on the below). Secondary IDE2 Primary IDE1 Master Slave Master Slave Primary channel has priority over the Status 1 Secondary channel Master has priority Status 2 over the Slave devices Hard disk drives have...
  • Page 28 Assignment CD-L CD-L CD-R CD-R Install the FDD Drive The motherboard has FDD interface that will support one or two floppy disk drives. The floppy ribbon cable connector for two 3.5” wide disk drives. Follow the procedure below to install the FDD drives. Install the floppy disk drive into a suitable drive bay in your system case.
  • Page 29 2. Hardware Installation Connecting the Power Supply Most cases include a power supply unit, it requires an ATX power supply for system application. Follow the procedure below to connect the power supply. Locate the power connector ATX1 on the motherboard and devices Plug the main power supply cable from the power supply unit into the ATX1 connector on the motherboard.
  • Page 30 Connecting PS/2, USB, Serial, Parallel, LAN, VGA and Audio-MIDI Devices After you have installed the motherboard, make the connections to the external ports. The motherboard rear I/O panel provides external access to PS/2 style keyboard and mouse port, two USB ports, a parallel port, a RJ-45 port, two serial ports, a game/MIDI port and three audio jacks, which are integrated on the motherboard and PC99 compliant.
  • Page 31 2. Hardware Installation Network (LAN) through a network hub. USB1 & LAN (Black two 4-Pin USB Ports) is a versatile port which can function as a serial, parallel, mouse, keyboard or joystick device. It is fast enough to support video transfer, and is capable of supporting up to 127 daisy-chained peripheral devices.
  • Page 32 Activity LED (Green) Link LED (Yellow) Link LED (Yellow): The Link LED is located on the left part of the port. It is associated with the RJ-45 phone jack to indicate whether the twisted pair link connected. When there is no coming network data packet on the jack, the jack will start to detect periodical link-integrity pulses which should be sent by the device connected at the other end of the link, on the received pair of the twisted-pair cable.
  • Page 33 2. Hardware Installation should be blinking when the data packet being transmitted from the cable. Table shows status of the activity LED. Description State Data packet being transmitted Blink Power off No data package transmitted User’s Manual...
  • Page 34 Display unit Telephone line and Telephone set Joystick or Network system pad controller on LAN Printer with the Multiport hub parallel interface PS/2 Mouse Device with Headphone Tape player Microphone PS/2 Keyboard the serial or powered or audio interface speaker source device Device with the...
  • Page 35 2. Hardware Installation One display monitor One PS/2 mouse and one PS/2 keyboard Of course you can use the system I/O ports and expansion slots to add many more features and components to your system than the essential items listed above. Verify the state or the connection, you are done. Now ready to boot the system for the first time.
  • Page 36 POST Powering on the system starts POST and displays its check results. If the logo is displayed, press the <ESC> key. After a few seconds, the following message appears at bottom left on the screen. { Press DEL to enter SETUP } When the error message appears, the POST displays the result upon completion and the system waits for a key entry.

  • Page 37: Bios Setup Utility

    3. BIOS Setup Utility 3. BIOS Setup Utility This chapter describes how to configure the system with the BIOS Setup Utility. It also describes system parameters and which parameter to select for your particular needs. The motherboard provides a 2MB, 32-Pins DIP package FWB that can be updated using provided BIOS utility.

  • Page 38: Standard Cmos Features

    are also indicated at the bottom of the screen. Navigation Key(s) Function Description <F1> Displays the General Help screen from anywhere in the BIOS setup. <Esc> Jumps to the EXIT menu or returns to the main menu from a sub-menu or (Keypad arrow) Selects the menu item to the left or right or (Keypad arrow)
  • Page 39 3. BIOS Setup Utility record disk drive parameters and the video subsystem type, and select the type of errors that stop the BIOS POST. Date and Time Setting The BIOS determines the day of the week from the other date information. This field is for information only.
  • Page 40 mode of almost all IDE hard disk drives. When you select type auto for a hard disk drive, the BIOS detects its specifications during POST, every time the system boots. Here is a brief explanation of drive specification Access Mode : [Auto] [Normal] [Large] [LBA].
  • Page 41 3. BIOS Setup Utility ondary video subsystem, but you do not select it in setup. [EGA/VGA] : Enhanced Graphics Adapter / Video Graphics Array. For EGA, VGA, SVGA, or PGA monitor adapters. [CGA 40] : Color Graphics Adapter, power up in 40 column mode. [CGA 80] : Color Graphics Adapter, power up in 80 column mode.

  • Page 42: Advanced Bios Features

    [Base Memory] : Display the amount of conventional memory detected during boot up. [Extended Memory] : Display the amount of extended memory detected during boot up. [Total Memory] : Display the total memory available in the system. Advanced BIOS Features Selecting “Advanced BIOS Features”...
  • Page 43 3. BIOS Setup Utility When enabled, you receive warning message if a program attempts to write the boot sector or the partition table of the hard disk drive. You should then run an anti-virus programs. Keep in mind that this feature protects only the boot sector, not the entire hard disk drive.
  • Page 44 Quick Power On Self Test This will skip some diagnostic checks during the Power On Self Test (POST) to speed up the booting process. The available options for Quick Power On Self Test are : [Enabled] [Disabled]. First / Second / Third Boot Device These items to setting the priority and sequence the devices that your sys- tem will search for an operating device during bootup.
  • Page 45 3. BIOS Setup Utility Boot Up NumLock Status This item defines if the keyboard <NumLock> key is active when your sys- tem is bootup. The available options for Boot Up NumLock Status are : [On] [Off]. Typematic Rate Setting / Rate (Chars/Sec) / Delay (Msec) When Disabled, the two items (Typematic Rate and Typematic Delay) are irrelevant.
  • Page 46 Select For DRAM > 64MB This item is only required if you have installed more than 64MB of memory and running the OS/2 operating system. Otherwise, leave this item at the default [Non-OS2]. The available options for OS Select For DRAM > 64MB are : [Non-OS2] [OS2].

  • Page 47: Advanced Chipset Features

    3. BIOS Setup Utility [Enabled] Advanced Chipset Features Selecting “Advanced Chipset Features” on the main program screen display this menu : The screen allows you to configure the system based on the specific fea- tures of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache.
  • Page 48 8ns] [Normal] [Medium] [Fast] [Turbo]. SDRAM Cycle Length This field sets the CAS latency timing. The available options for SDRAM Cycle Length are : [3] [2]. DRAM Clock Allows you to set the memory clock speed to any [HCLK-33M], [HCLK+33M] or [Host CLK], depending on your memory speed.
  • Page 49 3. BIOS Setup Utility AGP-4X Mode Enables the 4X AGP mode for higher AGP throughput. A 4X AGP graphics is required to enable this function. The available options for AGP-4X Mode are : [Enabled] [Disabled]. AGP Driving Control / AGP Driving Value Allows you to adjust the AGP driving force.

  • Page 50: Integrated Peripherals

    Integrated Peripherals Selecting “Integrated Peripherals” on the main program screen display this menu : The screen allows you to configure the onboard device controllers. OnChip IDE Channel 0 / Channel 1 Primary / Secondary Master / Slave PIO Primary / Secondary Master / Slave UDMA OnChip IDE Channel 0 / Channel 1 This chipset contains a PCI IDE interface with support for two IDE channels.
  • Page 51 3. BIOS Setup Utility mode (0~4) for each of up to four IDE devices that the internal PCI IDE interface supports. Mode 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device. The available options for Primary / Secondary Master / Slave PIO are : [Auto] [Mode 0] [Mode 1] [Mode 2] [Mode 3] [Mode 4].
  • Page 52 The available options for Onboard FDD Controller are :[Enabled] [Disabled]. Onboard Serial Port 1 / Port 2 Select a address and corresponding interrupt for the first and second serial ports. The available options for Onboard Serial Port 1 / Port 2 are : [Auto] [3F8 / IRQ4] [2F8 / IRQ3] [3E8 / IRQ4] [2E8 / IRQ3] [Disabled].

  • Page 53: Power Management Setup

    3. BIOS Setup Utility Encoded) compression and decompression. The available option Onboard Parallel Mode are : [Normal] [EPP] [ECP] [ECP / EPP]. ECP Mode Use DMA allows you to select a DMA channel for the parallel port for use during ECP mode. The available options for ECP Mode Use DMA are [3] [1].
  • Page 54 The Power Management Setup option controls the power management functions. This motherboard supports ACPI (Advanced Configuration and Power management Interface). The system has various power saving modes that allows the system to be automatically resumed by certain events. ACPI Function This item allows you to Enabled or Disabled the ACPI ( Advanced Configura- tion and Power management Interface) function.
  • Page 55 3. BIOS Setup Utility Suspend Mode After the selected period of system inactivity (1 minute to 1 hour), all devices except the CPU shut off. ACPI Suspend Type This item allows you to set how your system suspends. [S1(POS)] : This suspend mode is equivalent to a software power down. [S3(STR)] : This motherboard features the suspend to RAM function.
  • Page 56 The available options for Video Off Option are : [Suspend Off] [All Modes Off] [Always On]. Video Off Method Deter mines the manner in which the monitor is blanked. The Blank Screen option will let the system BIOS blank the screen when disabling video.

  • Page 57: Pnp / Pci Configurations

    3. BIOS Setup Utility resumes from power failure. This design is inconvenient for a network serve or work station without an UPS, that need to keep power on. This item is used to solve this problem. [Auto] : If you select Auto, the system will power-on or power-off based on the original state.
  • Page 58 This section describes configuring the PCI bus system. PCI (Personal Com- puter Interconnect) is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself use when communicating with its own spe- cial components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 59: Pc Health Status

    3. BIOS Setup Utility The available options for PCI / VGA Palette Snoop are : [Disabled] [Enabled]. Assign IRQ For VGA Assign an IRQ number to your VGA adapter. The available options for Assign IRQ For VGA are : [Enabled] [Disabled]. Assign IRQ For USB Assign an IRQ number to the onboard USB port.
  • Page 60 menu : The Frequency Control allows you to set the CPU and system bus clock for your system, also system clock frequency will automatically be modulated which help reducing electromagnetic interference. Auto Detect DIMM / PCI Clk If you Enabled this item, the system does not generate clock signals for unused PCI or DIMM slots, so that EMI (ElectroMagnetic Interference) is reduced.

  • Page 61: Load Fail-Safe / Optimized Defaults

    3. BIOS Setup Utility The available options for Host CPU / PCI Clock are : [Auto] [95/31MHz] [100/ 33MHz] [103/34MHz] [112/37MHz]. If your CPU Bus Frequency is support to 133MHz. The available options for Host CPU / PCI Clock are : [Auto] [133/33MHz] [138/34MHz] [140/35MHz] [150/37MHz].

  • Page 62: Set Supervisor / User Password

    When you pressing “Y” key to load the default values that are factory setting for optimal performance system operations. Set Supervisor / User Password You can set either Supervisor or User Password, or both of them. The differ- ences between are: Supervisor Password : Can enter and change the options of the setup menus.

  • Page 63: Save & Exit Setup / Exit Without Saving

    3. BIOS Setup Utility disabled. Once the password is disabled, the system will boot and you can enter setup freely. When a password has been enabled, you will be prompted to enter it every time you try to enter setup. This prevents an unauthorized person from changing any part of your system configuration.
  • Page 64 Pressing <Y> key to stores the selections made in the menus in CMOS special section of memory that stays on after you turn your system off. The next time you boot your system, the BIOS configures your system according to the setup selections stored in CMOS. After saving the values the system is restarted again.

  • Page 65: Installing The Utilities

    4. Installing the Utilities 4. Installing the Utilities Once you have assembled your system, fine-tuned the Setup utility, and installed your computer with an operating system, you can begin installing the support software that ships with the system. The support software is supplied on a CD-ROM, it is assumed that the CD-ROM drive in your system is identified as drive D.

  • Page 66: Hardware Doctor Vhm2.02 For Win9X Installation

    Figure 2 HardWare Doctor VHM2.02 For Win9X Installation The system environment monitoring Utility with the onboard VIA VT82C686A system monitor chip allow you to monitor your system’s temperature, fan speed, CPU and system voltage. Using this Utility, you can setup the upper and lower limits of these monitored parameters.

  • Page 67: Four In One Driver For Win9X Installation

    4. Installing the Utilities When completed, you will be prompted to reboot. Click [Finsh] to com- plete the installation. The “HardWare Doctor VHM2.02” option will be added to the “Program” directory. Click “VIA HM” to access the program, the screen will appear Figure 5.

  • Page 68: Ide Driver For Nt40 Installation

    program will now guide you through the rest of the install process. When completed, the screen will appear Figure 8. you will be prompted to reboot, Click [Finish] to reboot and complete the installation. Figure 7 Figure 8 IDE Driver For NT40 Installation This folder provides bus mastering UltraDMA 66 drivers for IDE devices runing on Windows NT4.0 system.

  • Page 69: Audio Driver Installation

    4. Installing the Utilities Audio Driver Installation This folder let you select the drivers for the audio system that is integrated on this motherboard. Drivers are provided for Windows 95/98, NT4.0 and Win 2000. Click “Audio Driver” on the Figure 2, the screen will appear Figure 11. (Install the Audio driver from sub-folders for Windows 95/98, NT4.0 and Win 2000).

  • Page 70: Lan Driver Installation

    View device through the Device Manager under Windows 98. Click [Start] → → → → → Point to [Setting] → → → → → Click [Control Panel] to view pro- gram install state.. Double click [System] → → → → → Click [Device Manager] → → → → → Click “+” to the left of the [Display adapters], the screen will appear Figure 14.

  • Page 71: Bios Utility

    4. Installing the Utilities Figure 15 Figure 16 View device through the Device Manager under Windows 98. Click [Start] → → → → → Point to [Setting] → → → → → Click [Control Panel] view pro- gram install state. Double click [System] →...
  • Page 72 how you use this program. If you erase the current BIOS and fail to write a new BIOS, or write a new BIOS that is incorrect, your system will malfunction. The flash memory utility is called AWDFLASH.EXE. To use the utility, you must be in real-mode DOS (not the DOS box that is available in Windows 95/ 98/NT).
  • Page 73 4. Installing the Utilities off or reset your system. Once the system reboots, verify that the new BIOS version appear on the screen. User’s Manual...
  • Page 74 DECLARATION OF CONFORMITY This device is in conformance with Part 15 of the FCC Rules and Regulations for Informa- tion Technology Equipment. Operation of this Product is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 75 EN 50082-1 / 1997 : EN61000-4-2/-3/-8, EN 50204 (Identification of regulations / standards) This declaration is the responsibility of the manufacturer / importer DELTA ELECTRONICS, INC. 11F-3, 266, 2ND WEN-HWA ROAD., SEC. 1, LINKOU, TAIPEI HSIEN, TAIWAN, R.O.C. (Name / Address)
