SA-VK450GC / SA-VK450GS / SA-VK450GCS / SA-VK450GCT / SA
Self diagnosis and special mode setting (updates)
Please use this manual together with the service manual for Model No.
[SA-VK450GC/GS/GCS/GCT-S, Order No. MD0602030C3] and [SA-
VK450EE-S, Order No. MD0603053C3].
2006 Matsushita Electric Industrial Co. Ltd.. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Notes
- This supplement service manual is the updates for the self-diagnosis
and special mode setting section for Model No. SA-VK450GC/GS/GCS/
GCT-S on page 25~39, and SA-VK450EE-S on page 24~38.
2. Self diagnosis and special mode setting
ORDER NO. MD0605175S3
1
DVD Stereo System
-VK450EE
Colour
(S)... Silver Type
Advertisement
Table of Contents
Summary of Contents for Matsushita Electric SA-VK450GC
- Page 1 ORDER NO. MD0605175S3 DVD Stereo System SA-VK450GC / SA-VK450GS / SA-VK450GCS / SA-VK450GCT / SA -VK450EE Colour (S)... Silver Type Self diagnosis and special mode setting (updates) Please use this manual together with the service manual for Model No. [SA-VK450GC/GS/GCS/GCT-S, Order No. MD0602030C3] and [SA- VK450EE-S, Order No.
-
Page 2: Service Mode Summary Table
This unit is equipped with functions for checking and inspecting namely: Self-Diagnostic and Test Mode. 2.1. Service Mode Summary Table The service modes can be activated by pressing various button combination on the player and remote control unit. Below is the summary of major checking: Player buttons Remote control unit Application... - Page 3 Item FL Display Key Operation Mode Name Description Remote Control Key Error code Error code check. In STOP (no disc) mode, press check STOP button on the player, and The latest error code “0” button on the remote stored in the EEPROM IC Error code (play_err) is control unit.
- Page 4 Item FL Display Key Operation Mode Name Description Remote Control Key Jitter check Jitter check. In STOP (no disc) mode, press STOP button on the player, and Jitter rate is measured and “5” button on the remote displayed. control unit. Measurement is Press STOP or OPEN button repeatedly done in the...
- Page 5 Item FL Display Key Operation Mode Name Description Remote Control Key Initialization Initialization. In STOP (no disc) mode, press STOP button on the player, and User settings are cancelled and player is initialized to factory button on the setting. remote control unit. DVD Module To reset DVD Module.
-
Page 6: Dvd Self-Diagnostic Function Error Code
Item FL Display Key Operation Mode Name Description Remote Control Key ECC error ECC decode error display. In STOP (no disc) mode, press display STOP button on the player, and TOP MENU button on the remote control unit. Cancelled automatically 5 seconds later. - Page 7 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F010 DVD Media disk A specification value is size Press from the PARENTAL LOCK value of the appointed country. on main unit for next error. F020 DVD Media disk There is no TT_SRPT.
- Page 8 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F041 DVD Media disk The number of PGCI_SRP is 0. Press on main unit for next error. F042 DVD Media disk A specification value. It is size Press from the number of PGCI_SRP.
- Page 9 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F062 DVD Media disk A specification value inside of Press PGC. It is size from the number of PGes. on main unit for next error. F063 DVD Media disk Although C_POSIT exists, it is Press in PGC.
- Page 10 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F0E1 DVD Media disk DFD main microcomputer. Press Compatibility with a DFD type < download is impossible. on main unit for next error. F0E2 DVD Media disk DFD download start. PGC Press reproduction error.
- Page 11 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F4FF Force initialize Timeout when force Press failure (time out) initialization fails on main unit for next error. F500 DSC error DSC (IC8251) stops in the Press occurrence of servo error (startup, focus error, etc.) on main unit for next error.
- Page 12 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F601 Indeterminate Operation stopped caused by Press sector ID the request to access requested abnormal ID data on main unit for next error. F602 Access failure to LEAD IN data unreadable Press LEAD-IN caused by demodulation...
- Page 13 Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F701 Message Next message is sent before Press command does replying to disc manager not end on main unit for next error. F702 Message Message is changed before it Press command changes is sent as a reply to disc...
-
Page 14: Flash Rom
Error Diagnosis Description of error Automatic FL Display Remarks Code Contents F897 Initialize is not Initialize completion check for Press completed factory preset setting failure prevention on main unit for next error. F898 Disagreement of Unsuitable combination of AV Press hardware and DECORDER, SDRAM and software... -
Page 15: Special Mode Table
2.3. Special Mode Table 2... - Page 16 Item FL Display Key Operation Mode Name Description Front Key 1. Select Self - To enter into self Diagnostic diagnostic Mode checking for main ] for unit. DVD/CD mode. 2. Press and hold [ button for 3 seconds follow by To exit, press button on main unit or remote control.
- Page 17 Item FL Display Key Operation Mode Name Description Front Key Cold Start Initialize backup In doctor mode: 1. Press [4] on remote control. data and start. To exit, press [ENTER] button on remote control or button on main unit or remote control.
- Page 18 followed by “4” and “7” on remote control). - When entering into DOCTOR MODE, the firmware version and checksum of EEPROM (if applicable) will appear on FL display. Below is the information on the EEPROM IC (ROM correction) under 3 possible situations: 1.
- Page 19 Note: Microprocessor firmware refers to version number for microprocessor IC. It is subject to change which would be updated accordingly. ROM correction checksum refers to the HEX code that is displayed upon key buttons pressed if an EEPROM is loaded in the unit. 2.3.2.
-
Page 21: Error Code Table
2.3.3. Error Code Table Self-Diagnosis Function (refer Section 10.3) provides information on any problems occuring for the unit and its respective components by displaying the error codes. These error code such as U**, H** and F** are stored in memory and held unless it is cleared. The error code is automatically display after entering into self-diagnostic mode. - Page 22 Error Code Diagnosis Description of Automatic FL Display Remarks Contents error Mode SW, The tray is not For deck mechanism unit (For plunger and able to open. deck 1/2). capstan motor abnormal Press [ on main unit for next error. Rec INH SW (Spindle servo, For deck mechanism unit (For...
- Page 23 Error Code Diagnosis Description of Automatic FL Display Remarks Contents error ISTK Drive rack/gear The tray drive For CD/DVD changer unit assembly rack does not (CRS1D). abnormal move to “STOCK” Press [SINGLE CHANGE] on position. (Tray main unit for next error. does not move to “STOCK”...
- Page 24 Error Code Diagnosis Description of Automatic FL Display Remarks Contents error PDRV Cam gear/gear Cam gear does For CD/DVD changer unit assembly not move from (CRS1D). abnormal “HOME” to Press [SINGLE CHANGE] on “PLAY” drive main unit for next error. position.
- Page 25 Error Code Diagnosis Description of Automatic FL Display Remarks Contents error 1. All trays set to SRVC_TRV To unlock the For CD/DVD changer unit “STOCK” position traverse unit (CRS1D). 2. Mechanism set to tray for service Press [SINGLE CHANGE] on 3.
