Frigidaire GLEF378C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. GLEF378C
  6. Factory parts catalog
Frigidaire GLEF378C Factory Parts Catalog

Frigidaire GLEF378C Factory Parts Catalog

Electric range
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
GLEF378CBA
GLEF378C
GLEF378CQA
GLEF378C
GLEF378CSA
GLEF378C
SERVICE DATA SHEET - # 316218506
WIRING DIAGRAM - #316255178
OWNER'S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
Gallery
black
Gallery
bisque
Gallery
white
Publication No.
5995386330
030221
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
MARKET
North America
North America
North America
ELECTRIC
RANGE
Model No.
GLEF378C
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire GLEF378C

Summary of Contents for Frigidaire GLEF378C

  • Page 1 PRODUCT NO. BASE MODEL NO. GLEF378CBA GLEF378C GLEF378CQA GLEF378C GLEF378CSA GLEF378C SERVICE DATA SHEET - # 316218506 WIRING DIAGRAM - #316255178 OWNER’S GUIDE - # 316257105 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917...
  • Page 2 Publication No. GLEF378C 5995386330 BACKGUARD 02/03...
  • Page 3 A = GLEF378C (GLEF378CSA) B = GLEF378C (GLEF378CBA) C = GLEF378C (GLEF378CQA) POS. NO 13A# 20 # 24 # 24C# 24C# 24C# 54 # 54A# 54B# # = Fast-moving Parts * = Non-Illustrated Parts GLEF378C BACKGUARD PART NO DESCRIPTION 316239900...
  • Page 4 Publication No. GLEF378C 5995386330 BODY 02/03...
  • Page 5 A = GLEF378C (GLEF378CSA) B = GLEF378C (GLEF378CBA) C = GLEF378C (GLEF378CQA) POS. NO 12 # 18 # 37 # 62 # 66 # 67 # 89 # 108# # = Fast-moving Parts * = Non-Illustrated Parts GLEF378C BODY PART NO...
  • Page 6 Publication No. GLEF378C 5995386330 BODY 02/03...
  • Page 7 A = GLEF378C (GLEF378CSA) B = GLEF378C (GLEF378CBA) C = GLEF378C (GLEF378CQA) POS. NO 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts GLEF378C BODY PART NO DESCRIPTION 5303935180 A B C Anti-tip Kit,w/bracket,screw 316107200 A B C...
  • Page 8 Publication No. GLEF378C 5995386330 TOP/DRAWER 02/03...
  • Page 9 A = GLEF378C (GLEF378CSA) B = GLEF378C (GLEF378CBA) C = GLEF378C (GLEF378CQA) POS. NO 15 # 15A# 15B# 15C# # = Fast-moving Parts * = Non-Illustrated Parts GLEF378C TOP/DRAWER PART NO DESCRIPTION 316011503 A B C Drawer 316231500 A B C...
  • Page 10 Publication No. GLEF378C 5995386330 DOOR 02/03...
  • Page 11 A = GLEF378C (GLEF378CSA) B = GLEF378C (GLEF378CBA) C = GLEF378C (GLEF378CQA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLEF378C DOOR PART NO DESCRIPTION 5303935192 A - - Trim kit-door,3 sided ,white ,w/tape and foil 5303935191 - B -...

  • Page 12: Wiring Schematic

    Publication No. GLEF378C 5995386330 WIRING SCHEMATIC 02/03...

  • Page 13: Wiring Diagram

    GLEF378C Publication No. 5995386330 WIRING DIAGRAM # = Fast-moving Parts 02/03 * = Non-Illustrated Parts...
