Service Manual
Chassis MK
42 VLE 8500 B0
49 VLE 8500 B0
55 VLE 8500 B0
PAM000
PAL000
PAK000

Advertisement

loading
Need help?

Need help?

Do you have a question about the 49VLE8500-B0 and is the answer not in the manual?

Questions and answers

Astrid g
January 18, 2025

What is the Bluetooth versjon of the grundig. 49 Vle 8500 B0. I **** not able to pair it with Sony wh-h900n which has Bluetooth 4.1

Summary of Contents for Grundig 49VLE8500-B0

  • Page 1 Zusätzlich erforderliche Unterlagen für den Komplettservice Additionally required Service Documents for the Complete Service Service Manual Sicherheit Safety Materialnr./Part No. 720108000001 Materialnummer / Part Number 720100569500 Änderungen vorbehalten / Subject to alteration TCC 0616…0915 MP • Prepared in Germany http://www.grundig.com...
  • Page 2 GRUNDIG Service Chassis MK Es gelten die Vorschriften und Sicherheitshinweise The regulations and safety instructions shall be valid gemäß dem Service Manual "Sicherheit", Material- as provided by the "Safety" Service Manual, part nummer 720108000001, sowie zusätzlich die even- number 720108000001, as well as the respective tuell abweichenden, landesspezifischen Vorschriften! national deviations.
  • Page 3 Product Code Code" oder Ihre Display-Variante Chassis manual, please look for a current nicht aufgeführt sein, können version at the GRUNDIG service Sie eine aktualisierte Version auf portal "http://service.grundig.de". dem GRUNDIG Service-Portal Serialnummer / Before changing any board please "http://service.grundig.de"...
  • Page 4 GRUNDIG Service Chassis MK Servicehinweise Service Hints Abnehmen des BMS-Gehäusevorderteils (Backlight Modul System) Remove the BMS Front Cabinet (Backlight Modul System) – Lautsprecher abnehmen. – Remove the speakers. – Fig. 1/3: Schrauben herausdrehen. – Fig. 1/3: Undo screws – IR-LED-Baustein und Linse abnehmen.
  • Page 5 GRUNDIG Service Chassis MK Technische Daten / Technical Data 42 VLE 8500 B0 49 VLE 8500 B0 55 VLE 8500 B0 Order No. PAM000 PAL000 PAK000 Product Code Country SE; DK; FI; NO SE; DK; FI; NO NO; SE; FI; DK...
  • Page 6 GRUNDIG Service Chassis MK 42 VLE 8500 B0 49 VLE 8500 B0 55 VLE 8500 B0 DVB-C Front end Input frequency (MHz) Imput level / Impedance Demodulation / Symbol rate Ms/s DVB-S2 Front end Input frequency range Signal level Demodulation Input symbol rate DiseqC 1.2 support...
  • Page 7 Bedienhinweise Dieses Kapitel enthält Auszüge aus der Bedienungsanleitung. Weitergehende Informationen entnehmen Sie bitte der gerätespezifischen Bedienungsanleitung, die Sie unter www.grundig.de, Menüpunkt Downloads/Bedienungsanlei- tungen herunterladen können. ANSCHLIESSEN/VORBEREITEN AUF EINEN BLICK -------------------------------------------------------------- ------------------------------------------------------------------------------------------------------------- Die Fernbedienung – Hauptfunktionen Ein- und Ausschalten (Stand-by). Einschalten aus Stand-by.
  • Page 8 AUF EINEN BLICK MONITOR-BETRIEB ------------------------------------------------------------------------------------------------------------- -------------------------------------------------------------------------------------------------------- Die Navigation in den Menüs Die Bedienelemente des Internet TV Grundfunktionen Zoomfunktion • Mit dem Haupt- und den Untermenüs Ihres Internet TV können Mit dieser Funktion können Sie das Bild nach Wunsch vergrö- Netzschalter, schaltet das Internet TV in Ein- und Ausschalten Sie viele Funktionen wählen und alle notwendigen Einstellung ßern.
  • Page 9 TV. Voraussetzung dafür ist, Sie laden die kostenlose Applika- hier müssen alle notwendigen Einstellungen (»IP Ad- Abhängig vom Router verwenden Sie: tion »GRUNDIG TV Remote« vom Apple App Store oder vom – die Option „WPS-PBC“ (Push Button Configuration); resse«, »DNS«, »Netzmaske« und »Gateway«) von Hand Google Play (Android Market) und installieren diese auf Ihrem eingegeben werden.
  • Page 10 NETZWERK INSTALLATION NETZWERK INSTALLATION -------------------------------------------------------------------------------- -------------------------------------------------------------------------------- Hinweis: Das erste Zeichen/Ziffer des benötigten Kennworts mit Die Meldung mit » « (grün) bestätigen. < > » «, » «, » « und » « wählen und mit »OK« zur – Die Meldung »Verbindung mit Gateway: Erfolgreich« Λ...
  • Page 11 Sie sich registrieren. pLICATION store. Hinweis: Hinweis: Grundig ist nicht für den Inhalt und die Qualität des Inhal- Zum vorherigen „Reiter“ kann mit » « (rot) geschaltet Wurde das Kennwort vergessen » « (gelb) drücken. tes der Applikationen verantwortlich. Dies unterliegt der werden.
  • Page 12 Menüs. » « wählen. Internet TV installieren können. Während der Wiedergabe das vorherige/nächste Im Menü »GRUNDIG appLICATION Store« sind ab Werk ei- Thema mit » « oder » « wählen. nige Applikationen installiert. Bildinhalt anwählen oder Schreibmarke (Cursor) in der Im GRUNDIG Online Store finden Sie eine große Auswahl...
  • Page 13 Sie können auf Videos, Musik oder Fotos von z.B. einem Nur Video-Dateiformate mit einem DLNA Zertifikat PC, Smartphone oder NAS (Network Attached Storage) grundig. (»MPEG_PS_NTSC«, »MPEG_PS_PAL«, »MPEG_TS_ zugreifen, die kompatibel zum DLNA-Standard sind und SD_EU« und »MPEG_TS_EU_ ISO«) werden unterstützt.
  • Page 14 USB-BETRIEB USB-BETRIEB ------------------------------------------------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------------------------------------------- Dateiformate Bilddaten Wiedergabe – Grundfunktionen Ihr Internet TV gibt Bilder in den Formaten JPEG, PNG und Ihr Internet TV kann folgende Dateiformate verarbeiten, die Menü mit »MENU« aufrufen. BMP wieder. über die USB-Buchsen zugeführt werden. > <...
  • Page 15 LIVESHARE-BETRIEB KOMFORTFUNKTIONEN ---------------------------------------------------------------------- ------------------------------------------------------------------------------------------------------- Menüs sperren Fernseh-Programme sperren Mit dieser Funktion können Sie folgende Menüs Sie können einzelne Fernseh-Programme mit des Fernsehgerätes sperren: »Automatischer einem persönlichen PIN-Code sperren, zum Suchlauf«, »Manuelle Abstimmung« und »Pro- Beispiel Programme, die sich nicht für Kinder grammtabelle«.
  • Page 16 Operating Hints This chapter contains excerpts from the operating instructions. For further particulars please refer to the appropriate user instructions which can be downloaded by www.grundig.com, submenu Downloads/Manuals. CONNECTION/PREPARATION OVERVIEW ---------------------------------------------------------------- ------------------------------------------------------------------------------------------------------------------------------------ Remote control - main functions Turns on and off the Internet TV set (stand-by).
  • Page 17 OVERVIEW MONITOR OPERATION ------------------------------------------------------------------------------------------------------------------------------------ ----------------------------------------------------------------------------------------- Navigation in the menus Control buttons on the Internet TV Basic functions Zoom function The main menu and submenus for your Internet TV enable you ON • OFF – Power switch, switches the Internet TV into With this function, you can enlarge the picture on the Internet Switching on and off to select many functions and carry out all required settings.
  • Page 18 Automatic connection, All data regarding connection settings (»IP Address«, Automatic connection, Grundig Application Store is a depot where you can find »Netmask«, »Gateway« and »DNS«) are obtained from all data regarding connection settings (»IP Address«, various applications that you may use on your Grundig modem automatically.
  • Page 19 NETWORK SETUP NETWORK SETUP ------------------------------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------------------------- To continue after pressing the WPS button on the access Press » « (green) to check the performed settings and Confirm the password with » « (green). point, press » « (green). also if the local network and internet connection has –...
  • Page 20 Application Store, you can find many applications that you Enter your »Name« and »Surname«: have provided during Grundig Application Store registration may use on your Grundig Internet TV. You can download < Select the letters for the information with »...
  • Page 21 «, » «, » «, » « allows sliding of the navigation You can download a wide array or applications from Grundig Λ keys in the applications and virtual keyboard. Application Store. Press »OK« to confirm the selections in virtual keyboard Press »@«...
  • Page 22 DMS device. devices with DMC feature. Video files played through DMS device support following Notes: grundig. formats that have obtained DLNA certificate: »MPEG_ You can share your video, music and image files through PS_NTSC«, »MPEG_PS_PAL«, »MPEG_TS_SD_EU« and devices such as PC, mobile phone or NAS (Network »MPEG_TS_EU_ISO«.
  • Page 23 USB OPERATION USB OPERATION --------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------- File formats The file browser Playback basic functions Your Internet TV can be operated via the USB input with the The file browser displays the video, audio and picture data Open the menu with »MENU«. following file formats: that the external data medium provides.
  • Page 24 WIRELESS SCREEN SHARE (LIVESHARE) CONVENIENCE FUNCTIONS ------------------------------------------------------------ -------------------------------- Note – Parental control: Changing the PIN code Activate (On) or deactivate (Off) the panel Note: Instead of the PIN Code 2356, you can enter a lock with » < « or » >...
  • Page 25 GRUNDIG Service Chassis MK Service- und Sonderfunktionen Service and Special Functions Tastenfunktionen Functions of the buttons Aufrufen/Beenden des Menüs / Beenden des Service Modes Call up/exit the Menu / exit the Service Mode MENU MENU Menü-Zeile (Menüpunkt) wählen Call up the dialogue line (point of menu)
  • Page 26 GRUNDIG Service Chassis MK 2. Software-Versionsnummer 2. Software Version Number Die Software-Versionsnummer wird unten im Menü Einstellungen The software version number is shown on the lower part of the opti- und im Service Menü angezeigt. z.B.: KYGRMR.-.-.-.-.V07.034.00 ons menu and the service menu. e.g.: KYGRMR.-.-.-.-.V07.034.00...
  • Page 27 GRUNDIG Service Chassis MK Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Chassisplatte / Chassis Board VKT190R-6 Bestückungsseite / Component Side Lötseite / Solder Side POS. POS. POS. POS. POS. POS. POS. POS. C100 C209 T 137 C700...
  • Page 28 GRUNDIG Service Chassis MK POS. POS. POS. POS. POS. POS. POS. POS. R307 R612 T 204 R804 R1122 T 224 RP904 T TP40 B 226 TP130 TP226 B 100 R308 R613 B 203 R805 B 239 R1123 T 206 RP905 T...
  • Page 29 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Bestückungsseite / View of Component Side TRANSPORT LINE LVDS S1114 LVDS S1700 S102 BL-PWM R1314 FID2 C107 S1102 C175 C176 T101 T102 D101 R110 R1317 R1402 L107 R116 R1318 C127 SW1500 R122 R523 L113 R119...
  • Page 30 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Bestückungsseite / View of Component Side TRANSPO LVDS S1114 LVDS S1700 S102 BL-PWM R1314 FID2 C107 S1102 C175 C176 T101 D101 T102 R110 R1317 R1402 R116 R1318 C127 R122 R523 R119 R533 T100 C128 IC105...
  • Page 31 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Bestückungsseite / View of Component Side TRANSPORT LINE TRANSP LVDS S1114 LVDS S1700 S102 BL-PWM R1314 FID2 C107 S1102 C175 C176 T101 D101 T102 R110 R1317 L107 R1402 R116 R1318 C127 SW1500 R122 L113 R523...
  • Page 32 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Lötseite / View of Solder Side IC1400 TP139 TP141 TP137 R336 R169 TP238 TP190 TP195 TP19 R1203 TP17 TP263 TP261 TP202 R652 R324 TP52 TP214 TP136 RP1200 C1400 TP204 TP259 TP216 TP154 TP24 TP26 TP250...
  • Page 33 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Lötseite / View of Solder Side IC1400 TP139 TP141 TP137 R336 R169 TP238 TP238 TP190 TP195 TP19 TP17 TP263 R1203 TP202 TP261 TP52 TP261 R324 R652 R324 TP214 TP136 C1400 TP204 RP1200 TP259 TP216 TP259...
  • Page 34 Chassisplatte / Chassis Board VTY190R-6 Ansicht von der Lötseite / View of Solder Side IC1400 TP139 TP141 TP137 R336 R169 TP238 TP190 TP195 TP19 TP17 TP263 TP202 TP261 TP52 R324 TP214 TP136 C1400 TP204 TP259 TP216 TP154 TP24 TP26 TP250 TP181 TP254 TP257...
  • Page 35 Chassisplatte – Blockschaltplan / Chassis Board – Block Circuit Diagram POWER_SW +5V2_ST IC1001 ENABLE SINGLE 19V PSU OPTION VCC3V3-ST VCC3V3 Tuner +5V2_19V DC/DC +5V2_ST DC/DC IC107 VCC1V17 Analog IC100 IC113 DVB-T/T2/C CI 1 CI 2 POWER_SW POWER_SW ENABLE L102 DC/DC VCC1.18V 3.3V_FE IC104...
  • Page 36 Chassisplatte – Netzteil / Chassis Board – Power Supply R100 R101 R102 Imax=2900mA T100B IC100 66.5K PANEL-VCC +5V2_ST TPS54335DRCR C100 L129 L101 +5V2_ST BC847BPDW1T1 100nF TP254 BOOT L100 Power 3D_EN TP255 3D_EN VSENSE +5V2_19V T101 C120 6.3UH C101 C102 C131 COMP C119 R103...
  • Page 37 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – HDMI XC8107 Reverse Current Prevention Current Sense UVLO Control Current Lim. 4ms Delay 7.5ms Delay ON/OFF Control each Thermal Shutdown circuit V ss HDMIB-5V D800 S802 HDMIB-5V HDMIB_HPDIN HDMIB_HPDIN IC800 CH1-...
  • Page 38 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – SCART, SPDIF C713 SCART_SOG SCART R714 33R C714 R715 0R SCART_RIN- SCART_RIN- Full SCART SC_CVBS-IN SCART_RIN+ SCART_RIN+ S702 SCART_GIN- SCART_GIN- R716 47nF TP221 C715 47nF CVBS- SCART_GIN+ 75R %1 SCART_GIN+ TP222...
  • Page 39 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – USB XC8107 Reverse Current Prevention Current Sense UVLO Control Current Lim. 4ms Delay 7.5ms Delay ON/OFF Control each Thermal Shutdown circuit V ss IC1400 XC8107AC10MR-GW D1400 TP137 V_BUS5 +5V_USB VOUT C1401...
  • Page 40 Chassisplatte / Chassis Board – DVB-S VKT190R-2 XTALO_S2 XTALO_S2 C1100 C1101 C1102 C1110 16 17 100nF 22pF TUNER_3V3_MA 100nF I2CS C1105 C1106 TUNER_3V3_MA R1102 I2CS_SCL SAT_3V3_MA I2CS_SCL 100nF 47pF I2CS_SDA TUNER_3V3_MA I2CS_SDA I2CS L1100 130mA TP107 VCC3V3 C1108 100nF 100R C1104 C1107 IC1100...
  • Page 41 Chassisplatte / Chassis Board – DVB-S VKT190R-6 XTALO_S2 XTALO_S2 BBIP 16 17 C1127 100nF BBIN L1820 XC8107 C1110 TP251 Reverse Current Prevention VCC3V3-ST IC1805 C1132 100nF BBQN 3.3V_FE I2CS XC8107AC10MR-GW R1102 BBQP 100nF I2CS_SCL Current Sense I2CS_SCL SAT_3V3_MA I2CS_SDA I2CS_SDA I2CS VOUT UVLO...
  • Page 42 Chassisplatte / Chassis Board – Multi-Tuner VKT190R-2 TAINP DVB-T2 Demodulator TUNER TAINM DVB-S2 Terrestrial TIFAGC TSCLK Demodulator Cable VGA control CXD2832 TSSYNC IOUTP 14 VREF18 RFAIN DVB-T RF Level IQ Mixer TSVALID Monitor Demodulator XC8107 Reverse Current Prevention TSDATA[7:0] IOUTN RFIN SIAIN DVB-C...
  • Page 43 Chassisplatte / Chassis Board – PCMCIA-Interface TS2-D0 TS_SAT2 TS_SAT2_D0 *IC601 bypass resistors TS BY-PASS BLOCK *IC602 bypass resistors TS MUX BLOCK TS2-D0 TS_SAT2_D0 IC600 VCC3V3 TS2-D1 TS_SAT2_D1 R645 TS2-D1 TS_SAT2_D1 TS2X-CLK TS2_CLK TS_CI2_D0 R604 NC/0R TS0X-D0 TSP_SELECT TSP_SELECT TS2-D2 TS_SAT2_D2 TS2-D2 TS_SAT2_D2 TS_CI2_D1...
  • Page 44 Chassisplatte / Chassis Board – Scaler-SOC / LAN IC200 MSD8361MVK IC200 MSD8361MVK HDMIC HDMIA-RX0_N HDMIC-RX0_N PCM-D0 PCM-IRQA AVDD5V_HDMIC RXA0N RXC0N PCM_D[0] PCM_IRQA_N HDMIA-RX0_N HDMIC-RX0_N PCM-D0 AVDD5V_HDMIC HDMIA-RX0_P HDMIC-RX0_P PCM-D1 AF10 PCM-OE MHL_CABLE_DET HDMIA-RX0_P RXA0P RXC0P HDMIC-RX0_P PCM-D1 PCM_D1] PCM_OE_N MHL_CABLE_DET HDMIA-RX1_N HDMIC-RX1_N PCM-D2...
  • Page 45 Chassisplatte / Chassis Board – Scaler-SOC IC200 MSD8361MVK IC200 MSD8361MVK VGACONN SCART VGA.VGA_RIN- SCART_RIN- RIN0M RIN2M VGA_RIN- SCART_RIN- LVDSA VGA.VGA_RIN+ SCART_RIN+ 3D_SYNC_S8_O LVA0_N LVA0_N RP300 47R*4 A0_N VGA_RIN+ RIN0P RIN2P SCART_RIN+ 3D_SYNC_S8_O PWM0 LVB0P A0_N LVA0_P LVA0_P VGA.VGA_GIN- SCART_GIN- PWM1 A0_P VGA_GIN- GIN0M...
  • Page 46 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – Scaler-SOC IC200 MSD8361MVK IC200 MSD8361MVK VDDC_CPU VDDC_CPU AVDD_ADC33 AVDD3P3_ADC STANDBY 3.3V POWER VDDC_CPU L400 VDDC_CPU VDDC_CPU AVDD_NODIE AVDD_NODIE VDDC_CPU AVDD_NODIE VDDC_CPU AVDD_DVI33 C400 VDDC_CPU AVDD_DVI33 AVDD3P3_DVI 100NF VDDC_CPU AVDD_USB33 L401 VDDC_CPU...
  • Page 47 Chassisplatte / Chassis Board – RAM AVDD_DDR A-TMBA1 R500 4*0R A-MBA1 A-TMDQL0 R501 4*0R A-MDQL0 IC200 MSD8361MVK A-TMA12 A-MA12 A-TMDQL2 A-MDQL2 A-TMA4 A-MA4 A-TMDQL6 A-MDQL6 IC500 A-TMA0 AD17 C-TMA0 A-TMA6 A-MA6 A-TMDQL4 A-MDQL4 A_DDR3_A[0] B_DDR3_A[0] A-TMA1 AD22 C-TMA1 K4B4G1646D A_DDR3_A[1] B_DDR3_A[1] AA25 AC16...
  • Page 48 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – FRC NORMAL 3.3V POWER AVDD_LVDSRX CORE POWER DVDD DDR POWER AVDDIO_CMD0 VCC3V3 VCC1.18V VCC1.8V L1702 TP153 TP151 TP152 C1706 C1708 C1702 C1704 C1703 C1705 C1707 C1701 L1700 R L1701 R FRC_VDDP...
  • Page 49 GRUNDIG Service Chassis MK Chassisplatte / Chassis Board – LVDS R1309 NC FOR UHD VESA VCC3V3 BRI_ADJ R1318 BRI_ADJ R1312 I2C-SCL I2C-SCL I2C-SDA I2C-SDA 47R*4 S1302 TP13 S1114 TP14 R1302 4.7K VCC3V3 3D_FORMAT0 R1316 3D_SYNC_PANEL_O TP15 3D_SYNC_PANEL_O S1300 3D_FORMAT1 VESA 4.7K...
  • Page 50 Chassisplatte – Verstärker / Chassis Board – Amplifier C902 330pF 50V C900 4.7nF C901 RP900 C905 R900 NC/100R C903 470R 47NF 2.2n 33nF 50V L900 C909 C907 C906 4.7nF NR 6045T 220M 100nF C908 C910 220nF R901 330p C911 C912 470R Power on (trigger: +5V2_ST) 47NF...
  • Page 51 Netzteil / Power Supply DPS-126BP A / DPS-136BP A Ansicht von der Bestückungsseite / View of Component Side...
  • Page 52 Netzteil / Power Supply DPS-126BP A / DPS-136BP A Ansicht von der Lötseite / View of Solder Side...
  • Page 53 Netzteil / Power Supply DPS-126BP A / DPS-136BP A J102 C801A Q907 NTC1 L801 FB801A D801 +19V_OVP R807 J101 IC801 R816 R817 R818 R809 R801 C381 D382 R833A R831D D803 R805 +19V_OVP_GND D240 T601 R600 R612 R613 R614 D600 IC601 Q600 R605 R602...
  • Page 54 Netzteil / Power Supply DPS-126BP A / DPS-136BP A L750 D751 FB751 C757 Power Table RefDes +19V SGND D752 IC780 R750 R793 IC780 R752B C787 R785 R784 Q759 IC751 IC750 R758 R756 R760 R766 R757 R759 C763 C776 C781 R796A R795A...
  • Page 55 Docking-Platte / Board ZJE195-01 Ansicht von der Bestückungsseite / View of Component Side S100 S101 S102 CON2+2 CON2+2 CON2+2 Docking-Platte / Board ZJB195-01 Ansicht von der Bestückungsseite / View of Component Side S102 S104 S101 CON2+2 CON2+2 S103 S105 S105 S106 S107 S103...
  • Page 56 Docking-Platte / Board ZJD195-01 Ansicht von der Bestückungsseite / View of Component Side Docking-Platte / Board ZJG195-01 Ansicht von der Bestückungsseite / View of Component Side Docking-Platte / Board ZJD195-01 Docking-Platte / Board ZJG195-01 S100 S101 S102 S103 S108 S101 S102 S103 S105...
  • Page 57 Sie eine aktualisierte Version auf dem for a current version at the service portal finden Sie eine aktualisierte Version auf dem for a current version at the service portal Service-Portal "http://service.grundig.de". "http://service.grundig.de". Service-Portal "http://service.grundig.de". "http://service.grundig.de". 001.000 759551812500 GEH.- VORDERTEIL SCHWARZ...
  • Page 58 If your "Product Code" or display variant is not oder Ihre Display-Variante nicht aufgeführt sein, mentioned in the spare parts list, please look finden Sie eine aktualisierte Version auf dem for a current version at the service portal Service-Portal "http://service.grundig.de". "http://service.grundig.de". 001.000 759551800500 GEH.- VORDERTEIL SCHWARZ FRONT CABINET BLACK 002.000...
  • Page 59 GRUNDIG Service GRUNDIG Service Chassis MK Chassis SU Ersatzteilliste / Spare Parts List 10 / 2015 CHASSISMODUL / CHASSIS BOARD MK Pos. Part Number Description 759551832600 DIO-SMD ESD PRTR5V0U2X SOT143B D804 759551832600 DIO-SMD ESD PRTR5V0U2X SOT143B D809 F900 759551778400 FUSE-SMD 5A 63V 0603 FAST ACT...
