Summary of Contents for Wizard ON-SP03
- Page 1 Smart 2-in-1 Hand Sanitizer Dispenser...
-
Page 2: Product Introduction
Product Introduction This product measures the human body temperature by collecting infrared thermal radiation from the human body, and then give voice alert whether the body temperature is normal or abnormal. After the test is completed, the outlet will dispense hand sanitizer to sterilize the hands when putting the hands near the outlet. -
Page 3: Product Features
Product Features • Using high-precision infrared sensors, stable and reliable performance. • Automatic body temperature detection with automatic washing-free hands sanitizer integrated, which makes disinfection more convenient. • Strong environmental temperature adaptability, could be used normally in complex environments. • Large-size digital display, which is clear and soft. -
Page 4: Product Description
Product Description Micro USB Power Temperature Display Interface Power Switch IR Temperature Sensor +Key IR Sensor Set Key -Key Measurement Indicator Speaker Hand Sanitizer Capacity Indicator Strip Sanitizer Vending Indicator Sanitizer Vending Outlet... - Page 5 Battery Cover Base/Tripod Fixing Hole Base Sanitizer Container Cover Base/Tripod Fixing Screw Upper Column Tightening Screw Lower Column Tightening Screw Tripod Base Tightening Screw...
- Page 6 Operating Instruction Instructions Open the battery cover on the back of the product. Install 4 AA batteries or connect the 5V power adapter to the micro USB port. Turn the power switch On. When the forehead or wrist is 1~5cm away from the infrared sensor, the product will automatically detect the body temperature and report the results by voice.
- Page 7 There are two power supply modes for this product, which supported by 4 AA batteries or 5V DC power supply. Switch the power button to ON, the power light is on, and the display will show 000. When the forehead or wrist is 1~5CM away from the infrared sensor of the product, the product will automatically detect the body temperature, the result will be showed on the display and also reported by...
- Page 8 Precautions This product is not a medical product and the measured body temperature is for reference only. If there is any temperature abnormality indication, please consult a doctor in time. Please read the User Manual before using this product and operate it according to the technical parameters. Clean the infrared sensor immediately if hand sanitizer or anything is blocking off it, to make sure the liquid output normally.
-
Page 9: Installation Methods
Installation Methods Tripod Installation Loosen the upper and lower fastening screws of the tripod first. Loosen the fastening screws on the tripod support feet. Pull out the tripod center column, and open the support feet. Fix the product base on the tripod and lock it with a special nut. -
Page 10: Wall Mounting
Wall Mounting Fix the wall bracket on the wall with screws. Then fix the base to the wall bracket with screws. Install the product to the bracket after the battery and hands sanitizer are loaded. - Page 11 Product Fectures Product Material: ABS + PC Power: ≤3W Power Supply: DC5V 2.1A/4 AA Batteries (Batteries not included) Detection Method: Infrared Detection Time: ≤2sec Detection Distance: 1~5cm Filling Bottle Capacity: 300ml Sanitizer Type: Rinse-Free Hand Sanitizer Gel or Common Hand Sanitizer Dispensing Method: Infrared Working Environment: 10°C~35°C(50°F~95°F), RH<85% Storage Environment: -20°C~55°C (-4°F~131°F), RH<85%...
-
Page 12: Packing List
Packing List SI.NO Name Device 1.6m Tripod (Optional) 2m Charging Cable 5V/2.1A Charger 300ml Bottle Wall mount Metal Bracket Sealing Ring Base Bracket wing nut Ф6 (Optional) Bracket butterfly nut grip plateOuter diameter 12mm hole diameter 6mm (Optional) Solid wall plugs Ф6 Wall mount metal y304 stainless steel self-tapping screws cross countersunk head screw Ф4*25...
