Summary of Contents for Pro DVX SD Series

  • Page 1 User Manual SD-Series...
  • Page 2: Table Of Contents

    Content Important Notices........................3 Features ............................ 4 Package Contents: ........................4 Drawing (14” – 15.6”) ......................5 Drawing (18.5” – 21.5”) ......................7 Remote Control........................9 Getting Started ........................10 Main Menu ..........................11 Viewing Your Photos ......................12 Listening To Your Music ...................... 12 Viewing Your Videos ......................
  • Page 3: Important Notices

    Important Notices 1. Please keep the device away from excess temperature (50 degrees C above), too cold (-10 degrees C below) or wet places. 2. Do not grievous hit the device or place something heavy on it. 3. Only use the accessories specified by the manufacturer. 4.
  • Page 4: Features

    Features ❖ Full HD Screen, LED Backlight ❖ High Resolution ❖ Width viewing angle ❖ Compatible with SD/MMC Card ❖ HDMI input ❖ AV input ❖ USB Host 2.0 ❖ 3.5mm earphone ❖ Support: MPEG2, MPEG4, H.264, RM, RMVB, MPG, MOV, AVI, MKV, TS, M2TS et. Video Format Support up to 1920 x 1080.
  • Page 5: Drawing (14" - 15.6")

    Drawing (14” – 15.6”) Serial number Function Remote receiver SD/MCC card slot Earphone AV Input USB2.0 HDMI Input DC In...
  • Page 6 Serial number Function Power Right Menu/Play/Enter/Pause Down Exit Left Speaker Keyholes for Wall-Mounting VESA 100 Stand Kensington Lock...
  • Page 7: Drawing (18.5" - 21.5")

    Drawing (18.5” – 21.5”) Serial number Function Remote receiver SD/MCC card slot Earphone AV Input USB2.0 HDMI Input DC In...
  • Page 8 Serial number Function Power Right Menu/Play/Enter/Pause Down Exit Left Speaker Keyholes for Wall-Mounting VESA 100 Kensington Lock Stand...
  • Page 9: Remote Control

    Remote Control Zoom EXIT Mute Exit Zoom setup Rotate Volume Up ON/OFF ON/OFF Volume Down Rotate INFO INFO Left Mode Right MODE ENTER Movie/Music/Photo Select/Execute Source Down SOURCE DMP/HMDI/AV Play/Pause Note: 1. Please remove the plastic tab between the Remote control battery door and the battery. 2.
  • Page 10: Getting Started

    Getting Started 1. To set up your digital photo frame, you first need to attach the stand 2. Place the frame horizontally on a flat surface 3. Insert the power lead into the digital photo frame’s socket marked dc. 4. Turn on the digital photo frame by either pressing the power button on the back of the unit or pressing the power button on the remote control.
  • Page 11: Main Menu

    Main Menu After turning on the unit, this screen will appear: The memory device (USB/SD) you have inserted, you can use the [ ] [ ] buttons on your remote control to choose the function you want, then press ok to select the menu item.
  • Page 12: Viewing Your Photos

    Viewing Your Photos Select the photo icon form the main menu and then press ENTER, us the [ ] [ ] buttons to select the memory device and the press ENTER, you will now have access to your photos in thumbnail view.
  • Page 13: Viewing Your Videos

    Viewing Your Videos Select the video icon form the main menu and then press ENTER, us the [ ] [ ] buttons to select the memory device and then press ENTER, your video files will now be shown on the screen. You can navigate through your videos using the [ ] [ ] [ ] [ ] buttons.
  • Page 14: Feature Setup

    Feature Setup Select the ‘setup’ icon from the main menu, to adjust settings on your digital photo frame. Alternatively, just press the ‘setup’ button on the remote control. From here, you will see the various options: ] Button: Move through items or choose parameters. ] Button: Change the parameters.

This manual is also suitable for:

Sd-10Sd-14Sd-15Sd-18Sd-22
