OBSBOT Tiny User Manual page 3

Gimbal
OBSBOT Tiny is equipped with a 2-axis gimbal. The controllable
rotation range for the pan is ±150°, and for the tilt is ±45°.
Privacy Mode
Point the lens straight down. When the indicator light turns yellow
which means the privacy mode is on.
⚠ The product cuts off both the video and audio in the privacy
mode.
Upside Down Mode
OBSBOT Tiny supports using with upside down mode. It can be
mounted upside down, then the screen will rotate automatically
for use.
Gesture Control
OBSBOT Tiny has the first of the kind implementation of gesture
control in AI webcam, empowering users to access a series of
functions such as select/cancel tracking target, zoom in/out with
natural simple gestures. No need to press the button or interrupt
your flow.
First of all, please put your hand nearby your face and keep your
fingers splay out when you making gestures, and then the camera
indicator light will turn blue. The three blue lights flash one by one
and then all of them flash once together means your gesture is
recognized successfully.
⚠ Please go to the link below to find the tutorial video for gesture
control: https://obsbot.com/obsbot-tiny/explore
Select/Cancel Target
�
2x Zoom in/out
Zoom
OBSBOT Tiny supports 2x digital zoom.
① Gesture Control
By default, the zoom settings is 2x. Users can create customized
zoom settings from 1x to 2x via OBSBOT TinyCam.
② Manual Control
Users can do the manual control for zoom settings from 1x to 2x
via OBSBOT TinyCam.
Indicator Statuses
Camera Indicator
The camera indicator is made up of four colors: red, yellow, blue
and green. Different combinations of light colors and flicker
frequencies represent different indications. They can show the
current working status to the users.
All three blue lights flash in a cycle which
means the product is being initialized.
The three blue lights flash one by one and then all
of them flash once together means your gesture is
recognized successfully.
The middle of the green light keeps on which
means no target was locked.
All three green lights keep on which means the
target was locked.
All three yellow lights keep on which means
losing target.
The middle of the yellow light keeps on which
means Tiny is in privacy mode.
During the upgrade, blue lights and yellow lights
flash alternatively.
All three red lights flash slowly which means
upgrade failed.
�
