Thank you for purchasing Crystal Audio PRT speakers
PRT speakers are innovative portable, battery powered, speakers equipped with TWS & Bluetooth wireless streaming capabilities.
Small and portable yet powerful, they produce an unexpectedly deep and clear bass for their dimension.
TECHNICAL SPECIFICATIONS:
PRT-8
Woofer:
8inch, Long Throw
Sensitivity:
96dB@2,83V/1m
Twitter:
1inch, Soft Dome
Sensitivity:
98dB@2,83V/1m
Battery:
9V / 3x 2200mAh (25Whr)
Power Supply:
30W
Pow. Sup. Voltage:
15V
Pow. Sup. Current:
2A
REAR PANEL
Playback Inputs
Connect a USB flash drive
or a SD/micro SD card
Microphone In
Connect a wired
Microphone (optional)
AUX In
Connect an external
sound source
12V DC Input
Connect
an external battery
LED Light Switch
Turn LED light on/off
Power Switch
Switch the unit on/off
TRUE WIRELESS STEREO
PORTABLE SPEAKERS
- Quick Guide -
PRT-12
12inch, Long Throw
102dB@2,83V/1m
1inch, Soft Dome
100dB@2,83V/1m
12V / 4500mAh (54Whr)
45W
15V
3A
CONNECTIVITY FEAUTURES:
• Bluetooth® v4.2
• USB port
• SD/microSD slot
• AUX In
• Microphone In
• Guitar/Keyboards In
• 12V DC External Battery In
LCD screen
Control buttons
Control the speaker
from the options on
the rear panel
Echo Effect
Only for Microphone
MIC Priority
Press to override
the music and give
sound priority to
the microphone
Control Switches
Adjust the Master, Guitar
and Mic volume levels as
well as the Bass, Treble
and Echo settings
Advertisement
Related Manuals for Crystal Acoustics PRT-8
Summary of Contents for Crystal Acoustics PRT-8
- Page 1 PRT speakers are innovative portable, battery powered, speakers equipped with TWS & Bluetooth wireless streaming capabilities. Small and portable yet powerful, they produce an unexpectedly deep and clear bass for their dimension. TECHNICAL SPECIFICATIONS: CONNECTIVITY FEAUTURES: PRT-8 PRT-12 Woofer: 8inch, Long Throw 12inch, Long Throw •...
- Page 2 Control the unit Control PRT speakers by the unit’s rear panel keys. 6 Pair it (Bluetooth®) You can pair PRT speakers with any Bluetooth enabled device (phone/tablet). 3. The speaker starts by default in Bluetooth mode. 1. Enable Bluetooth mode in your phone or tablet. The Bluetooth indication (bLUE) will be shown on the screen of the back panel.
- Page 3 Select Modes Note: Every time you turn on the speaker it starts by default in Bluetooth mode. Bluetooth Use the Mode selector on the unit, to cycle In case you are requested to enter a PIN between the various available inputs/modes: code, please enter 0000.
- Page 4 Before using the unit for the first time charge the battery for about 8hrs (PRT-8) & 10hrs (PRT-12). The unit’s playback time is up to 8hrs (PRT-8) & 12hrs (PRT-12) depending on the volume level and use of additional features, e.g. LED light, of the speaker.
