PRODUCT NO.
BASE MODEL NO.
FGFL66ASB
FGFL66A
SERVICE DATA SHEET - # 316259139
WIRING DIAGRAM - # 316255205
OWNER'S GUIDE - # 316257503
INSTALLATION INSTRUCTIONS -# 316259304
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
white
North America
Publication No.
5995358115
010824
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
GAS
RANGE
Model No.
FGFL66A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FGFL66A
Summary of Contents for Frigidaire FGFL66A
- Page 1 PRODUCT NO. BASE MODEL NO. FGFL66ASB FGFL66A SERVICE DATA SHEET - # 316259139 WIRING DIAGRAM - # 316255205 OWNER’S GUIDE - # 316257503 INSTALLATION INSTRUCTIONS -# 316259304 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 COLOR MARKET...
- Page 2 Publication No. FGFL66ASB 5995358115 BACKGUARD 08/01...
- Page 3 POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts FGFL66ASB BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316248900 Spacer,shield ,rear wall 316051600 Shield,backguard ,inner 316235100 Shield,top ,inner 316220202 Support,backguard ,white ,RH 316220203 Support,backguard ,white ,LH 316232647 Panel,backguard ,white 316222900...
- Page 4 Publication No. FGFL66ASB 5995358115 BURNER 08/01...
- Page 5 POS. NO 2C # 10 # 10C# 11 # 11B# 11C# 13 # 14 # 16 # 17 # 18 # 19 # 22 # 23 # 24 # 26 # # = Fast-moving Parts * = Non-Illustrated Parts FGFL66ASB BURNER PART NO DESCRIPTION...
- Page 6 Publication No. FGFL66ASB 5995358115 BODY 08/01...
- Page 7 POS. NO 12 # 14 # 18 # 37 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGFL66ASB BODY PART NO DESCRIPTION 316029416 Panel,main back 3131314 Shield,oven top 316230102 Panel,bodyside ,white ,RH 316230103 Panel,bodyside ,white ,LH 316201402 Burner Box 316129200...
- Page 8 Publication No. FGFL66ASB 5995358115 TOP/DRAWER 08/01...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGFL66ASB TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231400 Liner,drawer 316231205 Panel,drawer ,white 3051163 Glide,drawer ,rear 316202332 Main Top,white 316202401 Grate,gray 316213601 Cap,12K burner ,gray 316213501 Cap,9.5K burner ,gray 316099500 Pin,guide ,(2) 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome 316021110...
- Page 10 Publication No. FGFL66ASB 5995358115 DOOR 08/01...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGFL66ASB DOOR PART NO DESCRIPTION 5303935192 Trim kit-door,3 sided ,white ,w/tape and foil 5303935201 Glass,door kit ,white ,outer ,w/ foil tape 316237000 Glass,oven door ,heat barrier 316222707 Shield,wool ,oven door 316236700 Insulation,oven door 316237100...
-
Page 12: Wiring Diagram
Publication No. FGFL66ASB 5995358115 WIRING DIAGRAM 08/01...
