Use the Quick Installation Guide when using the camera for the first time. This guide
contains the basic instructions you will need to know in order to be able to use this
camera.
Layout of the instruction manual
Inserting the batteries and an explanation of the functions
Normal camera operation
Other functions and operation
Installation and using the software
Use with a Macintosh
Troubleshooting
1
Introduction
This instruction manual is for users of the TRUST 950 POWERC@M ZOOM. The
TRUST 950 POWERC@M ZOOM can be used to take photographs, to record live
video images or as a webcam for videoconferencing on the Internet.
The applications supplied with the camera have a wide range of options for editing
photographs and video clips. When the Trust 950 POWERC@M ZOOM is connected
to your computer, it can be accessed directly as a removable disk. You can then
open the photographs and video clips, edit them, send them via e-mail, save them on
your computer, etc.
The camera also works with Mac OS 8.9~9.1 and Mac OS 10.1 or later releases as a
mass storage device.
1.1
General comments regarding photography
Test photograph
Before you start photographing a unique event, it is a good idea to first take a
number of test photographs. This will help to ensure that the camera works as
required.
No compensation for unsuccessful photographs
No compensation may be claimed for unsuccessful photographs as a result of a
faulty camera, faulty software, etc.
Exchanging photographs and video clips
No guarantees are given that photographs and video clips produced with this camera
can be displayed on other devices or that photographs and video clips produced with
other devices can be displayed using this camera.
Sunlight
Do not aim the camera directly at the sun for a long period of time. This may damage
the sensor.
Shaking/knocks
Do not shake the camera or knock it against anything, because this may cause a
fault, unsuccessful photographs, memory incompatibility or the loss of photographs
from the memory.
LCD screen
There may sometimes be small black or clear dots visible on the LCD screen. This is
normal and does not affect the photographs. There is no reason to exchange the
camera if there are 10 dots or less.
Exposing the LCD screen to direct sunlight for a long period of time may cause faults.
TRUST 950 POWERC@M ZOOM
U K
Chapter
(4, 5)
(6 to 8)
(9 to 15)
(16, 17)
(18)
(19)
1
Advertisement
Table of Contents
Related Manuals for Trust 950
Summary of Contents for Trust 950
- Page 1 Troubleshooting (19) Introduction This instruction manual is for users of the TRUST 950 POWERC@M ZOOM. The TRUST 950 POWERC@M ZOOM can be used to take photographs, to record live video images or as a webcam for videoconferencing on the Internet.
-
Page 2: General Information
General information Carefully read the following instructions before use. • The Trust 950 PowerC@m Zoom does not require any special maintenance. Use a slightly damp, soft cloth to clean the camera. • Do not use aggressive substances, such as white spirit, to clean the device. -
Page 3: Inserting The Batteries
Standard AA NiCd batteries are unsuitable for use with this device. Note: You can also use rechargeable AA NiMH batteries (minimum 1800 mAh) with the Trust 950 PowerC@m Zoom. Note: The batteries will not be recharged when the camera is connected to a USB port on your computer. - Page 4 TRUST 950 POWERC@M ZOOM Item Name Description macro mode. : Macro mode: for close-up photographs (distance of 23 to 27 cm). : Normal mode: for photographs of surroundings or people (distance of 120 cm to infinity). See chapter 11.2. Digital...
- Page 5 TRUST 950 POWERC@M ZOOM Item Name Description Battery cover The batteries and the MMC/SD slot are located behind this cover. Table 2: Functions at the rear of the camera Explanation of the status icons on the LCD screen See table 3 for a description of the various status icons shown on the camera’s LCD screen (1, figure 3).
-
Page 6: Standard Camera Operation
TRUST 950 POWERC@M ZOOM Item Function Description the stand and the automatic exposure function or use the flash. Table 3: Reading the LCD screen STANDARD CAMERA OPERATION The following chapters explain how to take photographs, how to view photographs on the camera and how to save photographs on a computer. - Page 7 Select 'Run' from the Windows Start menu. b Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software Installer. The Trust Software Installer will appear (see figure 6). Select the language (in the top right-hand corner) you wish to use for the installation.
-
Page 8: Multi-Select Button
TRUST 950 POWERC@M ZOOM Open the ‘Removable Disk’. Open the ‘DCIM’ folder. Open the ‘100FSCAM’ folder. Double-click on a file to open and/or edit it. Windows XP A window will appear automatically which gives you various options. Select ‘Using folder to view files’ (see figure 7). -
Page 9: Indicator Status
TRUST 950 POWERC@M ZOOM Note: You cannot alter anything in the menu when the LCD screen is turned off. Playback mode - Press the ‘Disp’ button (2, figure 3) to hide the details. - Press the ‘Disp’ button again to display the details again. - Page 10 TRUST 950 POWERC@M ZOOM Description IMAGE Resolution 2976 x 2232 6.6 Mpix. resolution. 2048 x 1536 * 3.1 Mpix. resolution. 1600 x 1200 2.0 Mpix. resolution. 1280 x 960 1.3 Mpix. resolution. Quality Fine * Fine quality. Normal Normal quality.
-
Page 11: Taking A Photograph
The quality of the image is reduced when using the digital zoom. 11.2 Using the macro mode (close-up photographs) The Trust 950 PowerC@m Zoom has a macro mode which can be used to take photographs at a minimum distance of 20 cm. Selecting the macro mode: Slide the macro button (7, figure 2) upwards or downwards (see Table 7 for an explanation). -
Page 12: Setting The Flash
TRUST 950 POWERC@M ZOOM 11.3 Setting the flash The camera has various flash options. Selecting the flash: Set the camera to the ‘Capture’ mode. Press the flash button (9, figure 3). Repeat this until the correct flash setting has been reached (see Table 8). - Page 13 TRUST 950 POWERC@M ZOOM Option Option Explanation Resolution 2976 x 2232 Resolution settings (see chapter 11.4.1). 2048 x 1536 1600 x 1200 1280 x 960 Compression/ Fine Compression settings quality (see 11.4.2). Normal White balance Auto White balance settings (see 11.4.3).
- Page 14 TRUST 950 POWERC@M ZOOM Resolution 2972 x 2232 2048 x 1536 1600 x 1200 1280 x 960 Quality Fine Normal Table 10: Number of photographs that can be saved in the camera’s internal memory 11.4.3 White balance Under normal circumstances, the white balance is set automatically. You can select the white balance manually for conditions which do not change or for certain lighting conditions.
-
Page 15: Recording A Video Clip
Recording a video clip ( ) The Trust 950 PowerC@m Zoom can also be used to record short video clips at 15 frames per second and with a resolution of 320 x 240. The video clip will be saved in AVI format. - Page 16 TRUST 950 POWERC@M ZOOM Item Options Description Delete Delete One Delete one photograph or video clip, or delete all Delete All the photographs and Exit video clips. DPOF Select All/None Option for printing photographs via a printer Select One (DPOF).
- Page 17 TRUST 950 POWERC@M ZOOM Select the number of copies you wish to print by pressing the control button to the left/right (right increase the number of copies, left decrease the number of copies). Press ‘Enter’ to confirm the selection. If the memory card is inserted into a printer with a card reader, it is possible to print the selected photographs directly.
-
Page 18: Inserting/Removing A Memory Card
Select ‘PAL’ or ‘NTSC’. Press ‘Enter’ to confirm the selection. Inserting/removing a memory card The Trust 950 PowerC@m Zoom has a 16 MB internal memory. By default, photographs and video clips are saved in the internal memory. This memory can be extended with an SD (Secure Digital) or an MMC (Multi Media Card) memory card. - Page 19 TRUST 950 POWERC@M ZOOM Using the camera as a webcam (PC) Note: This function does not work on an Apple Macintosh computer. This camera can also be used as a webcam. It can then be used to record live moving images on a computer.
-
Page 20: Software (Installation And Use)
The conditions can be found at www.trustphotosite.com. 16.1 Installing the Trust Photo Upload software This software can be used to upload your photographs to the Trust Photo Site. Note: The latest version of the Trust Photo Upload software can be downloaded from the Trust website. - Page 21 TRUST 950 POWERC@M ZOOM 16.2.2 Using the Trust Photo Upload software Start Trust Photo Upload from the Windows Start menu (Start – Programs – Trust – Trust Photo Upload). Use the ‘Explorer’ to select the photographs you wish to upload. You can use the buttons on the right-hand side of the Explorer to select photographs, unselect photographs, view photographs, edit photographs, etc.
- Page 22 TRUST 950 POWERC@M ZOOM 17.1.1 PhotoBase 3.0 PhotoBase is a management program which you can use to organize and present your multimedia files. Carry out the following to make an album. Open PhotoBase via the Windows Start menu (Start – Programs – ArcSoft –...
- Page 23 TRUST 950 POWERC@M ZOOM After using the standard editing options, click on the ‘Edit’ button (B, figure 10) to use the advanced editing options. The menu at the bottom of the window (F, figure 10) will change. You will now...
- Page 24 TRUST 950 POWERC@M ZOOM See the program’s Help function for more information by clicking on the question mark in the top right-hand corner of the window. 17.1.4 FunHouse 1.0 ArcSoft FunHouse allows you to easily make amusing photographs by combining two or more photographs.
-
Page 25: Troubleshooting
Carry out the following to remove the driver from your computer. Open the Control Panel (Start – Settings – Control Panel). Double-click on the ‘Add/Remove Programs’ icon. Select ‘Trust 950 PowerC@m Zoom’. Click on ‘Change/Remove’. Follow the on-screen instructions until the options ‘Modify’, ‘Repair’ and ‘Remove’ are displayed. - Page 26 TRUST 950 POWERC@M ZOOM Digicam USB Port Driver – 950 PowerC@m Zoom Mass Storage Class Adapter (Windows 98) Storage Device – USB Disk (Windows ME) Storage volumes – Generic Volume (Windows XP, 2000) Universal Serial Bus Controllers – Trust 950 PowerC@m Zoom (Windows XP, 2000, 98, ME) ‘Start –...
- Page 27 TRUST 950 POWERC@M ZOOM Problem Cause Possible solution The Trust 950 The camera has been Connect the camera to a USB hub PowerC@m Zoom connected to a USB which has a power supply or to a is marked with an hub which does not USB port on your computer.
- Page 28 TRUST 950 POWERC@M ZOOM Problem Cause Possible solution The camera is still Wait until the photograph has busy saving the been saved in the memory. previous photograph. There is no The camera has been Reconnect the cables. connection with the connected incorrectly.
- Page 29 TRUST 950 POWERC@M ZOOM Problem Cause Possible solution No more recordings The camera’s memory Download the recordings onto are made. is full. your computer and then delete them from the camera’s memory. The problem is not Check the Internet for Click on listed here.
-
Page 30: Technical Specifications
TRUST 950 POWERC@M ZOOM Technical specifications Camera resolution 2976 x 2232 / 6.6 Megapixel Hardware sensor resolution 2048 x 1536 / 3.1 Megapixel Internal memory 16 MB flash memory (storage) External memory Built-in SD/MMC slot (maximum: 512 MB) Digital still camera... -
Page 31: Warranty Conditions
TRUST 950 POWERC@M ZOOM Warranty conditions - Our products have a two-year manufacturer's warranty which is effective from the date of purchase. - If there is a fault, return the product to your dealer. Include an explanation of the fault, the proof of purchase and all the accessories.
