ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FGFL79DBB FGFL79DQB FGFL79DSB
Series
30" f/s gas
Color
black
Market
North America North America North America
Wiring Diagram
316417808
Owner's Guide
316417102
Installation Instructions 316259336
Service Data Sheet
316417603
Publication No.
5995427076
05/01/19
(EN/SERVICE/BJH)
369
30" f/s gas
30" f/s gas
bisque
white
316417808
316417808
316417102
316417102
316259336
316259336
316417603
316417603
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGFL79D / FGFB55A
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGFB55A
Summary of Contents for Frigidaire FGFB55A
- Page 1 North America North America North America 316417808 316417808 316417808 316417102 316417102 316417102 316259336 316259336 316417603 316417603 316417603 30-INCH FREE- STANDING GAS RANGE Model No. FGFL79D / FGFB55A Publication No. 5995427076 05/01/19 (EN/SERVICE/BJH) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995427076 FGFL79D / FGFB55A BACKGUARD 01/05...
- Page 3 316416201 316040201 316230701 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A BACKGUARD A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A B C Shield, backguard, rear wall A B C Shield, backguard, inner...
- Page 4 Publication No: 5995427076 FGFL79D / FGFB55A BURNER 01/05...
- Page 5 316237902 GRLP2 316248105 316253700 316001003 316215600 5303271648 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A BURNER A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A B C Pipe, manifold A B C Valve, 14K burner, w/mtg screw...
- Page 6 Publication No: 5995427076 FGFL79D / FGFB55A BODY 01/05...
- Page 7 316407000 316418901 316401200 316232700 89 # 316415400 316401100 316401000 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A BODY A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A B C Back, main A B C Shield, oven top...
- Page 8 Publication No: 5995427076 FGFL79D / FGFB55A BODY 01/05...
- Page 9 5303305324 316021105 316021108 316021110 316021132 316089500 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A BODY A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A B C Bracket, motor mtg. A B C Cover, fan A B C...
- Page 10 Publication No: 5995427076 FGFL79D / FGFB55A TOP/DRAWER 01/05...
- Page 11 316213500 316213503 316213501 316099500 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A TOP/DRAWER A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A B C Drawer, utility A B C Liner, drawer A - -...
- Page 12 Publication No: 5995427076 FGFL79D / FGFB55A DOOR 01/05...
- Page 13 316405102 316405100 316021110 316433603 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A DOOR A FGFL79D (FGFL79DBB) B FGFL79D (FGFL79DQB) C FGFL79D (FGFL79DSB) DESCRIPTION A - - Trim, oven door, black - B - Trim, oven door, bisque...
-
Page 14: Wiring Schematic
Publication No: 5995427076 FGFL79D / FGFB55A WIRING SCHEMATIC 01/05... -
Page 15: Wiring Diagram
# Functional Parts * Non-Illustrated Parts FGFL79D / FGFB55A WIRING DIAGRAM Publication No: 5995427076 01/05...
