Model SH-2012AH-QG
Cutting Machine
User's Manual
PDF 文件使用 "pdfFactory Pro" 试用版本创建
(V5.0-1.0)
CNC
Contents
Functional Overview
Main Menu
AUTO
MAN
EDIT
Command System
SETUP
LIBMINIT
DIAGNOSE
I/O Interface
Appendix
1. Pin definitions of height controller
2. SH-2012AH-QG Software
Upgrading Instructions
3. Installation Dimensional Diagrams
4. Troubleshooting
5. Wiring Instructions of Extended
Manual Control Box
www.fineprint.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SH-2012AH-QG and is the answer not in the manual?

Questions and answers

Summary of Contents for Start Shaphon SH-2012AH-QG

  • Page 1 Cutting Machine LIBMINIT DIAGNOSE I/O Interface User's Manual Appendix 1. Pin definitions of height controller 2. SH-2012AH-QG Software Upgrading Instructions 3. Installation Dimensional Diagrams 4. Troubleshooting 5. Wiring Instructions of Extended Manual Control Box PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 2 1. After the container is unpacked, please check the system for any damage and verify if the contents in the container are physically in conformance with the packing list. 2. This user's manual is applicable to Model SH-2012AH-QG CNC System for Cuttingmanufactured by Microstep Control Technology Co., Ltd.
  • Page 3 18. The system power must be cut off when alternating the internal keyboard and an extended keyboard. 19. Special Statement： The quality warranty of this product is twelve months since its manufacturing date SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 4 Society causes such as war, strike, government prohibition, etc. C：Damage caused by unauthorized actions such as disassembly, modification, repair, etc. 20. The final power of interpretation to this user's manual is subject to Beijing Start Microstep Control Technology Co., Ltd. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 5: Table Of Contents

    北京斯达微步控制技术有限公司 Beijing Start M&E Technology Development Co.,Ltd. Contents Chapter I. Functional Overview......................1 1.1. System Functions ..............................1 1.2Technical specifications ............................1 1.3Microstep also supplies the following auxiliary products for compact CNC cutting machine......3 Chapter II. Main Menu ........................5 2.1. Menu Features ..............................5 2.2.
  • Page 6 Appendix I: The Wiring Diagram and Pin Definitions for Model SH-HC30 Height Controller Manufactured by Microstep......................50 Appendix II: Instructions for Software Upgrading Operation of SH-2012AH .......52 Appendix III: Installation Dimensional Drawing................54 Appendix IV: Troubleshooting......................55 Appendix V: Wiring Instructions for Extended External Manual Control Box......58 SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 7: Chapter I. Functional Overview

    Beijing Start M&E Technology Development Co., Ltd. Chapter I. Functional Overview 1.1. System Functions Model SH-2012AH-QG CNC System for Cuttingis designed to work with torch/plasma, high-pressure water jet and laser cutting machines and extensively used in metal working, advertisement fabrication and stone machining businesses.
  • Page 8 Memory space: 32M-64M oversized memory capacity for user program and no restriction to machining program l Machine case size: 298×202×95.2(mm) l Operation temperature: 0 to +40 ; storage temperature: ℃ -40 to +60 ℃ SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 9: Microstep Also Supplies The Following Auxiliary Products For Compact Cnc Cutting Machine

    1.3Microstep also supplies the following auxiliary products for compact CNC cutting machine. SH-GDC3 分压板 Model SH-GDC3 Divider Board 等离子电源 Power Supply Unit for Plasma SH-HC30 火焰/等离子割炬高度控制器 Model SH-HC30 Height Controller for Flame/plasma Cutting Torch SH-2012AH 切割机数控系统 Model SH-2012AH CNC Cutting Machine SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 À www.fineprint.com.cn...
  • Page 10 北京斯达微步控制技术有限公司 Beijing Start M&E Technology Development Co., Ltd. 23HS3002 型步进电机 Model 23HS3002 Step Motor SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 À www.fineprint.com.cn...

  • Page 11: Chapter Ii. Main Menu

    [G] [G] [3]Initial Setting: A dialog box as follows will appear: File format: to format user' s program space; Parameter: To restore the factory parameter setting; ENGLISH: Alternating between Chinese and English Fig. 2.2 Initial setting dialog SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 12: Chapter Iii. Automatic Function(Auto)

    Kerf Active speed Heavy-current Functio n keys Input/output Coordinate Work mode Machini Machining program paramete Plasma Mode Flame mode Fig. 3.1 Automatic Function (AUTO) Window 3.1. Description of Automatic Mode Window SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 13 [PIERCE] heavy-current control key To carry out a piercing process, the specific operation procedure is as follows: Flame machining case: rise the cutting torch(M72), open the cutting oxygen(M12) and lower the cutting torch(M73). SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 14: Function Selection In Auto Mode

    [S] key is used to magnify the pattern, one times by one keystroke and eight times maximum by three keystrokes. [Q] key is used to return the pattern to original size. The display position of pattern is moveable by pressing [↑], [↓], [←] and/or [→] key. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 15 It is possible to select X Mirror, Y Mirror and No Mirror if press [F5] key continually. When X Mirror is selected, the machining program will run along the symmetry direction of X-axis, as appears inverted SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建...

  • Page 16: Startup Of Speed Mode(Multiplying Factor) And Automatic Mode

    After the system operation is paused, it is allowed to perform the following operations: (a) Return along the original path; (b)adjust position; (c)exit machining operation; (d) [START]: restore system operation; and (e)Press [ESC] key to exit the machining program and return to automatic mode window. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 17 After piercing, the cutting torch returns from the current position to the adjustment beginning point along a straight line at cutting speed and continue machining along the original path without stop, which is somewhat like extended pierced, making the piercing point more smooth. ； 3) HOLE HERE(piercing here) SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 18: Original Path Return

    The program segment for return allows 300 rows maximum. In case of breakpoint restoration(RESBREK) or machining section selection(SECTION), the return beginning row is the row containing the current breakpoint or the section selecting row, upon which however the cutting torch is not allowed to return along SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 19 北京斯达微步控制技术有限公司 Beijing Start M&E Technology Development Co., Ltd. the original path for machining. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 20: Breakpoint Restoration Process

    SECTION: to assign system to start up machining operation from any section or piercing point. Press [F1] to select SECTION function and the system will show a menu as shown in the figure below: SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建...

  • Page 21: Move Hole For Thick Plate

    1 in the parameter control menu, thus to enables the option. In this way, whenever it is time for piercing operation, the system will prompt an option menu as shown below: SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 22 2） Press [START] key at the end of preheat. The cutting torch will reach the piercing point along a straight line at selected cutting speed and then go on machining. 3.8.3NO HOLE Instead of piercing, the system moves through the current piercing position to next, and new piercing prompt appears. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 23: Chapter Iv. Man(Manual Mode)

    Fig.4.1 Manual mode window 4.1. Description of Manual Mode Window The window display in manual mode is the same as it in automatic mode except that the multiplying factor is manually SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 24 It is allowed to adjust the speed quickly by pressing [F] key in this window. A pull-down menu will appear with 8 speed multiplying factors available for selection with [↑] and/or [↓] key: 5%, 20%, 30%, 40%, 50%, 60%, 80% and 100%. And then, press RETURN key to acknowledge the selection. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 25: Chapter V. Edit Mode

    Notes: 1）The program name and extension name should never exceed 12 characters. 2）For large-sized program above 200K, it is allowed to work along with USB disk instead of saving 5.1.4. 【F4】DELE SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 26 [F1] Input: to transmit program from USB disk to the machining program space. [F2] output: to output the machining program to USB disk from the machining program space. 5.1.7. 【F7】SEARCH STRING This feature is not provided yet. It is reserved for subsequent upgrading. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 27: Chapter Vi. Command System

    T command haver higher priority than G command. 6.2. Coordinate System This CNC system uses standard rectangular coordinate system, as shown in the figure below. Fig. Rectangular coordinate system 6.3. G: Basic Preparatory Commands SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 28 ＋Ｘ maximum speed limit multiplied by multiplying factor. G00 movement is subject to speed multiplying factor. Current Torch Position Format: G00 X[U]n Y[V]n ＋120 Expected Torch Position G00 PPn SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 29 G03. See the figure below for the setting of directions. Format：G02[03] X[U]n Y[V]n In Jn [Fn] or G02[03] X[U]n Y[V]n Rn [Fn] G02[03]PPn In Kn [Fn] or G02[03] PPn Rn [Fn] SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 30 Return to the reference point along Y axis. Return to the reference point simultaneously along both X and Y axes. Exemple: G28(simultaneously return to reference point, equivalent to execute G00 command) SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 31 - Level 1 loop ends. N008 G28 N009 M02 10）G40/G41/G42: Cutter Radius Compensation Commands Format: G41（or G42）Rn Program segment to be compensated. Notes: leftwards G41 is to compensate a half diameter of flame along the machining SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 32 Since cutter compensation is made automatically, there must be G00 Quick Move command before G41 or G42 commands so as to assure the position of cutting torch is corrected. Behind G40 the end mark of cutter compensation, a G00 command is necessary to adjust the position back. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 33: M Auxiliary Commands

    5． Switch on height controller(M38) and run the subsequent program. M08: fixed loop of cutting stop The operation sequence of M08 in flame cutting operation is as follows: 1.Close the cutting oxygen valve(M13). 2.Turn off the height controller(M39). SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 34 (refer to input port 8 XXW)(M17). Turn on the torch lifting switch(M14). After count the time delay of torch positioning(refer to 7.4 for plasma parameter), the lifting torch will stop(M15). M80: Master switch SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 35: Chapter Vii. Setup(Parameter Setting)

    Flame/plasma mode selection, machining speed limit, MOVE HOLE option, metric/English selection, etc. Height controller Arc voltage raising option, fine tuning of control speed, sensitivity of height controller, arc voltage height control, etc. Save SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 36: Setup(Parameter Setting)

    Circular corner transitional option ----- If this option is enabled(value:1), the system will not decelerate through a circular transition when the running direction change of system between program segments is within the conversion angle of corner speed, as shown in the figure below. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 37 = 8/1. Electronic Gear Ratio = Pitch of Screw Rod × 1000(360 × Subdivision Number / Stepping Angle × Drive Ratio) The computation method(adjustment method) of electronic gear is as follows: SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 38: Flame Cutting Parameters

    Preheating delay——It is the preheating time for piercing operation in second. If the preheating time is insufficient, it will be prolonged to 150 seconds automatically by pressing [PAUSE] key. If preheating is done in the midway, press [START] key to abort the time delay. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ...

  • Page 39: Plasma Parameters Setting

    If this distance option is enabled, the system will automatically disable the arc voltage and the height control in such a distance from the endpoint , in mm. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建...

  • Page 40: Control Parameters Setting

    X-axis width of steel plate ---- The actual width of steel plate along X axis, which is enabled only in running extra large program. Y-axis height of steel plate ---- The actual height of steel plate along Y axis, which is enabled only in running extra large program. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 41: Control Parameters Setting Of Height Controller

    Positioning height B ---- The height to raise the cutting torch when the torch hits steel plate in the process of initial location. Upper/lower limit value ----To adjust the upper and lower limits of height controller SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ...

  • Page 42: Chapter Viii. Libminit(Library Of Patterns)

    In the system main menu, press [F6] to enter the LIBMINIT(Library of Patterns). Fig. 8.1 LIBMINIT Feature(Library of Patterns) 凹圆梯形Concave-edged trapezium 带孔法兰Holed flange 六孔法兰Six holed flange 双耳法兰Double-ear flange 叶轮挡板Impeller baffle SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 43: Selection Of Pattern Elements

    Note: The 17th pattern element is customized element. 8.3. Arrangement and Layout of Pattern Element After pattern element is selected as per the above-mentioned procedure, the system will prompt at the upper SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 44 Row pitch----Distance between rows. Column pitch----Horizontal distance between machined parts Row offset----The deviation of raw misplacement, as shown in Fig. 8.3. Fig. Pattern Fig. 8.3 Schematic diagram of part layout 工件 Workpiece 孔形 Hole SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 45: User Defined Module

    Simply copy this program into the file system. The 17th pattern element is self-defined. If no new module is self-defined, the system will take the old module automatically. This module is allowed to use for Layout and Rotate features, but no parameter to set. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 46: Chapter Iv. Diagnose

    Let the system to show the state of active optical isolation input ports. 0 stands for low potential(grounding) while 1 stands for high potential(24V or overhead). See "Definitions of Input/output Ports" for the symbol definitions of input ports. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 47: Chapter X. Connections Of Input/Output Ports

    Control signal = 0 switch/relay on(+24V circuit on, low effect and sign transmission) Control signal = 1: switch/relay off(+24V circuit off and no sign transmission) +24V System input NC contact Input signal SH-2012AH-QG 切割机数控系统说明书（C002） 24VGND Internal System PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 48: Definitions Of Input/Output Ports

    NC contact for lifting operation(OH3) of cutting torch with height controller M10/M11 Flame cutting: M38 height control; M38 for ON and M39 for OFF Plasma cutting: M10 reserve; M10 for ON and M11 for OFF SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 49 M22/M23 Reserved M24/M25 Reserved NC contact for corner(OH1) NC contact for cutting oxygen(OH2) +24V/1A power supply +24V/1A power supply 24V地 Ground for 24V power supply 24V地 Ground for 24V power supply SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 50: Definitions Of 15-Pin Ports For Motor

    燃气/预热氧电磁阀Gas/preheating oxygen solenoid valve 电源 XS1Power supply XS1 继电器Relay 通讯/手控Communication/manual control 割枪升上限位（升降机构）Upper limit for torch lifting operation(elevating mechanism) 调高电机Height control motor 割枪降下限位（升降机构）Lower limit siwtch for torch lowering operation(elevating mechanism) 输入/输出XS12Input/output XS12 电机XS3Motor XS3 SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 51 Beijing Start M&E Technology Development Co., Ltd. 切割氧电磁阀 燃气/预热氧电磁阀 DC24V 继电器 继电器 24V 24G COM 01 电源 XS1 COM <+ >- 继电器 继电器 通讯/手控 割枪升上限位 输入/输出 电机 （升降机构） XS12 割枪降下限位 （升降机构） 调高电机 SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...

  • Page 52: Typical Wiring For Plasma Arc Cutting Operation

    Y正限位 X负限位 Y负限位 外部起动键 输入端 外接回退键 输出端 接调高等离子起弧成功信号 急停（常闭） 外接暂停键（常闭） 割枪初始定位 （输出）等离子模式M38调高 器自动/手动转换（拐角信号） 等离子起弧开关（常开） 继电器 等离子调高公共端 （输出）调高器割枪降控制（常开） 割枪 （输出）调高器割枪升控制（常开） 调高器割枪降（常闭） 调高器割枪升（常闭） 待切割钢板 （输出）火焰模式时M38接调高 控制（自动/手动转换） *M20如果不接点火（参数中将点火延时 设为0），M20为火焰/等离子转换开关 拐角常闭触点 切割氧常闭触点 24V+ 火焰模式时去调高公共端 24V地 SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 53 （输出）调高器割枪升控制（常开） Output for lifting operation of cutting torch with height controller(NO contact) 调高器割枪降（常闭） Lowering operation of cutting torch with height controller(NC contact) 调高器割枪升（常闭） Lifting operation of cutting torch with height controller(NC contact) SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 54: Compatible Connection For Flame/Plasma Operations

    COM 01 10.8 Pin Definitions The pin definitions of 15-pin connector for Model SH-HC30 height controller manufactured by Microstep are as follows: Attribute Description Remarks 232-COM Serial common Serial Rx 232-RXD SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 55 Input Port 10 for External Control Box X- Input Port 11 for External Control Box Y+ Input Port 12 for External Control Box Y- Input Port 13 for piercing key of External Control Box Ground for 24V power supply SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 56: Appendix I: The Wiring Diagram And Pin Definitions For Model Sh-Hc30 Height Controller Manufactured By Microstep

    Ground of 24V power supply for height controller Power supply Ground of 24V power supply for height controller Output Arc voltage signal for the height of plasma cutting torch Power supply + 24V power supply for height controller SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 57 9-pin connector of divider board 调高控制器 15 芯接头 25-pin connector for CNC 15-pin connector for system height controller 4.Wiring Diagram of Capacitance-type Height Controller 15-pin connector for 25-pin connector for CNC height controller system SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 58: Appendix Ii: Instructions For Software Upgrading Operation Of Sh-2012Ah

    USB disk. If these two factors are assured, try to upgraded the program again following the specific operation procedure. If program upgrading failure insists, please contact the Customer Service Department of SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 59 北京斯达微步控制技术有限公司 Beijing Start M&E Technology Development Co., Ltd. Beijing Start M&E Technology Development Co., Ltd. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 60: Appendix Iii: Installation Dimensional Drawing

    北京斯达微步控制技术有限公司 Beijing Start M&E Technology Development Co., Ltd. Appendix III: Installation Dimensional Drawing SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 61: Appendix Iv: Troubleshooting

    Check if any external lim Check if limit switches ar Secure the connection. it switch is connected. e functional and if loose c Travel limit ala onnection or disconnection rm at power-on exists. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 62 USB port for any ligh e system for any loose co ign material from the port. nnection; check the USB port for any foreign materi al and all the pins are in normal condition. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 63 Check if the four relays Replug or replace the relays. system on the rear panel are reli output ably connected, if the rela y operation is normal and if the contact is function SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...

  • Page 64: Appendix V: Wiring Instructions For Extended External Manual Control Box

    The wiring instructions are as follows: 输入/输出(DB25) Input/output(DB25) 启动键 Start key 暂停键 Pause key 急停键 Emergency stop key 回退键 Backspace key X 轴正向运动 X-axis positive movement X 轴反向运动 X-axis reverse movement Y 轴正向运动 Y-axis positive movement SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 65 NO contact or all NC contact. The availability of these 5 external control keys depends on the option of external manual control box for height controller in parameter setting. When the option is enabled, they will function. SH-2012AH-QG 切割机数控系统说明书（C002） PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
