APPLIANCE MODELS ACCEPTABLE TO BE USED WITH THIS KIT - NGCK-A 787 (AUTO IGNITION MODELS)
TICK
SERIES NAME
OUTLAND FIRE TABLE
OUTLAND Fire Table model FMPPC2E (400) only.
Please contact OUTLAND, or visit www.outlandliving.com if you require
the assembly instruction manual for Fire Table model FMPPC2E-1 (401).
NOTE: This assembly instruction manual is for
FMI BRANDS INC.
107 – 19052 26 Avenue | Surrey, B.C. Canada V3Z 3V7
Toll Free 1-888-514-1663 | Fax 1-888-797-9931
Propane to
Natural Gas Appliance
Conversion Kit
NATURAL GAS CONVERSION KIT RATINGS
GAS ORIFICE SIZE
MANIFOLD PRESSURE
INLET PRESSURE
INPUT RATING
Tested by CSA International
MODEL NUMBERS
FMPPC2E, FMPPC2E-1
NGCK-A
PART #787
AUTO IGNITION
2.6mm
7in WC
0.25 PSIG
35,000BTU/h
SERIES NUMBERS
400, 401
D.787.000.V1_400
Advertisement
Related Manuals for Outland Living NGCK-A
Summary of Contents for Outland Living NGCK-A
- Page 1 7in WC INLET PRESSURE 0.25 PSIG INPUT RATING 35,000BTU/h Tested by CSA International APPLIANCE MODELS ACCEPTABLE TO BE USED WITH THIS KIT - NGCK-A 787 (AUTO IGNITION MODELS) TICK SERIES NAME MODEL NUMBERS SERIES NUMBERS OUTLAND FIRE TABLE FMPPC2E, FMPPC2E-1...
- Page 2 The installation is not proper and complete until the operation of the converted appliance is checked as specified in the manufacturer’s instructions supplied with the kit. En-2 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 3 CONTENTS 1. Natural Gas Conversion Kit Manual - FMPPC2E (400) 2. Natural Gas Valve (marked with Yellow Cap) 3. Heat Shrink Tubing 4. Low Pressure Natural Gas Hose with Quick Disconnect Inlet Fitting and 5/8”-18UNF Outlet Connector; MAX. WP 1/2 PSI; 3/8” diameter, 12ft length (marked with Yellow Cap) 5.
- Page 4 Disconnect and remove the LP cylinder from the Fire Table. CLOSE VALVE ON LP (PROPANE) CYLINDER DISCONNECT AND REMOVE THE PROPANE CYLINDER FROM FIRE TABLE En-4 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 5 STEP 3 Empty the Fire Table burner tray of all glass rocks. WARNING: Avoid glass dust. Always wear gloves to handle rocks; caution for glass dust when handling; use a rag to wipe glass dust. STEP 4 Remove bottom Cylinder Base by lifting off press-fit studs.
-
Page 6: Gas Valve
Disconnect the igniter cable. Slide protective cap back to expose the cable connection. Grasp the cable at the base and pull firmly. GAS VALVE IGNITER CABLE En-6 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™... -
Page 7: Mounting Bracket
STEP 7 M6 SCREWS Remove End Panel with Gas Knob and Valve by removing (4x) M6 screws. END PANEL WITH GAS KNOB & VALVE STEP 8 GAS KNOB Disassemble the propane gas (2X) SCREWS valve. BASE RING Remove the gas control knob FACEPLATE by gripping firmly and pulling straight out. - Page 8 The arrow on the knob should be aligned with the OFF indicator on the valve cover at this point. En-8 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 9 STEP 10 Slide the heat shrink tubing (part 3) over the burner venturi tube. HEAT SHRINK TUBING BURNER VENTURI TUBE STEP 11 Mount the end panel with new natural gas bracket assembly. Use the same 4x M6 screws. Important: Ensure the gas valve orifice is aligned to sit inside the burner venturi tube.
- Page 10 If, for some reason, after applying the heat shrink tubing there are visible gaps, or exposed air holes around the venturi connection area, we suggest you use common high heat electrical tape to close those gaps. En-10 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 11 STEP 13 Connect the igniter cable to the gas valve. Note the small rectangular connection IGNITER CABLE STEP 14 Attach the natural gas hose (part 4). If the natural gas hose is not preassembled to the natural gas valve, remove the yellow cap and attach the natural gas hose to the gas valve coupling.
- Page 12 3/8” Diameter, closed OFF. Low Pressure (.5 PSIG) NG/LP Gas Hose with Quick Disconnect Inlet Fitting En-12 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 13 STEP 20 STEP 21 Attach the gas hose to Turn on the your installed quick- gas flow from disconnect natural gas your source source (house line). valve. STEP 22 LEAK TEST: Mix a solution of liquid soap and water in a QUICK spray bottle and perform a leak test on all DISCONNECT...
- Page 14 Ensure igniter cover is not covered by glass rocks (see photo). This helps air circulate. Repeat ignition procedure. En-14 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 15 STEP 25 AFFIX MARKING AND WARNING LABEL AFTER CONVERSION, TESTING AND VERIFICATION SEQUENCES ABOVE ARE COMPLETE AND PRIOR TO FIRST USE. The marking and warning label has two sides, containing specific TAG 1 and TAG 2 content, and requires specific action as instructed below to be in strict compliance with CSA guidelines.
- Page 16 After Steps A and B above are complete, affix the label on the appliance, using the supplied hang strap, in the location as shown on the applicable model appliance picture below. MODEL HANG TAG LOCATION FMPPC2E (400) HANG TAG HOLE LOCATION En-16 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
- Page 17 STEP 26 Your Outland Fire Table is now converted to Natural Gas. Follow normal lighting procedures as per your Owners’ Manual. CAUTION! Hose is a trip hazard! NG CONVERSION COMPLETE En-17 1-888-514-1663 | WWW.OUTLANDLIVING.COM...
-
Page 18: Handle With Care
Children should be supervised at all times when using this unit without exception. WARNING! HOT SURFACE! GLASS. FRAGILE! HANDLE WITH CARE En-18 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™... - Page 19 FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT WWW.OUTLANDLIVING.COM Fire Table accessories, replacement rocks and parts can be purchased at: www.outlandliving.com or by calling 888-514-1663. The owner’s manual is available as a free download from www.outlandliving.com. Replacement part orders can be sent by mail to the address on the cover of this booklet, or faxed to (888) 797-9931.
- Page 20 Natural Gas Conversion Kit En-20 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E (400) ™...
