MasterCraft SC20BBL Instruction Manual

MasterCraft SC20BBL Instruction Manual

Leaf blower
Hide thumbs

Advertisement

Table of Contents

model no. SC20BBL
IMPORTANT:
Read and understand this instruction manual thoroughly
before using the product.
LEAF BLOWER
INSTRUCTION
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC20BBL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MasterCraft SC20BBL

Summary of Contents for MasterCraft SC20BBL

  • Page 1 SC20BBL LEAF BLOWER INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly MANUAL before using the product.
  • Page 2 headline bars continuation tabs notes warnings...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Technical Specifications Safety Guidelines Key Parts Diagram Operating Instructions Maintenance Troubleshooting Parts List Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS •...

  • Page 4: Technical Specifications

    SC20BBL | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Rated Voltage 20 V d.c. Maximum Air Volume 370 CFM Maximum Air Speed 90 MPH (144 KPH) *Maximum battery voltage without workload; with workload nominal voltage is 18 V.

  • Page 5: Safety Guidelines

    SAFETY GUIDELINES: WARNING! Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, eliminate any danger, nor are they substitutes for proper accident prevention measures.
  • Page 6 SC20BBL | contact us 1-800-689-9928 ELECTRICAL SAFETY • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adaptor plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
  • Page 7 POWER TOOL USE AND CARE • Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. • Do not use the power tool if the switch does not turn it on and off.
  • Page 8 SC20BBL | contact us 1-800-689-9928 • Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130°C (265°F) may cause explosion. • Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions.
  • Page 9 ....WARNING–To reduce the risk of injury, always wear ear protection... The logo of UL certification WARNING! To reduce the risk of electric shock or damage to the charger and battery, use only the Mastercraft batteries and chargers listed. ® BATTERY PACKS...

  • Page 10: Key Parts Diagram

    SC20BBL | contact us 1-800-689-9928 PACKAGE CONTENTS: Cordless blower, blower tube. KEY PARTS DIAGRAM continuation tabs notes warnings Description No. Description Blower tube Variable-speed trigger switch Tube-release button Before attempting to use this tool, become familiar with all of its operating features and safety requirements.

  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS fig 1 Battery-release button TO ATTACH BATTERY PACK (fig 1) 1. Make sure that the switch is in the OFF position. 2. Align the raised portion on the battery pack with the grooves on the bottom of the tool, and then slide the battery pack onto the tool as shown.
  • Page 12 SC20BBL | contact us 1-800-689-9928 TO TURN THE BLOWER ON/OFF (fig 3) fig 3 Variable-speed trigger switch 1. To turn the blower on, depress the variable-speed trigger switch. 2. The variable-speed trigger switch delivers higher speed with increased trigger pressure and lower speed with decreased trigger pressure.

  • Page 13: Maintenance

    MAINTENANCE The tool may be cleaned most effectively with compressed dry air. Always wear safety goggles when cleaning tools with compressed air. Before each use: 1. Check for damaged, missing, or worn parts. 2. Check for loose screws, misalignment or binding of moving parts, or any other condition that may affect the operation.

  • Page 14: Troubleshooting

    SC20BBL | contact us 1-800-689-9928 TROUBLESHOOTING Problem Possible causes Solutions The blower does not The battery pack is depleted. Charge the battery pack. work. The battery pack is too hot. Turn off the blower and allow the battery pack to cool.
  • Page 15 EXPLODED VIEW...
  • Page 16 SC20BBL | contact us 1-800-689-9928 No. Part No. Description No. Part No. Description SC20BBL01 Blower Tube SC20BBL11 Screw SC20BBL02 Locking Spring SC20BBL12 Screw SC20BBL03 Blower Tube Button SC20BBL13 Decorative Cover SC20BBL04 Air Hood SC20BBL14...
  • Page 17 This product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;...
  • Page 18 SC20BBL | contact us 1-800-689-9928 to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners; and i) this warranty will not apply to component parts sold by and identified as the product of another company, which shall be covered under the product manufacturer’s warranty, if any.
  • Page 19 model no. SC20BST GRASS TRIMMER/ EDGER INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly MANUAL before using the product.
  • Page 20 headline bars continuation tabs notes warnings...

  • Page 21: Parts List

    TABLE OF CONTENTS Technical Specifications Safety Guidelines Key Parts Diagram Operating Instructions Maintenance Troubleshooting Parts List Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS •...

  • Page 22: Technical Specifications

    headline bars model no. SC20BST | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Rated Voltage 20 V d.c. No-load Speed 7,700 RPM Cutting-line Diameter 0.065” (1.65 mm) Cutting Width 12” (30.5 cm) *Maximum battery voltage without workload; with workload nominal voltage is 18 V. continuation tabs notes warnings...

  • Page 23: Safety Guidelines

    SAFETY GUIDELINES: WARNING! Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, eliminate any danger, nor are they substitutes for proper accident prevention measures.
  • Page 24 headline bars model no. SC20BST | contact us 1-800-689-9928 • Avoid dangerous environments. Don’t use appliances in damp or wet locations. PERSONAL SAFETY • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
  • Page 25 • Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
  • Page 26 ....WARNING–To reduce the risk of injury, always wear eye protection....WARNING–To reduce the risk of injury, always wear ear protection. WARNING! To reduce the risk of electric shock or damage to the charger and battery, use only the warnings Mastercraft batteries and chargers listed. ® BATTERY PACKS CHARGERS...
  • Page 27 • If the power tool should start to vibrate abnormally or become noisy, stop the motor and check immediately for the cause. Abnormal noise is generally a warning of trouble. • Keep guards in place and in working order. Make sure all proper guards and other safety devices are properly and securely attached before using this product.

  • Page 28: Key Parts Diagram

    headline bars model no. SC20BST | contact us 1-800-689-9928 PACKAGE CONTENTS: Cordless trimmer, safety guard, auxiliary handle, flower guard, edging wheel, 2 screws. KEY PARTS DIAGRAM continuation tabs notes Description No. Description warnings Lock-off button Angle-adjustment button On/off switch Flower guard Auxiliary handle Edging wheel Handle-unlock button...

  • Page 29: Operating Instructions

    OPERATING INSTRUCTIONS fig 1 Safety guard INSTALL/REMOVE THE SAFETY GUARD (fig 1) 1. Insert the ribs of the safety guard into the slots on the trimmer head. 2. Align the holes on the safety guard with the holes Trimmer on the trimmer head, and then use the screws head (included) to lock the safety guard.
  • Page 30 headline bars model no. SC20BST | contact us 1-800-689-9928 INSTALL THE EDGING WHEEL (fig 3) fig 3a Wheel 1. Align two slots on the wheel with the metal plate on the trimmer head, and then fully insert the wheel onto the metal plate. Slots 2.
  • Page 31 ADJUST THE DIRECTION OF UPPER fig 5 SHAFT (fig 5) 1. Pull the upper shaft rotation collar backward and Upper shaft hold on the knob. rotation collar 2. Turn the upper shaft for 90° in a clockwise direction and then release the knob to lock the upper shaft.
  • Page 32 headline bars model no. SC20BST | contact us 1-800-689-9928 TO ATTACH BATTERY PACK (fig 8) fig 8 1. Make sure that the switch is in the OFF position. 2. Align the raised portion on the battery pack with the grooves on the bottom of the tool, and then slide the battery pack onto the tool as shown.
  • Page 33 TO START/STOP THE TRIMMER (fig 9) fig 9 Lock-off button 1. To turn the trimmer on, press the lock-off button and then depress the on/off switch. 2. To turn it off, release the on/off switch and allow the trimmer to come to a complete stop. TRIMMING 1.
  • Page 34 headline bars model no. SC20BST | contact us 1-800-689-9928 AUTOMATIC LINE FEED SYSTEM (fig 11) fig 11 When initially switching on the trimmer, a small Feed length of line is fed out. Each time the tool is started button from rest it will advance same amount trimmer line. If the noise of the line being cut can’t be heard, more line will be fed out.
  • Page 35 MANUALLY FEED THE LINE (fig 12) fig 12a Spool cap If required, line can be fed out manually. Before manually feeding, remove the battery first. To operate, press and release manual line feed button Slot Spool base (fig 11), while gently pulling out the lines until the lines reach the line cutter.
  • Page 36 headline bars headline bars model no. SC20BST | contact us 1-800-689-9928 WIND THE SPOOL WITH NEW LINE fig 13a (fig 13) Spool hole 1. Detach the spool cap and spool from the spool base (refer to ). Remove the old cutting line fig 12 from the spool.

  • Page 37: Maintenance

    MAINTENANCE CHECK FOR DAMAGED/WORN PARTS BEFORE EACH USE Check the trimmer head, safety guard and auxiliary handle and replace any parts that are cracked, warped, bent, or damaged in any way. The line cutter on the edge of the guard can dull over time. It is recommended that you periodically sharpen it with a file or replace it with a new blade.

  • Page 38: Troubleshooting

    headline bars model no. SC20BST | contact us 1-800-689-9928 TROUBLESHOOTING Problem Possible causes Solutions The trimmer doesn’t The battery is depleted. Charge the battery pack. work. The battery pack is overloaded. Decrease the load on the trimmer. The battery pack is too hot. Cool the battery pack and then restart the tool again.
  • Page 39 EXPLODED VIEW...
  • Page 40 headline bars headline bars model no. SC20BST | contact us 1-800-689-9928 No. Part No. Description No. Part No. Description SC20BST01 Secondary Handle SC20BST32 Left Swivel Arm SC20BST02 Right Handle SC20BST33 Angle-adjustment Button SC20BST03 Right Decorative Cover SC20BST34 Right Housing SC20BST04 Rotation Button SC20BST35 Fixing Plate...
  • Page 41 This product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;...
  • Page 42 The provisions contained in this warranty are not intended to limit, modify, take notes away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or federal legislation. Made in China Imported by Mastercraft Canada Toronto, Canada M4S 2B8 warnings...
