Communications
Test Set
3550 / 3550R
RCI Manual
Issue-8
EXPORT CONTROL WARNING: This document contains controlled technical data under the
jurisdiction of the Export Administration Regulations (EAR), 15 CFR 730-774. It cannot be
transferred to any foreign third party without the specific prior approval of the U.S. Department of
Commerce, Bureau of Industry and Security (BIS). Violations of these regulations are punishable
by fine, imprisonment, or both.
