Gardener's 8593617 Quick Start Manual

Store your homegrown harvest or farmer's market bounty in this spacious and space-saving rack. The drawers have slatted floors to
allow good air-flow, essential for extending shelf life and preventing decay. The deep drawers provide dark storage for potatoes and
onions, as well as canning jars, prolonging shelf life. The two shallow drawers are ideal for drying garlic and herbs. The slatted top is
handy for stowing supplies like pickling crocks.

Parts List

Drawer A
(4) Front/Back
Panels
(2) Sides (4) Side Panels
(4) Brace
Slats

Tools Needed

Drill with bits
Phillips screwdriver
Adjustable wrench
NOTE: Assembly is easiest with two people.
Step 1. Identify and organize all parts on a clean, level surface.
Step 2. Stand 2 of the Drawer A Side Panels parallel to each other with the wooden
columns facing in (Figure 3). Notice how there are gaps between the Side Panels'
ledges and wooden columns (Figure 2). Slide a Drawer Bottom into those gaps and
line up the ends with the edges of the Side Panels.
Step 3. Fit two Drawer A Front/Back Panels onto the open sides of the drawer. Their
wooden columns should fit next to the wooden columns on the Side Panels (Figure 2).
Step 4. Slide a Bolt through a predrilled hole on the outside of a Side Panel, into the
Panel's wooden column, and through the wooden column on the Front/Back Panel
(Figure 2). Place a Washer onto the end of the Bolt and loosely attach a Nut. Repeat to
insert Bolts into the remaining seven sets of predrilled holes and then tighten them all
into place using a Phillips screwdriver and wrench.
Step 5. Repeat Steps 2-4 to make another Drawer A, three Drawer Bs and one Drawer C.
#8593617

Deep Drawer Harvest Storage Rack

Drawer B Drawer C
(6) Front/Back (2) Front/Back
Panels Panels
(6) Side Panels (2) Side Panels
(2) Crossbars

Assembly

(1) Slatted Top
(6) Drawer
Bottom
(20) Screws
(48) Bolts,
Washers & Nuts
over please
Figure 2
Side Panel Front/Back Panel
Bolt
wood
Washer
columns
ledge
Drawer
Bottom
Figure 3
Side Panels
Drawer
Bottom
wood
columns
_
Figure 1
Drawers A
Drawers B
Drawer C
Nut
Front/Back
Panels
Bolt,
Washer
and Nut
0891V Rev 07/16
