WMDQ-177ACN
2T2R PCIeModule
802.11b/g/n/ac/n/a
User Manual
Version 1.0
Gemtek Technology Co., Ltd.
www.gemtek.com.tw
No.15-1 Zhonghua Road, HsinChu
Industrial Park, HuKou Hsiang,
HsinChu Hsien,Taiwan, R.O.C.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WMDQ-177ACN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gemtek WMDQ-177ACN

  • Page 1 WMDQ-177ACN 2T2R PCIeModule 802.11b/g/n/ac/n/a User Manual Version 1.0 Gemtek Technology Co., Ltd. www.gemtek.com.tw No.15-1 Zhonghua Road, HsinChu Industrial Park, HuKou Hsiang, HsinChu Hsien,Taiwan, R.O.C.
  • Page 2 Introduction WMDQ-177ACN is a 5Ghz +2.4G dual Band selectable 2T2R PCIe mini Card Module based on the Qualcomm QCA9892 solution which features improved transmission power and sensitivity by Gemtek. Using the QCA9892 external FEM, it is the ideal cost effective solution for platform integration.
  • Page 3: Hardware Specification

    Hardware Specification General Information Model name WMDQ-177ACN Chipset Qualcomm QCA9892 Interface PCI Express 1.1 Operating Voltage DC 3.3V Antenna Connectors 2 x I-PEX connectors PCB Dimensions 30mmX 50.8mm Temperature Range 0 to 40 °C (Operating), -30 to 70 °C (Storage)
  • Page 4 80MHz channel:  1Nss: 390Mbps @ 800GI, 433.3Mbps @ 400GI  (Max.) 2Nss: 780Mbps @ 800GI, 866.7Mbps @ 400GI  (Max.) T x channel width 20MHz / 40MHz /80MHz support Standard/Compliance IEEE 802.11b/g/n/ac RF Spec Frequency Range 2.4G,5G Radio Stream 2T2R Transmit Power 802.11b 1Mbps 19 dBm...
  • Page 5 Dimension : 50mm* 30mm (Full size) Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6: Important Note

    cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna.
  • Page 8 Industry Canada statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
  • Page 9: Radiation Exposure Statement

    Caution: the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; Avertissement: les dispositifs fonctionnant dans la bande de 5150 à 5250MHz sont réservés uniquement pour une utilisation à...
  • Page 10 Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 7280B-120506". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
