- Page 1 eXtremeRAID 3000 Quick Installation Guide DB11-000034-00 First Edition 08P5526...
- Page 2 Electromagnetic Compatibility Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference.
- Page 4 Declaration of Conformity Per FCC Part 2, Section 2.1077(a) Manufacturer’s Name: LSI Logic Corporation Manufacturer’s Address: North American Headquarters Milpitas, CA Declares that the product: Product Name: High Performance RAID Controller Model Number(s): eXtremeRAID 3000 Year of Manufacture: 2000 Conforms to the following Product Specification(s): FCC: CFR 47 Part 15, Subpart B, Section 15.107(e) and Section 15.109(g) Class B Digital Device...
- Page 5 Declaration of Conformity Per 89\336\EEC Responsible Party Name: LSI Logic Corporation Address: North American Headquarters Milpitas, CA U.S.A. hereby declares that the product Trade Name: High Performance Caching RAID Controller Model Number(s): eXtremeRAID-3E Fab. 550137-A Rev. A conforms to the following specifications Standards: EN 50081-1:1992, Emissions EN 55022:1998 Class B ITE radiated and conducted...
- Page 6 Community of Europe CE mark is rated for the eXtremeRAID 3000 as follows: CISPR 22 Radiated Emission EN55022, Generic immunity standard for the following: IEC 801-2 ESD, IEC 801-3 Radiated, and IEC 801-4 EFT/Burst Warning! This is a Class B product. In a residential environment this product may cause radio interference, in which case the user may be required to take adequate measures.
- Page 7 Underwriters Laboratories Statement and Warning...
- Page 8 Proprietary Rights Notice This document contains proprietary information of LSI Logic Corporation. The information contained herein is not to be used by or disclosed to third parties without the express written permission of an officer of LSI Logic Corporation. Any product(s) described herein is/are a licensed product of LSI Logic Corporation.
- Page 9 Trademark Acknowledgments LSI Logic, the LSI Logic logo, MORE, Mylex, and SANmapping are trademarks or registered trademarks of LSI Logic Corporation. All other brand and product names may be trademarks of their respective companies.
-
Page 11: Table Of Contents
Contents Hardware Installation Introduction ..................1-1 Performing an Installation ..............1-1 PCI Hot Plug ................1-1 Connectors, Jumpers, and LEDs ..........1-1 Installing the eXtremeRAID 3000 into the System Board ....1-4 What to Do Next ................1-7 SOFTWARE LICENSE AND WARRANTY POLICY Manual No. - Page 12 eXtremeRAID 3000 Installation Guide...
-
Page 13: Hardware Installation
Hardware Installation Introduction The eXtremeRAID 3000 is a very versatile PCI to Fibre Channel RAID controller with an internal Ultra2 SCSI, LVD channel. There are many possible hardware configurations. This quick installation guide assumes that the user is familiar with controller, disk drive, and RAID terminology. Performing an Installation WARNING To avoid electrical shock, do not attempt to... - Page 14 Performing an Installation SCSI (CH 0) Fibre Loop (CH 1) Fibre Loop (CH 2) Figure 1. eXtremeRAID 3000 Controller with Channel Connectors 5- Host Activity 6- Cache Activity 1- SCSI Activity 2- Single Ended Mode 8- Fibre CH 1 3- Fibre CH 0 7- Diagnostic 4- LVD Mode Activity...
- Page 15 Hardware Installation Figure 3. eXtremeRAID 3000 Controller with Jumpers (front) Table 1. Jumper Descriptions Jumper Description Default Setting pins 1–2 for Arm Proc, pins 2–3 for I 1–2 Mylex manufacturing diagnostics – do not use pins 1–2 normal , pins 2–3 normal mode 1–2 maintenance –...
-
Page 16: Installing The Extremeraid 3000 Into The System Board
Installing the eXtremeRAID 3000 into the System Board Installing the eXtremeRAID 3000 into the System Board 1. With the power off, plug (install) the controller firmly into any 32 bit or 64 bit PCI slot, and wear a ground wrist strap as shown in Figure 4. Notice that the black handle must fit into the side slot for a proper fit. - Page 17 Hardware Installation 4. Enable termination power on all SCSI drives connected to the controller. See the documentation that comes with your drives for instructions on how to do this. Figure 5. Internal SCSI Configuration and Termination 5. Set the SCSI ID for each external disk drive to a unique address between 0 and 15, but do not use address 7 (reserved for the controller).
- Page 18 Installing the eXtremeRAID 3000 into the System Board 8. Connect a Fibre cable, with the High Speed Serial Data Connector (HSSDC), to either one or both of the external Fibre connectors on the eXtremeRAID 3000 controller. Connect the other end of the Fibre cable, with a 9-Pin DSUB connector, to other devices or to a Fibre Channel Cabinet external drive cabinet, as required (see Figure 6).
-
Page 19: What To Do Next
Hardware Installation What to Do Next 1. Use RAID EzAssist to create an automatic or a custom RAID Configuration. Refer to the RAID EzAssist Configuration Utility Quick Configuration Guide or RAID EzAssist Configuration Utility User Reference Guide. 2. Install the eXtremeRAID 3000 controller drivers appropriate for your server’s network operating system. - Page 20 What to Do Next eXtremeRAID 3000 Quick Installation Guide...
-
Page 21: Software License And Warranty Policy
LSI LOGIC CORPORATION SOFTWARE LICENSE AND WARRANTY POLICY Limited Warranty LSI warrants to the original purchaser of the product enclosed herein (“Customer”) that (a) for a period of three (3) years from the date of Customer’s purchase of the Product (excluding batteries and memory) (the “Product Warranty Period”), and (b) for a period of one (1) year from the date of purchase of the Product by Customer (the “Battery/Memory Warranty Period”), the batteries and memory... - Page 22 with LSI’s instructions and the terms of this Agreement, shipping costs to be borne by LSI, and (c) Customer has provided proof of purchase price and date for unregistered Product. LSI shall bear one-way shipping, packing and insurance costs and all other costs, excluding labor and parts, necessary to effectuate repair or replacement under this warranty.
- Page 23 is a part of the Product (“LSI Software”) solely as part of the Product incorporated into the OEM Products that and not on a standalone basis. Customer may not (a) sell, lease, license, or sublicense the LSI Software, (b) de-compile, disassemble, reverse engineer,...
- Page 24 Manual No. DB11-000034-00 08P5526 LSI Logic Corporation North American Headquarters Milpitas, CA 408.433.8000...
