Polychain
You can connect any 2 ARGON8 models together to give 16 voices using polychain.
First, connect the desired master ARGON8 DIN MIDI Out to your desired slave ARGON8 DIN
MIDI In.
On the master ARGON8 navigate to 'Settings (General) > Polychain Master' and turn this on.
The slave device should now be showing all voice mode LEDs lit and 'Polychain Slave' on-
screen.
When In Polychain mode, the slave ARGON8 panel is disabled along with the keyboard (for
ARGON8 & ARGON8X).
Polychain mode can be exited by turning off the 'Settings (General) > Polychain Master'
setting on the master ARGON8 or by rebooting the synthesisers.
Note: Polychain can only be enabled when not in MPE mode
