ASSEMBLY INSTRUCTIONS 2M X 1M RECTANGULAR ALUMINIUM FIREPIT TABLE SKU: FLAME200-123 / FLAME200-124 2021 V1.0 IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
ASSEMBLY INSTRUCTIONS PARTS LIST Table Box Part Part Name Table Base Table Base With Door Support Bar Table Top Glass Washer M6 x 20mm Screw Allen Key Suction Ring M6 x 40mm Screw Door Handle...
Page 3
ASSEMBLY INSTRUCTIONS PARTS LIST Firepit System Box Windguard Box Part Part Name Firepit System Stainless Steel Lid Cover Onyx Coloured Fireglass Long Winguard Panel Short Winguard Panel Top Connector For Rectangular Windguard Bottom Connector For Rectangular Windguard...
ASSEMBLY INSTRUCTIONS SAFETY ADVICE BEFORE YOU START: • Ensure that you read this manual before starting to assemble your item(s). • Check that you have all parts from the above part list. Do not throw away any packaging until you are confident that you have all parts. •...
Page 5
• Please only use this product for its intended purpose as outdoor furniture within a residential environment. Failure to do so will void your warranty. • Westminster Outdoor Living holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, misuse and/or negligence •...
Page 6
ASSEMBLY INSTRUCTIONS TABLE ASSEMBLY STEP 1 Secure the handle (Z) with the M6 x 40mm screw (Y) to the door found on the table base (A1). Loosely secure the table base (A + A1) onto the table top (B) using 8 x M6 x 20mm screws (E), 8 x washers (D).
Page 7
ASSEMBLY INSTRUCTIONS TABLE ASSEMBLY STEP 2 Turn the table top (B) and legs (A+A1) over. Add the suctions cups (X) Secure the glass (C) onto the table top frame (B), ensuring the suctions cups are flat.
Page 8
ASSEMBLY INSTRUCTIONS FIREPIT SYSTEM ASSEMBLY STEP 3 Unscrew the firepit system control panel nuts. Keep the nuts to one side.
Page 9
ASSEMBLY INSTRUCTIONS FIREPIT SYSTEM ASSEMBLY STEP 4 Lower the gas firepit system (G) into the centre of the table, positioning the regulator, hose and control panel through the table hole before lowering the system into place.
Page 10
ASSEMBLY INSTRUCTIONS FIREPIT SYSTEM ASSEMBLY STEP 5 Attach the firepit control panel to the table base (A1). Tighten the control panel onto the frame using the nuts previously removed from the control panel.
Page 11
ASSEMBLY INSTRUCTIONS FIREPIT SYSTEM ASSEMBLY STEP 6 Carefully fill the firepit system with the fireglass (I) ensuring the pilot cover is not obstructed. Ensure the gas pipes under the table are not kinked and all wiring is connected. PIN: 0359 03837...
Page 12
ASSEMBLY INSTRUCTIONS FIREPIT SYSTEM ASSEMBLY STEP 7 Remove the battary cover. Place 1 x AAA battery into the ignition, ensuring the negative side is inserted first.
Page 13
ASSEMBLY INSTRUCTIONS WINDGUARD ASSEMBLY STEP 8 Loosen all the grub-screws in the 8 x connectors (K + L) with a phillips screwdriver (not supplied). Loosely secure each windguard panel (J +J1), one at a time, using the top and bottom connectors (K + L) until a rectangular windguard is formed. Do not tighten any screws until the windguard is formed.
ASSEMBLY INSTRUCTIONS TROUBLESHOOTING • Ensure the black wire from the system is connected to the igniter. • 1 x AAA battery must be inserted into the ignition, position within the control panel. • Ensure the pilot cover is free from the Onyx glass.
ASSEMBLY INSTRUCTIONS CARE, MAINTENANCE & WARRANTY INFORMATION Our range of aluminium furniture is designed for continual outdoor use. The aluminium frame ensures that you can leave it outside all year round. ALUMINIUM CARE The aluminium framework is incredibly low maintenance and is resistant to UV rays, salt water, frost and snow and requires only basic care to keep it clean.
