Frigidaire FEFL79D Factory Parts Catalog

30-inch freestanding electric range
Hide thumbs

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Market
Wiring Diagram
Owner's Guide
Installation Instructions 316259206
Service Data Sheet
GLEFS79D.eps T20G0028.eps T20V0052.eps T20T0021.eps T20D0008.eps
316417708d.eps 316417708s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FEFL79DBA FEFL79DBB FEFL79DQA FEFL79DQB FEFL79DSA
30" f/s elec
30" f/s elec
30" f/s elec
black
black
bisque
North America North America North America North America North America North America
316417708
316417708
316417708
316417005
316417005
316417005
316259206
316259206
316417600
316417600
316417600
Publication No.
5995417895
04/10/05
(EN/SERVICE/ECL)
369
FEFL79DSB
30" f/s elec
30" f/s elec
30" f/s elec
bisque
white
white
316417708
316417708
316417708
316417005
316417005
316417005
316259206
316259206
316259206
316417600
316417600
316417600
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEFL79D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire FEFL79D

Summary of Contents for Frigidaire FEFL79D

  • Page 1 316417005 316417005 316259206 316259206 316259206 316259206 316417600 316417600 316417600 316417600 30-INCH FREE- STANDING ELECTRIC RANGE Model No. FEFL79D Publication No. 5995417895 04/10/05 (EN/SERVICE/ECL) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved. FEFL79DSB 30" f/s elec white 316417708 316417005...
  • Page 2 Publication No: 5995417895 FEFL79D BACKGUARD 10/04...
  • Page 3 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FEFL79D BACKGUARD A FEFL79D (FEFL79DBA) B FEFL79D (FEFL79DBB) C FEFL79D (FEFL79DQA) D FEFL79D (FEFL79DQB) E FEFL79D (FEFL79DSA) F FEFL79D (FEFL79DSB) DESCRIPTION A B C D E F Shield, backguard, rear wall...
  • Page 4 Publication No: 5995417895 FEFL79D BODY 10/04...
  • Page 5 316203500 89 # 316415400 316404100 # Functional Parts * Non-Illustrated Parts FEFL79D BODY A FEFL79D (FEFL79DBA) B FEFL79D (FEFL79DBB) C FEFL79D (FEFL79DQA) D FEFL79D (FEFL79DQB) E FEFL79D (FEFL79DSA) F FEFL79D (FEFL79DSB) DESCRIPTION A B C D E F Panel, main back...
  • Page 6 Publication No: 5995417895 FEFL79D BODY 10/04...
  • Page 7 316021132 316089500 5303271648 5303285179 5308014215 # Functional Parts * Non-Illustrated Parts FEFL79D BODY A FEFL79D (FEFL79DBA) B FEFL79D (FEFL79DBB) C FEFL79D (FEFL79DQA) D FEFL79D (FEFL79DQB) E FEFL79D (FEFL79DSA) F FEFL79D (FEFL79DSB) DESCRIPTION A B C D E F Cover, fan...
  • Page 8 Publication No: 5995417895 FEFL79D TOP/DRAWER 10/04...
  • Page 9 316021105 316021108 316021109 316021110 5308014215 # Functional Parts * Non-Illustrated Parts FEFL79D TOP/DRAWER A FEFL79D (FEFL79DBA) B FEFL79D (FEFL79DBB) C FEFL79D (FEFL79DQA) D FEFL79D (FEFL79DQB) E FEFL79D (FEFL79DSA) F FEFL79D (FEFL79DSB) DESCRIPTION A B C D E F Drawer, utility...
  • Page 10 Publication No: 5995417895 FEFL79D DOOR 10/04...
  • Page 11 316433603 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FEFL79D DOOR A FEFL79D (FEFL79DBA) B FEFL79D (FEFL79DBB) C FEFL79D (FEFL79DQA) D FEFL79D (FEFL79DQB) E FEFL79D (FEFL79DSA) F FEFL79D (FEFL79DSB) DESCRIPTION A B - - - - Trim kit-door, 3 sided, black, w/tape...

  • Page 12: Wiring Schematic

    Publication No: 5995417895 FEFL79D WIRING SCHEMATIC 10/04...

  • Page 13: Wiring Diagram

    FEFL79D Publication No: 5995417895 WIRING DIAGRAM 10/04 # Functional Parts * Non-Illustrated Parts...
