convertible
car seat
0 8
FROM
TO
MONTHS
Illustrations and designs may vary.
IMPORTANT: KEEP THIS BOOKLET IN THE PLACE
PROVIDED ON THE CHILD RESTRAINT.
motherschoice.com.au
MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 1
MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 1
PLEASE USE THIS HIGH RESOLUTION PROOF AS A GUIDE FOR
HOW WE WANT THE COLOURS TO APPEAR. THIS ARTWORK HAS
NOT BEEN TRAPPED. PRINTER IS REQUIRED TO CARRY OUT ANY
NECESSARY TRAPPING. THE CONFIGURATION AND OVERALL
APPEARANCE OF THIS PRODUCT AND ITS PACKAGING IS
COPYRIGHT PROPERTY OF DOREL AUSTRALIA.
*
#
YEARS
BRAND:
Mothers Choice
PRODUCT:
Infinity
ITEM NUMBER:
19994 | 20054 | 20026
MATERIAL:
White Satin paper stock - 100-150gsm Preferred
DATE
12/05/2021
INSTRUCTION
*
#
Rearward-facing
DOREL ARTWORK PRINT SPECIFICATIONS
VERSION
DESIGNER
FA
Owen
MANUAL
Forward-facing
Service
ARTWORK SIZE:
(W) 148mm x (H) 210mm
NUMBER OF COLOURS: 4
CMYK
APPROVED BY
MARKETING DEPT
PRODUCT DEPT
OPTS DEPT
12/5/21 3:06 pm
12/5/21 3:06 pm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mother's Choice Infinity
Summary of Contents for Mother's Choice Infinity
- Page 1 BRAND: ARTWORK SIZE: Mothers Choice (W) 148mm x (H) 210mm PRODUCT: NUMBER OF COLOURS: 4 Infinity ITEM NUMBER: 19994 | 20054 | 20026 CMYK PLEASE USE THIS HIGH RESOLUTION PROOF AS A GUIDE FOR APPROVED BY HOW WE WANT THE COLOURS TO APPEAR. THIS ARTWORK HAS NOT BEEN TRAPPED.
-
Page 2: Before You Start
before you start Thank you for purchasing this child seat. This product is suitable for newborn to children approximately 8 years old. We welcome you as a valued customer, and trust that your child will enjoy many years of comfort and safety. No child restraint can guarantee absolute protection from a crash. -
Page 3: Product Registration
product registration mother’s choice tip... Visit us online to register your new Mother’s Choice product. www.motherschoice.com.au/product-registration Benefits of Registration • Your safety - allows us to contact you with important product notifications. • Confirmation of ownership - provides a record in case of product loss or theft. - Page 4 WARNINGS Read and follow all of the installation instructions for maximum protection. If you have any questions regarding the installation or use of this child restraint in Australia or New Zealand, please contact our customer service number provided. An alternative option is to also contact any registered child fitting station authorised by your local transport authority.
- Page 5 WARNINGS • This child restraint is not approved • TO BE USED WITH A LAP-SASH/LAP- for use with any connectors that ONLY SEATBELT IN THE FRONT/BACK connect to the car’s ISOFIX low OF MOST CARS WITH FORWARD anchorages. FACING SEATS. •...
-
Page 6: Visual Guide
contents Before You Start Product Registration Product Warnings What’s in The Box Components List 10-11 Suitability Guide 12-13 VISUAL GUIDE Rearward Facing 14-18 Removing the Inserts 16-17 Adjusting the Seat For Fitment Rearward-Facing Installation 19-24 Forward Facing Removing the Inserts 21-23 Adjusting the Seat for Fitment Forward-Facing Installation... - Page 7 DETAILED GUIDE 25-26 Correct in-Car Positions 27-28 Connecting the Top-Tether 29-32 Anchor Fitting Installation 33-34 Correct Seat Installation Angle Shoulder Height Markers 35-36 Fastening the Buckle Configuring Seat for Child Fitment 38-42 Recline Adjustment Pre-Installation Fitment Checklist Adjusting the Top-Tether Rearward-Facing Installation 46-48 Forward-Facing Installation...
-
Page 8: What's In The Box
Machine Washable on Lukewarm Setting - Delicate Cycle 535mm DO NOT BLEACH DO NOT DRY CLEAN DO NOT IRON infinity Tumble Dry: 10 - 15 minutes on low DOREL AUSTRALIA PTY. LTD. 655-685 Somerville Road, THIS CHILD RESTRAINT COMPLIES WITH Sunshine West VIC 3020 570mm E: customerservice@dorel.com.au... -
Page 9: What's Included
What’s Included: 1 Car Seat 1 Instruction Manual 1 Swing Tag 1 Features Card 1 Anchor Bolt Kit Suitable from Birth to 8 years of age. LEGAL POP: NON-ISO MOTHER’S CHOICE TAG CHECK THAT THIS Most compact 0-8 seat* in Australia! CHILD RESTRAINT Best for compact vehicles, providing WILL FIT IN YOUR CAR... -
Page 10: Components List
components list Body Insert Adjustable Headrest Belt Path Opening Air Protect Cell (x2) 10. Centre Front Adjuster Headrest Insert (under cover) Belt Mates (x2) 11. Seat Base Harness Holders 12. Adjuster Strap Harness 13. Base Recline Adjuster Buckle 14. Headrest Adjuster Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 10 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 10... - Page 11 20. Splitter Plate (under cover) 15. Top Tether Strap 21. Recline Position Label 16. Top Tether Strap Adjuster 22. Rearward Facing Belt Path Label 17. Top Tether Storage Pocket 23. Forward Facing Belt Path Label 18. Instruction Manual Storage Pocket 24.
- Page 12 suitability guide Rearward Facing: 0 - 30 months old See page 14-18 for visual guide See page 35-48 for detailed guide Between Mode: 12 - 30 months old Choosing the best mode for your child See page 13 Rearward-Facing Forward-Facing Forward Facing: 12 months - 8 years old See page 19-24 for visual guide...
- Page 13 Considerations for Rearward or Forward Facing: • Extended rearward facing is the safest option for your child, providing them with additional head, neck and back support for long drives, whilst also removing more force and trauma from the child in the unfortunate event of an accident. •...
- Page 14 rearward-facing quick guide 0 - 12 months 12 - 30 months Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 14 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 14 12/5/21 3:06 pm 12/5/21 3:06 pm...
-
Page 15: Removing The Inserts
removing the inserts PULL PULL PRESS PRESS NOTE: Body insert can be used in isolation to headrest insert. Inserts can only be used when rearward facing. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 15 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 15 12/5/21 3:06 pm 12/5/21 3:06 pm... -
Page 16: Recline Adjustment
recline adjustment SWING SWING SWING LIFT LIFT LIFT SQUEEZE SQUEEZE SQUEEZE NOTE: Only use recline position 4 for rearward facing mode. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 16 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 16 12/5/21 3:06 pm 12/5/21 3:06 pm... - Page 17 harness and headrest adjustment PULL PULL PULL PRESS PRESS SQUEEZE SQUEEZE SQUEEZE LIFT LIFT LIFT NOTE: Position child in seat and adjust headrest and harness to be level with shoulders or slightly above but not below. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 17 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 17 12/5/21 3:06 pm...
-
Page 18: Rearward-Facing Installation
rearward-facing installation Newborn up to 30 Months Approx. Recline Setting 4 CLICK CLICK CLICK Thread Through to Opposing Side Connect Top-Tether And Pull Slack to Adjuster Side of Seat PUSH PUSH PUSH PULL PULL PULL Twist & Position Adjuster Facing Out Pull Out Vehicle Belt Slack to Tighten Tighten to Remove all Slack... - Page 19 forward-facing quick guide 12 months - 8 years Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 19 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 19 12/5/21 3:06 pm 12/5/21 3:06 pm...
- Page 20 removing the inserts PULL PULL PRESS PRESS NOTE: Inserts are not to be used when forward facing. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 20 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 20 12/5/21 3:06 pm 12/5/21 3:06 pm...
- Page 21 recline adjustment SWING SWING SWING LIFT LIFT LIFT SQUEEZE SQUEEZE NOTE: Recline position 1, 2 or 3 can be used forward-facing but never use position 4. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 21 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 21 12/5/21 3:06 pm 12/5/21 3:06 pm...
- Page 22 adjusting the buckle height PUSH PUSH PUSH PULL PULL PULL To Extend Push & Pull at the Same Time PULL PULL PULL To Shorten NOTE: Do not use the buckle height adjuster to loosen the harness. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 22 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 22 12/5/21 3:06 pm...
- Page 23 harness and headrest adjustment PULL PULL PULL PRESS PRESS SQUEEZE SQUEEZE SQUEEZE LIFT LIFT LIFT NOTE: Place child in seat and adjust headrest and harness to be in the position closest to level with the childs shoulders. Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 23 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 23 12/5/21 3:06 pm...
-
Page 24: Forward-Facing Installation
forward-facing installation 12 Months up to 8 Years Approx. Thread through to opposing side Select Recline 1,2 or 3 CLICK CLICK PULL OUT PULL OUT SLACK SLACK PULL TO PULL TO TIGHTEN TIGHTEN Connect Top-Tether and Pull Slack to Adjuster Side of Seat PULL OUT PULL OUT SLACK... -
Page 25: Correct Rearward Facing Vehicle Position
correct in-car positions Correct Rearward Facing Vehicle Position Some seating positions in your vehicle may NOT be safe for this safety seat. Some vehicles do not have any seating positions that can be used safely with the seat. If you are not sure where to place the infant seat in your vehicle, consult your vehicle’s owner’s handbook. -
Page 26: Correct Forward-Facing Vehicle Position
correct in-car positions Correct Forward-Facing Vehicle Position CORRECT CORRECT INCORRECT Mother’s Choice | convertible car seat 0-8 years MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 26 MCh_INFINITY_19994_20054_20026_IM_FA_2.indd 26 12/5/21 3:06 pm 12/5/21 3:06 pm... - Page 27 connecting the top-tether Location of Top-Tether Anchorage Point NOTE: The anchor point can be found in different locations in different cars. The illustration above shows possible locations of anchor points. Sometimes it is on the parcel shelf in sedans, and on the floor area in station wagons, vans and hatchbacks.
- Page 28 connecting the top-tether Vehicle information Vehicle information Checking for Correct Connection Vehicle information Vehicle information Anchorage fitment check Anchorage fitment check Anchorage fitment check Anchorage fitment check Child restraints must be used correctly to provide proper protection for your child. Child restraints must be used correctly to provide proper protection for your child.
-
Page 29: Anchorage Fitting Installation
anchorage fitting installation For Cars fitted with a Child Restraint Upper Anchorage Point Locate the upper anchorage point behind the rear seating position (consult the car owner’s handbook for the location of the upper anchorage point). Remove the thread plug from the parcel shelf/floor/roof and install the attachment bolt as shown in Figure 1. - Page 30 anchorage fitting installation For Cars not Fitted With a Child Restraint Upper Anchorage Point For Sedans Only Drill a 9mm diameter hole in the parcel shelf on the centre-line of the seating position as shown in Figure 2. FOR SEDANS ONLY: 200mm min.
- Page 31 Install the anchor bolt as shown in Figure 3. It is recommended that this installation be carried out by a child restraint fitting station or licensed motor mechanic. ATTACHMENT BOLT ANCHOR FITTING SPACER(S) (IF REQUIRED) VEHICLE TRIM VEHICLE METAL STRUCTURE REINFORCING WASHER LOCK WASHER...
- Page 32 WARNINGS • CHILD RESTRAINTS MUST NOT BE ATTACHED TO UNSOUND METAL OR TO WOOD OR SYNTHETIC STRUCTURES. WHEN DRILLING THE 9mm HOLE DO NOT DRILL THROUGH FUEL LINES, FUEL TANKS, ELECTRICAL WIRING, OR RADIO SPEAKERS. WEBBING STRAPS MUST BE PROTECTED FROM SHARP CORNERS AND EDGES. •...
- Page 33 correct seat angle All vehicle seats are different which may position the child restraint too upright or reclined for the child’s comfort. The diagram below indicates the recommended installation angle range of child restraints specific to this manual. The child restraint’s backrest angle should not exceed 55°...
- Page 34 WARNINGS • DO NOT install convertible child restraints excessively reclined. • DO NOT adjust harness or tether strap hardware such that it sits too close to the occupant. • Ensure that correct seatbelt path is used and that the restraint is installed in the correct direction for rearward facing application refer to page 11.
- Page 35 SHOULDERS MUST BE ABOVE THIS LINE shoulder height markers SHOULDERS MUST BE BELOW THIS LINE MUST BE REAR FACING WHEN UPPER HEIGHT MARKER (A) SHOULDERS BELOW THIS LINE SHOULDERS MUST BE ABOVE THIS LINE SHOULDERS BELOW THIS LINE WHEN MIDDLE HEIGHT MARKER (B) LOWER HEIGHT MARKER (C) HEADREST AT HIGHEST POSITION 2010-2013...
- Page 36 WARNINGS • Continue to use this child restraint until the child reaches the Upper Height Marker. • Do not use forward facing until child’s shoulders are above the lower shoulder height marker. • Infants are at risk of serious injury if they face forward too early. •...
-
Page 37: Fastening The Buckle
configuring seat for child fitment fastening the buckle PRESS PRESS To release, press the red button to unfasten the buckle. To fasten, insert one buckle tongue as shown in image. You will not hear a “click”. Insert the second buckle tongue as shown. - Page 38 configuring seat for child fitment Adjusting the Harness Fitment: To loosen, push-down on the PULL PULL PULL harness release lever at the front of the seat and pull the shoulder straps. To tighten, pull on the adjuster strap at the front of the seat. For tightening tips, see page 40.
- Page 39 Removing the Body Insert: Loosen the harness as per page 38. Release the buckle assembly by pressing the red button and pull the buckle tongues over the side of the seat, looping them through the elastic holders (image A). Pull each side wing of the insert through the harness straps as shown (image B).
- Page 40 configuring seat for child fitment Tightening the Harness: Before pulling on adjuster strap to tighten harness, pull on harness shoulder straps first to remove slack from the waist area. Once slack is removed, pull on adjuster strap so that the harness fitment over the shoulders is firm.
- Page 41 buckle height adjustment When adjusting the buckle height, it should be positioned on the lower abdomen of the child when fastened. As your child grows, this will need to be adjusted accordingly. CORRECT POSITION This adjustment can be completed in the car so there is no need to undo your installation.
-
Page 42: Rearward-Facing
configuring seat for child fitment rearward-facing (Newborn to approximately 30 months) The shoulder straps must be in the slots which are nearest to the child’s shoulders, but not lower than the child’s shoulders. Shoulder strap forward-facing (12 months to 8 years) Strap can be next The shoulder straps must slot above... - Page 43 recline adjustment The seat is fitted with 3 forward- facing recline positions. The 4th and most reclined position is for rearward-facing use ONLY. Place hand under seat and squeeze the red recline handle. Whilst squeezing, tilt the seat back gently to recline. Release the handle when desired mode is reached.
-
Page 44: Checklist Before Installation
checklist before installation Rearward-Facing Check that your child’s upper shoulders are NOT above the middle height marker and if they are, convert to forward facing. Harness height is level or above shoulder but not below. Rearward facing recline setting 4 is selected. Crutch buckle is adjusted to sit over child’s lower abdomen. - Page 45 Adjusting the top-tether strap PUSH PUSH PULL PULL BUTTON BUTTON PULL PULL To Loosen: To Tighten: Press on the adjuster button with thumb Adjust top tether strap and remove slack. and pull strap back the adjuster. Pull loose end of strap to tighten. NOTE: Store the excess webbing in the pocket provide on the side of the child restraint.
-
Page 46: Rearward-Facing Installation
rearward-facing installation Adjust the restraint into recline RECLINE SETTING 4 position four (full recline) for rearward facing as shown in image A. Place the restraint facing rearwards on either of the back vehicle seats, centred and in line with a top tether anchorage point. - Page 47 Loosen top-tether strap and connect the anchor clip to the anchor point as shown in image H. Please note, you will need to remove the anchor bolt kit from the anchor clip if the seat is straight out of the box. Check to ensure there are no twists in the top-tether belt path as Twist &...
- Page 48 rearward-facing installation 10. To tighten the installation, begin by pushing down into the car seat with PUSH PUSH PUSH one hand using maximum force whilst simultaneously pulling up on the vehicle seatbelt, feeding it back into the retractor as shown in PULL PULL PULL...
-
Page 49: Forward-Facing Installation
forward-facing installation Adjust the restraint into upright or SELECT POSITION 1, 2 OR 3 recline, by positioning the seat into either position 1, 2 or 3 as shown in image A. Loosen top-tether strap, enough to position the clip away from the back cover. - Page 50 forward-facing installation Connect the anchor clip to the anchor point as shown in images E and F. Please note, you will need to remove the anchor bolt kit from the anchor clip if the seat is straight out of the box. Check to ensure there are no twists in the top-tether belt path as shown in image F.
- Page 51 10. To tighten the installation, begin by pushing down into the car seat with one hand using maximum force whilst simultaneously pulling up on the vehicle seatbelt, feeding the belt slack into the retractor as shown in image I. Continue this step until the installation is as firm as possible.
-
Page 52: Cleaning The Buckle
cleaning the buckle Follow the manufacturer’s instructions at all times. Your child car seat is equipped with a buckle designed to give your child maximum protection during proper use. When working properly, your buckle should always fasten with an audible ‘CLICK’ when both tounges are engaged. If sticky liquids (such as baby food, fruit juice, etc.) get into the buckle it may become sluggish and you will not hear a ‘CLICK’. - Page 53 seat fabrics WASHING INSTRUCTIONS Do not dry clean Lukewarm setting Tumble dry - delicate cycle 10-15 minutes on low heat Never clean with bleach All other surfaces should be cleaned with or spirit-type cleaners a mild soap and water VERY IMPORTANT: Only replace the cover with a manufacturer’s supplied replacement cover with identical shoulder height markers or a replacement cover meeting AS/NZS 8005.
- Page 54 removing the seat fabrics Removing the Head and Body Inserts Remove the head and body inserts as needed - referring to the detailed sections found on page 39. Removing the Harness Pads Each harness pad has two press studs on the external edge. Locate the press studs and release them to unwrap each pad from the harness straps.
- Page 55 Removing the Backrest Fabrics Adjust the headrest into the highest position (see detailed section on page 38). Release the ten exterior press studs connecting the trim to the physical backrest as shown in images G, H and I (repeat for both sides).
- Page 56 removing the seat fabrics Reattaching the Fabrics Pieces To reattach each seat fabric piece, repeat the removal process in reverse order. Please see the below for some tips to help achieve the best result. Headrest: • Ensure the elastic cords are threaded behind the plastic headrest tabs prior to attaching the backrest trim panel to the headrest as shown in image M.
-
Page 57: Troubleshooting
troubleshooting Twisted Harness If you notice your car seat’s harness has a twist in it like shown in image A, follow the steps below to identify the type of twist and how to fix it. Identifying the Type of Twist: There are two types of harness twist, a single twist on the upper shoulder strap and a double twist, split around the buckle tongue. - Page 58 troubleshooting Double Twist: For the double twist to occur, the buckle tongue must have been slid over a twist in the belt. To undo this, the process must be reversed. Using the strap section below the buckle tongue, twist the strap so it appears flat before entering the buckle tongue slot.
- Page 59 the next seat for your child When your child has outgrown this child car seat, you can either use a booster or the vehicle seat if your child is ready. NOTE: This illustration is representative only. If using a larger booster seat it must be suitable for children up to 8-10 years of age, until their shoulders reach the upper height marker.
