ILS: INDUSTRIAL LASER

SYSTEM

INSTRUCTION MANUAL

WARNING!

The laser light emitted by this unit may be in the infrared (non-visible) region of the electromagnetic

spectrum. Avoid Exposure to direct or scattered radiation from the laser. Use extreme caution at all times

when the laser is in use.

The output power of these laser devices is sometimes high enough to cause permanent damage to the

human eye. You should wear appropriate laser safety goggles at all times when the laser is operational.

All laser safety warning labels are provided on the unit and be taken into note. Warning labels comply

with IEC 60825-1

STRUCTURED LIGHT AND

LASER BEAM SHAPING SOLUTIONS

Table of Contents

Need help?

Do you have a question about the ILS and is the answer not in the manual?

Questions and answers

Summary of Contents for OSELA ILS

Page 1 STRUCTURED LIGHT AND LASER BEAM SHAPING SOLUTIONS ILS: INDUSTRIAL LASER SYSTEM INSTRUCTION MANUAL WARNING! The laser light emitted by this unit may be in the infrared (non-visible) region of the electromagnetic spectrum. Avoid Exposure to direct or scattered radiation from the laser. Use extreme caution at all times when the laser is in use.
Page 2 OPERATING THE LASER The Laser requires 12-24VDC, 1.5A and up to 2A at the extremes of the temperature range • (white lead =12-24VDC, black = Gnd). After a few seconds, assuming normal ambient temperature, the LED will be lit green and the laser will begin •...
Page 3 DB9 INTERFACE A DB9-RA-SMT-Socket-Female is provided to interface with the laser. Laser diode temperature temperature Internal temperature Optical Power monitor External Key + Diode current monitor External Key - Modulation Interlock Ground Safety interlock: A safety feature option of the laser where the laser will not function if the circuit (Pin1-Pin6) is open Modulation: The laser can be modulated in intensity and/or frequency by applying an external voltage (0 to 5V = 100% to 0% linear intensity modulation) on Pin 2 of the DB9 connector.
Page 4 DIODE TEMPERATURE MONITORING diode temperature [degC] OPERATING ENVIRONMENT The lasers operating temperature range is from -10°C to 50°C. In order to prevent the diode from being damaged, there is built in over-temperature protection which will prevent lasing. Once the laser detects that the temperature has dropped within the safe threshold, it will begin to lase again automatically.
Page 5 FOCUSING THE LASER The laser can be focused with the aid of a 1/16” dowel pin and L5/64 hex wrench enclosed with the laser. To refocus the laser you must remove black plastic protective sealer cap that protects the focus Protective set screw from dust and debris.
Page 6 LASER SAFETY AVIOD EXPOSURE TO DIRECT OR SCATTERED RADIATION FROM THE LASER. It is extremely important to follow laser safety and wear appropriate eyewear when working around lasers. Do not shine laser in the direction of other people or at reflective surfaces that might cause exposure to the human eye.
Page 7 Removal of the laser safety sticker renders warranty null and void. All returns require a Return Merchandise Authorization number (RMA#). This number can be obtained by contacting Osela or the distributor from which the unit was purchased.
Page 8 0.675 ±0.005 4.375 ±0.005 17.14 ±0.13 111.12 ±0.13 0.975 ±0.015 0 ±0.015 24.76 ±0.38 8 ±0.38 1.115 ±0.010 28.32 ±0.25 0.230 REF. 5.84 5.725 ±0.015 145.42 ±0.38 osela.com OSELA inc. 1869 32 Avenue, Lachine, QC, H8T 3J1 Canada info@osela.com 514 631.2227...
