- Page 1 SAT405 CLIP HEAD NAILER OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: Specification
SPECIFICATION TOOL MODEL SAT405 MAXIMUM OPERATING PRESSURE 115 PSI RECOMMENDED OPERATING PRESSURE 75-100 PSI MAGAZINE CAPACITY 80 NAILS FASTNER GAUGE 2.8-3.8 MM FASTNER LENGTHS NAILS (MM) 50-90 MM SAFETY GUIDELINES Indicates an immediately hazardous situation which if not DANGER avoided will result in death or serious injury. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS 1. Read and understand tool labels and manual. Failure to follow warnings could result in DEATH or SERIOUS INJURY. 2. Operator and others in work area MUST wear safety glasses. 3. Keep fingers AWAY from trigger when not driving fasteners to avoid ac- cidental firing. -
Page 4: Safety Mechanism
The tool must not cycle. Never use the tool if a cycle occurs. Hold the tool clear of the work-piece. The WCE should return to its original down position. Pull the trigger. The tool must not cycle. Never use the tool if a cycle occurs. WWW.SGS-ENGINEERING.COM PAGE 4... -
Page 5: Loading The Tool
LOADING THE TOOL Connect the air hose. Depress the magazine latch. Pull back on the magazine cover. Insert a stick of fasteners into the magazine. Make sure the pointed ends of the fasteners are loaded with the points downward. Also make sure fasten- ers are not dirty or damaged. - Page 6 A filter also increase the efficiency and lifespan of the tool. The filter must be checked on a daily basis and if necessary drained. CORRECT CONNECTION OF THE TOOL WWW.SGS-ENGINEERING.COM PAGE 6...
-
Page 7: Clearing A Jam From The Tool
CLEARING A JAM FROM THE TOOL Fig.1 1. Remove any remaining fasteners from the nailer. Fig.2 A. Pull nail pusher all the way to the rear until it latches (Fig.1). B. Slide fasteners to the rear and remove from magazine (Fig.2). 2. -
Page 8: Parts Diagram
PARTS DIAGRAM WWW.SGS-ENGINEERING.COM PAGE 8... -
Page 9: Parts List
PARTS LIST PAGE 9... -
Page 10: Troubleshooting
Incorrect fasteners. Verify fasteners of correct size. frequently. Damaged fasteners. Replace fasteners. Magazine or nose screw Tighten screws. loose. Magazine is dirty. Clean screws. Driver is worn or damaged. Install Driver maintenance kit. Other Contact SGS Engineering. WWW.SGS-ENGINEERING.COM PAGE 10... - Page 11 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd AIR TOOL - Clip Head Nailer TYPE OF EQUIPMENT: SAT405...
