AKW MediCare 2000 Series User & Care Manual

::bathroomsource.com
Color: White to RAL 9016 / Gray to RAL 7035
Shower Seat Use
The Shower Seat must only be used for the tasks it is intended to perform.
Do not stand on it or misuse it. This may have serious detrimental effects
on its performance and safety.
The Shower Seat should be checked as part of a planned maintenance
program.
Children and other users may require supervision when using this product.
Keeping your AKW Shower Seat Clean
This product should be cleaned periodically to remove any accumulation
of hair or other waste material, using normal domestic bathroom cleaning
materials. After cleaning always flush down with water then wipe
thoroughly with a damp cloth to remove any cleaning material residues
before drying off.
Disinfecting
Where disinfecting is necessary, standard established procedures for disinfecting equipment should be used
with due care and attention taken of the warnings concerning possible effects of aggressive chemicals on plastics.
After cleaning always flush down with water then wipe thoroughly with a damp cloth to remove any cleaning material
residues before drying off.
Do not use strong or concentrated acidic, alkaline or other cleaning materials as these may discolor or damage the product.
AKW does not approve or recommend autoclave cleaning due to the damage this can cause to the special engineering
plastics used in the construction of this product.
Packaging
This Shower Seat is supplied in a polypropylene (PP) bag to keep the product unsoiled until installation; it may also be
packed in a cardboard box.
Both are suitable for recycling operations and should be disposed of in accordance with local recycling regulations.
Cushion Assembly
1. Fit seat cushion to seat.
Note the front of the cushion
as indicated.
2. The seat cushion retainer is
fitted from underneath the
seat.
Each cushion tab
has a retainer (4 in total)
Call 1-800-667-8721 anywhere in the US and Canada -
AKW MediCare
2000 Series Seats (02130/P, 02230P)
User care instructions
Fig.1
AKW MediCare at bathroom
3. To fit retainer, it should be
rotated in a clockwise
direction whilst applying
firm pressure towards the
seat.
The seat cushion may need
to be held in position
whilst the retainer is
fastened.
4. The retainer should be
tightened until it is no
longer possible to lift or
move the seat cushion.
Be careful not to
overtighten the retainer.
accessories
::
U N L I M I T E D
www.bathroomsource.com
Internal Building use only
Covered by one or
more of the following
Reg Designs:
GB 3011017, EU 000548607
USA 29/249106
Pat apps:
USA 11/456352, EU 06253480
Fig.2
