PowerBright XC180 Owner's Manual

Direct plug-in inverter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

WARNING:

This Unit employs Components that tend to produce arcs or sparks – To

prevent fire or explosion, do not install in compartments containing

batteries or flammable materials - SHOCK HAZARD. DO NOT OPEN.

CAUTION:

OUTPUT NON-SINUSOIDAL REFER TO MANUAL - Provided with integral

protection against overloads. To prevent fire, do not cover or obstruct

ventilation openings. Do not mount in Zero-Clearance compartment.

Overheating may result.

Notice :

The output of this device is not sinusoidal. It has a total harmonic distortion

of 30% percent and maximum single harmonic of 8 percent

Toll Free 1 866 295 6775

www.PowerBright.com

Printed in China

XC120

XC180

Owner's Guide

Conforms to / Conforme à UL std. 458,

CSA std. C22.2 No. 107.1

Table of Contents

Need help?

Do you have a question about the XC180 and is the answer not in the manual?

Questions and answers

Summary of Contents for PowerBright XC180

Page 1 Notice : The output of this device is not sinusoidal. It has a total harmonic distortion of 30% percent and maximum single harmonic of 8 percent XC120 XC180 Toll Free 1 866 295 6775 Owner's Guide www.PowerBright.com Conforms to / Conforme à UL std. 458, Printed in China CSA std.
Page 2: Important Safety Information
1 Introduction ® Thank you for purchasing the PowerBright XC120/180 Connected to the 12 volt outlet in your vehicle, the XC120/180 efficiently and reliably powers a wide variety of loads through both the AC outlet and USB port. Read this guide before connecting or using the and save it for future reference.
Page 3 Warnings and Cautions housing may become XC120/XC180 uncomfortably warm, reaching 140° F (60° C) under extended high power operation. During operation, keep it away from materials that may be affected by high temperatures. XC120/XC180 Do not use the in the presence of flammable fumes or gases, such as in the bilge of a gasoline powered boat, or near propane tanks.
Page 4 CAUTION: Risk of Fire. Do not replace any vehicle fuse with a rating higher than recommended by the Vehicle Manufacturer. Ensure that the electrical system in your vehicle can supply this product without causing the vehicle fusing to open. Information on the vehicle fuse rating is typically found in the vehicle operator’s manual.
Page 5 CAUTION: Output non-sinusoidal Some chargers for small nickel-cadmium batteries XC120/XC180 can be damaged if connected to the Do not use the inverter with the following appliances: • Small battery-operated appliances like rechargeable flashlights, some rechargeable shavers, and night lights that are plugged directly into an AC receptacle to recharge.
Page 6: Additional Safety Guidelines
Additional Safety Guidelines • Do not insert foreign objects in the outlets or other openings. XC120/XC180 • Never connect the inverter to power utility AC distribution wiring. • Do not use the in temperatures XC120/XC180 over 100° F (40° C).
Page 7: Inverter Features
4 Inverter Features PowerBright® XC120/180 USB port 2.1 Amp (shared) AC Outlet LED Light DC Connector indicator Ventilation openings...
Page 8: Using The Inverter
5 Using the Inverter XC120/180 Through its AC outlet, the is capable of powering most 120V AC products that use 120W/180W or less. The XC120/180 can also power or charge most consumer electronics that have USB power ports. XC120/180 AC output waveform, called “modified sine wave”...
Page 9 Plug a DC cable into the DC cable port on the XC120/180 and connect to a 12V cigarette lighter receptacle. Plug the device you want to operate into the XC120/180 When the inverter is not in use, unplug it from the 12V outlet to prevent slight discharge of the battery.
Page 10: Inverter Operation
6 Inverter Operation When properly connected to a 12V outlet, the light will glow GREEN, indicating the inverter is ready. Plug the product(s) you want to operate into the AC outlet or USB port and switch them on (if necessary). Operating Guidelines •...
Page 11 Important: Vehicle batteries are designed to provide brief periods of very high current needed for engine starting. They are not intended for constant deep discharge. Regularly operating the XC120/180 from a vehicle battery until low-voltage shutdown occurs will shorten the life of the battery.
Page 12: Battery Operating Time
16 V. • In the event of an overload, low battery voltage or overheating, the XC120 / XC180 automatically shuts down. Battery Operating Time Operating time will vary depending on the charge...
Page 13: Interference With Electronic Equipment
/180. Generally, the only solution is an audio product with a higher quality filter. Television interference The XC120 / XC180 is shielded to minimize its interference with TV signals. However, with weak TV signals interference may be visible in the form of lines scrolling across the screen.
Page 14: Troubleshooting
7 Troubleshooting PROBLEM: AC product will not operate, no inverter lights are Possible cause Solution Battery is defective. Check battery and replace if required. Loose connections. Check connections. PROBLEM: Measured inverter output is to o low. Possible cause Solution Standard “average- Inverter’s “modi ed sine reading”...
Page 15 Possible cause Solution Battery voltage is too low. Recharge battery. PROBLEM: AC product will not operate, RED FAULT light ON. Possible cause Solution AC product(s) connected Use a product with a power are rated at more than the rating less than the inverter’s inverter’s continuous continuous power rating.
Page 16: Ac Power Output
Specifications are subject to change without notice. AC Power Output XC120 0 XC180 AC output voltage (nominal) 115VAC/60Hz 120W 115VAC/60Hz 180W Continuous AC output power 120W 180W AC output waveform Modified sine wave Maximum AC output surge power 360W 240W AC output frequency 60 ±...
Page 17 DC Power XC120 XC180 DC input voltage range (VDC) 13.8V DC, 10A Max 13.8V DC, 15A Max Battery drain with no AC load 0.4A 0.4A (at 12 V input) Efficiency (maximum) Low voltage shutdown point (nominal) 10.5V+ 0.5V 10.5V+ 0.5V...
Page 18: Warranty And Return
You require proof of purchase to make warranty claims. What will PowerBright do? PowerBright will, at its option, repair or replace the defective product free of charge, provided that you notify PowerBright of the product defect...
Page 19 PowerBright. PowerBright covers both parts and labor necessary to repair the product, and return shipment to the customer via a PowerBright selected non-expedited surface freight within the contiguous United States and Canada.
Page 20 This warranty does not apply to, and PowerBright will not be responsible for, any defect in or damage to: the product if it has been misused, neglected, improp-...
Page 21 SHOULD NOT BE USED IN CONNECTION WITH LIFE SUPPORT SYSTEMS OR OTHER MEDICAL EQUIPMENT OR DEVICES. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, POWERBRIGHT MAKES NO REPRESENTATIONS OR WARRANTIES XC120/180 REGARDING THE USE OF THE POWERBRIGHT IN CONNECTION WITH LIFE SUPPORT SYSTEMS OR OTHER MEDICAL...
Page 22: Return Material Authorization Policy
Return Material Authorization Policy Before returning a product directly to PowerBright you must obtain a Return Material Authorization (RMA) number and the correct factory "Ship To" address. Products must also be shipped prepaid. Product shipments will be refused and returned at your expense if they are unauthorized, returned...
Page 23: Return Procedure
This warranty will not apply where the product is damaged due to improper packaging. Include the following: • The RMA number supplied by PowerBright Technology, Inc. clearly marked on the outside of the box. • A return address where the unit can be shipped.
