OPERATING INSTRUCTION

Battery Supply

Open the battery compartment and insert as indicated in the compartment one
Rechargeable Battery, Li-ion 3.7V or 3 x AAA cells.

Battery Charging (using rechargeable battery)

Insert rechargeable battery to the unit.
Connect the unit by inserting the charging cable into DC 5V IN jack, and inserting
the other end into the USB interface or USB charger. The charging time is around
2 hours. The charging indicator will flash during battery charging.

DC Adapter

To use 5V AC/DC adapter for external DC charging, plug the connecting cable to
the DC charging port. (Voltage adapter is an optional accessory. Do not charge
the battery with the AC / DC adapter for more than 24 hours.)

IMPORTANT

If the unit has not been used for a long period of time, the rechargeable battery
may be completely discharged into a "sleep mode" condition. This is the
characteristics of all the rechargeable battery. For the first time to recharge (to
wake up) the battery, it is recommended to charge for a period exceed 5 hours but
not exceed 24 hours.

Switch On The Radio

1. Connect the unit with Li-ion 3.7V rechargeable battery or 3xAAA cells or DC
adaptor
2. Press POWER once to enter DAB / FM Mode
3. During DAB / FM mode, press POWER once to standby mode or press and
hold POWER to switch on / switch off the unit.

DAB Mode

Auto Scan

1. Adjust the antenna extension and angle to have the best reception.
2. Press POWER to switch on the unit.
3. The first time the radio is powered and switched on, it will automatically select
DAB mode and start a quick scan of the DAB channels to search for available
stations. Please leave it to complete this process.
4. Press LEFT ( ) or RIGHT ( ) to select desired station.
Note: You may have to wait for the unit to tune into the new channel.
5. Press SCAN can fully scan the available channels again.

Manual Scan

1. Hold INFO/MENU, the display shows MANUAL, then press SELECT.
2. Press LEFT ( ) or RIGHT ( ) to select desired channel (5A-13F), press
SELECT to enter the channel.
3. Select station by using LEFT ( ) or RIGHT ( )
