- Page 1 SAT110K IMPACT & RATCHET WRENCH KIT OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
- Page 2 MAX TORQUE 50 FT-LB / 69 Nm AVERAGE AIR CONSUMPTION 4 SCFM WORKING PRESSURE 90 PSI / 6.3 BAR AIR INLET 1/4 IN. AIR HOSE 3/8 IN. LENGTH x HEIGHT 263 x 53 MM WEIGHT 1.18 KGS WWW.SGS-ENGINEERING.COM PAGE 2...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS DANGER RISK OF FIRE OR EXPLOSION WHAT COULD HAPPEN HOW TO PREVENT IT Abrasive tools such as sanders and grinders, Never operate tools near flammable sub- rotating tools such as drills and impact tools stances such as petrol, naphtha, cleaning such as nailers, staplers, wrenches, hammers solvents etc. - Page 4 RISK OF CUT OR BURNS WHAT COULD HAPPEN HOW TO PREVENT IT Tools that cut, shear, drill, staple, punch & Keep the working part of the tool away chisel are capable of causing serious injury. from hands and body. WWW.SGS-ENGINEERING.COM PAGE 4...
- Page 5 Air tools can inadvertently propel fasteners Use only parts, fasteners and accessories or other materials in work area. recommended by SGS Engineering. Keep work area clean and free of clutter. Keep children and others away from tool while it is in operation.
- Page 6 If damaged, have the tool serviced and repaired before use. Use only accessories identified by SGS Use of an accessory not intended for a Engineering as suitable for use with specific specific tool increases the risk of injury to tools.
-
Page 7: Safety Guidelines
SAFETY GUIDELINES Make sure that the air compressor being used for the air tool operation sup- plies the correct output (CFM). Have the tool in the “off” position when connecting the tool to the air supply. Use normal 90 PSI (or ranging from 6.0 to 8.0kg) air pressure while running the tool. - Page 8 The tool should be lubricated daily (or before each use) with air tool oil (not in- cluded). Air tool oil is available from SGS Engineering. Do not use detergent oil. During continuous operation, the tool should be oiled every 1 to 2 hours. This may be done using an in-line oiler or manually.
- Page 9 Figure 2 Figure 3 Figure 1 Figure 4 Figure 5 Figure 6 Figure 7 PAGE 9...
- Page 10 The tool should be lubricated daily (or before each use) with air tool oil (not in- cluded). Air tool oil is available from SGS Engineering. Do not use detergent oil. During continuous operation, the tool should be oiled every 1 to 2 hours. This may be done using an in-line oiler or manually.
- Page 11 Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 PAGE 11...
-
Page 12: Troubleshooting
TROUBLESHOOTING SERVICE AND REPAIRS All quality tools will eventually require servicing or replacement of parts due to wear from normal use. These operations should ONLY be performed by a licensed profes- sional technician. Never try to repair the tool by yourself. WARNING Disconnect tool from air supply before performing any service procedure. - Page 13 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Impact & Ratchet Wrench Kit TYPE OF EQUIPMENT: SAT110K PART NUMBER:...
