KFM-200 Handheld Fiber Microscope Operation instruction
1

Front panel function description

4
1
Eyepiece: Optical fiber end face viewing window
2
Battery cover: unscrew to put the battery
3
Switch: Two different lighting modes can be selected
4
Adapter interface: including 1.25 mm and 2.5 mm
universal adapters
5
Focus knob: adjust the focus of the knob to check the
clarity of the fiber end face
2

Two lighting modes

Toggle "|" to jump to the
axial illumination, toggle "||" to
jump to the side illumination,
and toggle "o" to directly turn
off.
3

Battery cover

5
1
3
2
Fiber Connector Microscope
200
KFM-200
Fiber Connector Microscope
200
KFM-200
The first step is to unscrew
the battery cover, and the
second step is to put the battery
in, and the battery can be
replaced and used in time.
4
Holding the fiber optic
microscope with one hand, aiming
at the eyepiece with a single eye,
you can accurately check whether
the fiber end face needs to be cleaned.
5
X
6
X
Universal adapter
interface, respectively 1.25mm
and 2.5mm is appropriate
interfaces Orchestration.
Eyepiece viewing
Fiber Connector Microscope
KFM-200
Ocus knob
Fiber Connector Microscope
KFM-200
Align the eyepiece and
adjust the focal length of the
knob to clearly check the degree
of dirt on the end face.
Universal adapter
Fiber Connector Microscope
KFM-200
X
200
X
200
X
200
