PCIE-6001
Installation and Use
P/N: 6806800U73A
June 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIE-6001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Artesyn PCIE-6001

Summary of Contents for Artesyn PCIE-6001

  • Page 1 PCIE-6001 Installation and Use P/N: 6806800U73A June 2017...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    M.2 AHCI or NVME SSD Installation and Removal ........31 2.5.1 M.2 AHCI or NVME SSD module installation on the PCIE-6001 card ....31 2.5.2 M.2 AHCI or NVME SSD module removal from the PCIE-6001 Card .
  • Page 4 PCIE-6001 Card Configuration Example ........
  • Page 5 On Board LEDs ..............46 Table B-1 Artesyn Embedded Technologies - Embedded Computing Publications ....51 PCIE-6001 Installation and Use (6806800U73A)
  • Page 6 List of Tables PCIE-6001 Installation and Use (6806800U73A)
  • Page 7 Figure A-1 Configuration Example- Artesyn MaxCore System ......50 PCIE-6001 Installation and Use (6806800U73A)
  • Page 8 List of Figures PCIE-6001 Installation and Use (6806800U73A)

  • Page 9: About This Manual

    PCIE-6001 card block diagram. Controls, Indicators, and Connectors on page 41 provides information about the controls,  indicators, connectors, and pin assignments associated with the PCIE-6001 card. Appendix A, PCIE-6001 Card Configuration Example, on page 49 provides an example on ...
  • Page 10 Non-Volatile Memory Host Controller Interface Specification Solid State Drive Test Clock Test Data Input Test Data Output Thermal Design Power TFTP Trivial File Transfer Protocol Upper Critical UEFI Unified Extensible Firmware Interface Upper Non-Critical Upper Non-Recoverable PCIE-6001 Installation and Use (6806800U73A)
  • Page 11 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being. Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers). PCIE-6001 Installation and Use (6806800U73A)
  • Page 12 Indicates a property damage message. No danger encountered. Pay attention to important information. Summary of Changes This manual has been revised and replaces all prior editions. Part Number Publication Date Description 6806800U73A June 2017 Initial version PCIE-6001 Installation and Use (6806800U73A)

  • Page 13: Safety Notes

    Artesyn intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 14 Changes or modifications not expressly approved by Artesyn Embedded Technologies could void the user's authority to operate the equipment. Board products are tested in a representative system to show compliance with the above mentioned requirements.
  • Page 15 Only use appropriate tools when installing/removing the product to avoid damage/deformation to the card and/or PCB. Environment Always dispose equipment that is finally taken out of operation according to your country’s legislation and manufacturer’s instructions. PCIE-6001 Installation and Use (6806800U73A)
  • Page 16 Safety Notes PCIE-6001 Installation and Use (6806800U73A)

  • Page 17: Sicherheitshinweise

    Anwendungen in der Telekommunikationsindustrie und im Zusammenhang mit Industriesteuerungen verwendet werden. Einbau, Wartung und Betrieb dürfen nur von durch Artesyn ausgebildetem oder im Bereich Elektronik oder Elektrotechnik qualifiziertem Personal durchgeführt werden. Die in diesem Handbuch enthaltenen Informationen dienen ausschließlich dazu, das Wissen von Fachpersonal zu ergänzen, können dieses jedoch nicht ersetzen.
  • Page 18 Sicherheitshinweise Das Produkt wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten...
  • Page 19 Verwenden Sie geeignetes Werkzeug, um das Produkt zu installieren/deinstallieren. Auf diese Weise vermeiden Sie, dass das card oder die Platine deformiert oder zerstört wird Umweltschutz Entsorgen Sie alte elektronische Baugruppen stets gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. PCIE-6001 Installation and Use (6806800U73A)
  • Page 20 Sicherheitshinweise PCIE-6001 Installation and Use (6806800U73A)

  • Page 21: Introduction

    The PCIE-6001 card leverages NVMe technology, which is currently the fastest way to attach an SSD to a CPU. The PCIE-6001 card is a carrier for COTS SSD modules with M.2 form factor. M.2 modules are considered mainstream for data center and consumer market and they deliver outstanding size/price/performance ratio.

  • Page 22: Hardware Overview

    Introduction Hardware Overview The PCIE-6001 is a full-height, full-length PCIe expansion card that acts as a additional storage functionality exclusively to Artesyn MaxCore platforms. The following figure shows the mechanical layout of PCIE-6001 card. Figure 1-1 depicts length and height of the PCIE-6001 card.

  • Page 23: Standard Compliances

    EN 300 386 v1.6.1: 2012 EN 61000-4-4: 2012 EN 300 386 v1.6.1: 2012 EN 61000-4-5: 2014 Surge The PCIE-6001 card is designed to comply only with MaxCore Server. Ordering and Support Information Use the part number given in the following table, when ordering a card, supported software packages, or requesting support information.
  • Page 24 Introduction Table 1-2 Ordering Information Part Number Description PCIE-6001-4-128G Full PCIE-6001card (with four 128G SSDs installed) PCIE-6001-4-1T Full PCIE-6001 card (with four 1T SSDs installed) PCIE-6001 Installation and Use (6806800U73A)

  • Page 25: Hardware Preparation And Installation

    The environmental, thermal, and power requirements, and the installation and removal procedures of the card are also explained in this chapter. Unpacking and Inspecting PCIE-6001 Card Damage of Circuits Electrostatic discharge and incorrect installation and removal of the card can damage circuits or shorten their life.

  • Page 26: Environmental, Thermal, And Power Requirements

    Make sure the card is thoroughly inspected before shipment. If any damage has occurred during transportation please contact our Contact Center immediately. Environmental, Thermal, and Power Requirements This section contains the environmental, thermal, and power requirements of the PCIE-6001 card. PCIE-6001 Installation and Use (6806800U73A)

  • Page 27: Environmental And Thermal Requirements

    20 CFM @ 55 °C host system sea level) ambient Temperature Change +/– 0.5 °C/min +/– 1 °C/min Relative Humidity 5% to 95% non-condensing at +40 °C 5% to 95% non-condensing at +40 °C PCIE-6001 Installation and Use (6806800U73A)

  • Page 28: Power Requirements

    2.2.2 Power Requirements The PCIE-6001 payload card accepts single and double-sided modules up to a power consumption of 10W per module. The module interface must comply with the NVMe (NVMExpress) standard. In case of MaxCore platforms, the MaxCore system reads the thermal sensors and provides sufficient cooling.

  • Page 29: Weight And Dimensions

    Hardware Preparation and Installation Weight and Dimensions The following table provides weight and dimensions of PCIE-6001 card. Table 2-3 Weight and Dimensions Feature Value Height 111.15 mm (4.37 inches) Length 312.00 mm (12.28 inches) Width 14.47 mm (0.57 inches) Weight 0.14 kg (0.30 lb)

  • Page 30: Esd Prevention

    Avoid moving as much as possible. Movement gathers static electricity around you.  Do not touch the solder point, pin, or bare circuit.  Do not leave the device in the place where others can operate it.  PCIE-6001 Installation and Use (6806800U73A)

  • Page 31: M.2 Ahci Or Nvme Ssd Installation And Removal

    This section provides procedures on how to install or remove M.2 AHCI or NVME SSDs from a PCIE-6001 card. 2.5.1 M.2 AHCI or NVME SSD module installation on the PCIE-6001 card PCIE-6001 provides four (4) sets of the hardware as shown in Figure 1-1. PCIE-6001 Installation and Use (6806800U73A)
  • Page 32 Hardware Preparation and Installation To install M.2 AHCI or NVME SSD modules on a PCIE-6001 card: 1. Install M2.5 screw and standoff in the PCB hole location based on the length of the M.2 module. M2.5 screw Standoff screw 2. Install the M.2 module.

  • Page 33: Ahci Or Nvme Ssd Module Removal From The Pcie-6001 Card

    M2.5 shoulder screw 2.5.2 M.2 AHCI or NVME SSD module removal from the PCIE-6001 Card To remove M.2 AHCI or NVME SSD modules from a PCIE-6001 card: 1. Remove M.2 shoulder screw. 2. Remove M.2 module. PCIE-6001 Installation and Use (6806800U73A)

  • Page 34: Pcie-6001 Card Installation And Removal

    (For more details, refer to the section Precautions on page 29). 2. Identify the system in which the PCIE-6001 card is to be installed. 3. Remove the system cover. For detailed information about the PCIe card installation, refer to MaxCore product documentation.

  • Page 35: Pcie-6001 Card Removal

    Hardware Preparation and Installation 4. Insert the PCIE-6001 card into the PCIe slot, secure it, and ensure that the card is properly fitted in the PCIe slot. 5. Close the system cover and then power on the system. Make sure that the card has enough air flow after closing the system with the cover.
  • Page 36 Hardware Preparation and Installation 4. Remove the screw holding the front panel bracket and gently pull the PCIE-6001 card from the slot. Place the PCIE-6001 card into an ESD-protective bag and seal it appropriately. 5. Close the cover of the system.

  • Page 37: Functional Description

    The following figure depicts the functional block diagram of PCIE-6001 card. Figure 3-1 PCIE-6001 Block Diagram Power Both 3.3V and 12V power are provided to the PCIE-6001 through the PCIe gold fingers (through the +3.3V Aux and +12V rails respectfully). PCIE-6001 Installation and Use (6806800U73A)

  • Page 38: Cpld

     M.2/NGFF Card Sockets The primary purpose of the PCIE-6001 is to extend the storage capabilities of the MaxCore chassis by providing four M.2/NGFF card sockets for solid state drives. PCIE-6001 supports all standard module sizes for Socket 3 (2242, 2260, 2280 and 22110) for both single and dual-sided modules (S1-S3 and D0-D5).

  • Page 39: Temperature Sensors

    Functional Description Temperature Sensors To ensure the board will operate at safe temperatures, the PCIE-6001 has a pair of LM75A temperature sensors (at the inlet and outlet) along with an ADT7461A which provides the internal PEX die temperature. These sensors cannot be directly accessed via the upstream host processor, but can be accessed via a CPLD register.
  • Page 40 Functional Description PCIE-6001 Installation and Use (6806800U73A)

  • Page 41: Controls, Indicators, And Connectors

    PCIE-6001 Faceplate View The following figure shows the faceplate view of PCIE-6001 card. Figure 4-1 PCIE-6001 Faceplate The PCIE-6001 card comes with two gold finger edge connectors referred as Edge Connector 1 and Edge Connector 2. PCIE-6001 Installation and Use (6806800U73A)

  • Page 42: M.2/Ngff Edge Card Socket J3-J6

    LVTTL) NVME_R3_N PCIe Receive Pair Ground NVME_R3_P PCIe Receive Pair Ground Ground Ground NVME_T2_N PCIe Transmit Pair Ground NVME_T2_P PCIe Transmit Pair No Connect Not connected Ground No Connect Not connected NVME_R2_N PCIe Receive Pair PCIE-6001 Installation and Use (6806800U73A)
  • Page 43 Not connected NVME_T0_N PCIe Transmit Pair No Connect Not connected NVME_T0_P PCIe Transmit Pair No Connect Not connected Ground No Connect Not connected NVME_R0_N PCIe Receive Pair No Connect Not connected NVME_R0_P PCIe Receive Pair PCIE-6001 Installation and Use (6806800U73A)
  • Page 44 Not connected Ground No Connect Not connected Mechanical Key No Connect Not connected SUSCLK Suspend Clock No Connect Not connected +3.3V +3.3 Volt power Ground +3.3V +3.3 Volt power Ground +3.3V +3.3 Volt power Ground PCIE-6001 Installation and Use (6806800U73A)

  • Page 45: Leds

    Table 4-2 Front Panel LEDs Color Function NVMe 0 Blinking Green Drive activity Steady Red Drive is held in reset. Error. NVMe 1 Blinking Green Drive activity Steady Red Drive is held in reset. Error. PCIE-6001 Installation and Use (6806800U73A)

  • Page 46: On Board Leds

    PCI Express Gen 3 (8GT/s) Link NVMe 2 No link Blinking Green, 2 Hz PCI Express Gen 1 (2.5GT/s) Link Blinking Green, 1 Hz PCI Express Gen 2 (5GT/s) Link Steady Green PCI Express Gen 3 (8GT/s) Link PCIE-6001 Installation and Use (6806800U73A)
  • Page 47 Table 4-3 On Board LEDs (continued) Color Function NVMe 3 No link Blinking Green, 2 Hz PCI Express Gen 1 (2.5GT/s) Link Blinking Green, 1 Hz PCI Express Gen 2 (5GT/s) Link Steady Green PCI Express Gen 3 (8GT/s) Link PCIE-6001 Installation and Use (6806800U73A)
  • Page 48 Controls, Indicators, and Connectors PCIE-6001 Installation and Use (6806800U73A)

  • Page 49: Pcie-6001 Card Configuration Example

    CPU on a SharpServer PCIE-7410 card or on a SharpStreamerPro PCIE-7210 card in the same MaxCore system. The PCIE-6001 card with M.2 AHCI or NVME SSD modules are displayed in the CPUs PCIe device tree after booting the CPUs, along with many other PCIe devices that were connected to a CPU by SSF.

  • Page 50: Figure A-1 Configuration Example- Artesyn Maxcore System

    PCIE-6001 Card Configuration Example Figure A-1 Configuration Example- Artesyn MaxCore System PCIE-6001 Installation and Use (6806800U73A)

  • Page 51: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 52 Related Documentation PCIE-6001 Installation and Use (6806800U73A)
