Summary of Contents for Zetronix ORCA Pro zShades-HD4
- Page 1 ORCA Pro 2.7K Video Recording Sunglasses USER MANUAL zShades-HD4...
- Page 2 DO NOT BEND OR TWIST Comply with your local laws. Laws related to using a device that records video and audio may very from jurisdiction to jurisdiction. Zetronix does not condone activity that does not comply with the law.
- Page 3 Caution: Failure to comply with these warning may voice the warranty.
- Page 4 DIAGRAM...
- Page 5 IN THE BOX ORCA PRO Video Camera Glasses USB Cable Manual Cleaning Cloth Carrying Case...
-
Page 6: Before Use
BEFORE USE Charging your glasses Fully charge your glasses with the included USB Cable. Connect the glasses to a USB Port (Charger or Computer) While charging the LED indicator on the inside arm of the glasses with glow red. Once the battery is full the red LED will turn off. -
Page 8: Software Setup
SOFTWARE SETUP FREE Software Setting the Date and Time stamp along with changing the video resolution and formatting the glasses is easy with free software. Software can be downloaded from ZETRONIX.COM/DOWNLOAD... -
Page 9: Manual Setup
MANUAL SETUP Setting Manually If you do not want to use the free included software to set time / date and change the video format below are instructions for doing it manually The camera settings file can be accessed in the “init.txt” located in the “settings”... - Page 10 MANUAL SETUP To accessing the “Settings” file [init.txt] Connect the glasses using the USB cable to your computer in Windows open with Notepad in Mac OSx open with TextEdit. Open the file and edit the settings like in the example below (Please do not change the format) Copy the saved file onto the root level of the drive of the glasses (Not...
- Page 11 MANUAL SETUP Time and Date To change the time and date on the glasses, edit the text line like in the sample below to the required settings 2020-03-10 01:10:48 N [Date Time Watermark{Y/N}] Video Mode To change the “Video Mode” on the glasses edit the txt...
- Page 12 MANUAL SETUP The glasses can be set to the following video modes: 2160P24 = 2880x2160@24fps 1440P30 = 2560x1440@30FPS 1080P60 = 1920x1080@60FPS 1080P30 = 1920x1080@30FPS 720p60 = 1280x720@60FPS 720P120 = 1280x720p@120FPS...
- Page 13 MANUAL SETUP Reformatting Memory Card The built-in memory can be automatically reformatted by selecting “Y” in example below. WARNING: Formatting will erase all content from the glasses. Note: Its good practice to format the memory from time to time...
-
Page 14: Operation
OPERATION Turning On To power the glasses press the ON/OFF button for 2 – 3 seconds until the red LED lights up. Shortly the glasses will vibrate, and the red LED will start flashing. Once the red LED starts flashing the glasses are recording. - Page 15 OPERATION Taking Photos The Orca Pro video recording sunglasses can take photos while recording video. To take a photograph while recording video press the ON/OFF button quickly. The blue LED will blink quickly when a photograph is taken. This can only be done while recording video.
-
Page 16: Video Playback
VIDEO PLAYBACK Reviews Files on your Computer To view the files on your computer, connect the glasses using the USB cable to your computer’s USB port. A new drive will appear on your computer just like plugging in any USB drive. Some computers may notify you that a drive has been plugged in. - Page 17 VIDEO PLAYBACK files will be stored in that sub folders. On a Mac, open the finder icon, the glasses will be listed under devices, in the left hand side of the finder menu with an eject button next to it. Files can be moved from the glasses to your computer by dragging them into your desktop.
- Page 18 Windows and Mac. The software can be downloaded from WWW.VIDEOLAN.ORG However, please note VLC is not affiliated with Zetronix in anyway and Zetronix is not liable for the use of any third party programs including and not limited to VLC Player.
- Page 19 QUESTIONS STILL HAVING TROOUBLE? DO NOT RETURN YOUR GLASSES! For additional assitance contact Zetronix tech supoport. Phone__________________(6 17) 861-8418 Email________SUPPORT@ZETR ONIX.COM Web______________HELP.ZET RONIX.COM...
- Page 20 Zetronix Corp. 119 Braintree St Suite 701 Boston, MA 02134...
- Page 21 Zetronix Corporation ("Zetronix") warrants this product against defects in m11terial or workmanship as follows: PRODUCT: Zetronix will repair this product with new or refurbished parts, free of charge, for a period of one (1) year from the date of original purchase in the event of a defect in material or workmanship. REPAIRS: Zetronix will repair...
