- Page 1 User’s Manual For Model : SK-7360 RF Wireless Keyboard Version: 1.0 Department: HIS, R&D Date: May. 22-2004 Prepared :Muchuan Lee LITE-ON Technology Department: HIS R&D...
-
Page 2: Table Of Contents
Table of Contents 1. GENERAL :......................1 MAIN FEATURE .....................1 SOFTWARE REQUIREMENT 2. M ID.......................... ECHANICAL ......................4 EYBOARD ECEIVER 3. E LECTRICAL EATURE 3.1 K ......................3 EYBOARD RANSMITTER 3.1.1 Operating voltage ..............................3 3.1.2 Current consumption..............................3 3.1.3 Power consumption..............................3 3.1.4 Low Power Indicator..............................3 3.1.5 Circuitry ...................................4 3.1. -
Page 3: General
1. General SK-7260 is a 27 MHZ RF keyboard set, the product is composed of a wireless desk top PC keyboard and a PS2 receiver. The keyboard includes Standard function keys and several (option) easy access keys. General the receiver supports both keyboard and mouse function. There are only described keyboard and receiver functionality in the product specification but excluded mouse specification. -
Page 4: Mechanical Id
2. Mechanical ID Keyboard: Receiver : SK-8810 RF WIRELESS KEYBOARD Page No: 2 of... -
Page 5: Keyboard Transmitter
3. Electrical Specification Functional Block diagram: Low power indicator Keyboard (Base-Band) TX-Freq : RF Link Crystal : 32.768KHz 27.145 MHz Microprocessor MA6231 Microprocessor MA6135 Base-Band RX-Freq : Crystal : 26.690 /26.590 MHz Crystal : 32.768KHz PS2 Interface PC Host cable NumL ,CAP, Scrol Data indicator 3.1 Keyboard Transmitter... -
Page 6: Circuitry
3.1.1 Circuitry PCB Assembly Microprocessor MA6231 , MosArt ‘s Chip is applied. It’s placed on the PCB main board. There is also an antenna connected to this PCB for transmitting RF signal. 3.1.2 Battery Life The battery life under the operating condition of 10 keystrokes/sec continuous use is 80 hours for alkaline type and 30 hours for Zinc-Carbon type. -
Page 7: Receiver
WWW Home E0 32 E0 B2 E0 3A E0 F0 3A 10 WWW Back E0 6A E0 EA E0 38 E0 F0 38 11 WWW Forward E0 69 E0 E9 E0 30 E0 F0 30 12 WWW Favorites E0 66 E0 E6 E0 18 E0 F0 18... -
Page 8: Channel And Id Default Setting
Channel: two channels including CH1 for keyboard(27.145mHZ) and CH2 For mouse (27.045mHz) ID: There has a randomly 256 ID from for selection. Note: The ID indication is to prevent from interfering each other. End of SK-7360 User’s Manual SK-8810 RF WIRELESS KEYBOARD Page No: 6 of... - Page 9 FEDERAL COMMUNICATIONS COMMISSION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
