Summary of Contents for Atomos Connect
- Page 1 CONNECT 4K VIDEO/AUDIO CAPTURE...
- Page 2 Introduction Thank you for purchasing Atomos Connect, our HDMI to USB converter that allows you to take 4K (up to 30p), HD (up to 60p) or 720p (up to 60p) sources and output the same resolution and frame rate up to a maximum of 1080p60 ready for connection to the USB input on a computer and out to your choice of streaming platform.
-
Page 3: You Will Also Need
• 1 x User manual You will also need (sold separately) HDMI cable to connect from the output of your device (camera, Atomos recorder) and into the Connect HDMI input. Atomos have a range of 4Kp60 cables with die cast connectors and coiled cables in a range of lengths and connections (sold separately). -
Page 4: Specifications
Specifications • HDMI input resolution up to 4Kp30. • USB output resolution up to 1080p60 (YUV.JPEG). • Supports 8/10/12-bit deep color. • Supports certified AWG26 HDMI cables up to 15 meters. • Supports popular acquisition software on Windows, Android & Mac OS. •... -
Page 5: System Requirements
System requirements Minimum computer hardware requirements: • PC i5-3400 or above. • NB i7-3537U 2.0GHZ or above. • Graphics card: PC NVIDIA GT630 or above. • NC NVIDIA GT735M or above • Run memory: 4G RAM... -
Page 6: Getting Started
Atomos or HDMI device to your Mac or PC and the Atomos Connect automat- ically converts your input to the widely supported USB Video Class (UVC) standard. - Page 7 Teams, Zoom etc) minimal setup is required. You may need to grant these applications permission to access the audio and video feed from the Atomos Connect on your Mac/PC but then it is simply a case of selecting “USB Video” as your video source and “USB Digital Audio”...
-
Page 8: Warranty And Conditions
• The main product, or any external accessories, will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. If during the warranty period the product is shown to be defective ATOMOS may at its option:... - Page 9 ATOMOS with regard to the copyrighted Software provided with this EULA. Use of the Software provided to you by ATOMOS in whatever form or media, will constitute your acceptance of these terms, unless separate terms...
- Page 10 Software and/ or the ATOMOS Connect in whole or in part. Any failure to comply with the above or any other terms and conditions contained herein will result in the automatic termination of this license and the reversion of the rights granted hereunder by ATOMOS.
- Page 11 CONNECT 4K VIDEO/AUDIO CAPTURE...
- Page 12 ® All trademarks and registered trademarks are the property of their respective owners.
