Alpine PDP-E802DSP Manual

8 channel class-d dsp power amplifier

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

FOR CAR USE ONLY/ NUR FÜR AUTOMOBILGEBRAUCH/ POUR APPLICATION AUTOMOBILE/ PARA

USO EN AUTOMÓVILES/ SOLO PER L'UTILIZZO IN AUTOMOBILE/ ENDAST FÖR BILBRUK/ ALLEEN

VOOR GEBRUIK IN DE AUTO/ ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ

8 CHANNEL CLASS-D DSP POWER AMPLIFIER

• OWNER'S MANUAL

Please read before using this equipment.

• BEDIENUNGSANLEITUNG

Lesen Sie diese Bedienungsanleitung bitte

vor Gebrauch des Gerätes.

• MODE D'EMPLOI

Veuillez lire avant d'utiliser cet appareil.

• MANUAL DE OPERACIÓN

Léalo antes de utilizar este equipo.

ALPINE ELECTRONICS MARKETING, INC.

1-7, Yukigaya-Otsukamachi, Ota-ku,

Tokyo 145-0067, JAPAN

Phone: 03-5499-4531

ALPS ALPINE EUROPE GmbH

Ohmstraße 4

85716 Unterschleißheim, Germany

Phone: 089-3242640

For contact information in your

respective country, please visit:

www.alpine-europe.com/distribution.html

PDP-E802DSP

• ISTRUZIONI PER L'USO

Si prega di leggere prima di utilizzare il

attrezzatura.

• ANVÄNDARHANDLEDNING

Innan du använder utrustningen bör du

läsa igenom denna användarhandledning.

• GEBRUIKERSHANDLEIDING

Lees deze aanwijzingen aandachtig

alvorens dit toestel te gebruiken.

• РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ

Прочтите настоящее руководство

перед началом использования

оборудования.

ALPINE ELECTRONICS OF AMERICA, INC.

1500 Atlantic Boulevard, Auburn Hills,

Michigan 48326, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

ALPS ALPINE ASIA CO.,LTD.

The 9th Towers, Tower B ,floor 24th 33/4 Rama 9 road

Huay Kwang, Huay Kwang

Bangkok, Thailand 10310

Phone: +66 2-090 9596 Ex.265

Table of Contents

Need help?

Do you have a question about the PDP-E802DSP and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpine PDP-E802DSP

Page 1 1500 Atlantic Boulevard, Auburn Hills, Tokyo 145-0067, JAPAN Michigan 48326, U.S.A. Phone: 03-5499-4531 Phone 1-800-ALPINE-1 (1-800-257-4631) ALPS ALPINE EUROPE GmbH ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. Ohmstraße 4 161-165 Princes Highway, Hallam 85716 Unterschleißheim, Germany Victoria 3803, Australia Phone: 089-3242640 Phone 03-8787-1200 ALPS ALPINE ASIA CO.,LTD.
Page 3: Table Of Contents
PC CONNECTION .............. 15 FACTORY settings ............. 16 USE THE CORRECT AMPERE RATING WHEN REPLACING ALPINE SOUND LAB FOR PDP‑E802DSP ....17 FUSES. ALPINE REMOTE CONTROL APP Failure to do so may result in fire or electric shock.
Page 4: Service Care
HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to IMPORTANT NOTICE the product. Return it to your authorized Alpine dealer or Customers who purchase the product with which the nearest Alpine Service Center for repairing.
Page 5: Product Features
A sophisticated software for setting EQ, Time Correction, Crossover and Gain. This tool was designed by the ALPINE sound team with the needs of the audiophile in mind. Wired and wireless connection available. Alpine Remote Control App for PDP-E80xDSP for iOS and Android for Windows PC Recall presets, change sources and control the volume right from your smartphone.
Page 6: Accessories
ACCESSORIES 1. DSP Amplifier PDP‑E802DSP ....................1 2. Jumper ............................5 3. Power Harness 1,5m ........................ 1 4. Speaker Output Harness ....................... 1 5. RCA Input + Remote Harness ....................1 6. USB Connection Cable ......................1 7. RJ11 Adapter for RUX‑Knob ....................1 8.
Page 7: Installation Sequence
INSTALLATION SEQUENCE Please follow the flowchart below when installing the PDP‑E802DSP for the first time. Before completing the installation, we recommend to update the PDP‑E802DSP to the latest firmware. Start Parallel mode needed? (2 Ohms, high power) Change jumpers according to Use default setting owner’s manual Speaker Level Input?
Page 8: Hardware Configuration
3. Release the indicated screws in order to remove HARDWARE the digital board. CONFIGURATION This product uses semiconductors that can be damaged by electrostatic discharge (ESD). ATTENTION OBSERVE PRECAUTIONS FOR HANDLING 4. Flip over the digital board. ELECTROSTATIC SENSITIVE DEVICES When handling, care must be taken so that the devices are not damaged.
Page 9 JUMPER LOCATIONS Power Speaker Input 100 Load for Factory Unit Connector Connector Connector (see page 10) J32/J33CH1/2 J34/J35CH3/4 J36/J37CH5/6 100 load in High mode if open (FACTORY DEFAULT=connected) High/ Low Power Input (see page 10) J1/J4Channel 1 DC Detection capable J9/10Channel 2 J12/J13Channel 3 J14/J15Channel 4...
Page 10: Input Configuration
Important: INPUT CONFIGURATION For setting the High/Low level jumpers make sure the power is disconnected. Set the jumpers accordig to your connection To change the position of a jumper, it has to be method to the headunit. removed by pulling it straight up. Make sure that High Level inputs (speaker line) the jumper is reinserted properly and all pins are fully inserted.
Page 11 BRIDGE MODE VS. PARALLEL Example for parallel mode on channels 7+8: MODE Bridge Mode NOT SUPPORTED BY PDP‑E802DSP! This connection equals a straight short and may break your amplifier. Note: Connections are not done as in regular bridged mode!Example for parallel mode on channels 7+8: The Equivalent Circuit Axis of Symmetry...
Page 12 The 1‑channel RCA output is fully ask your dealer for assistance. We recommended processed and a straight “copy” of speaker output the installation should be done by an ALPINE channel 8. An optionally connected amplifier authorized dealer. should be able to handle input signals of up to 2V RMS.
Page 13 In this case the amp will perform at maximum ouput level. This may damage your speakers. It is recommended to use the ALPINE remote app or the wired RUX‑Knob. Note: The Alpine PDP‑E802DSP amp can only...
Page 14: Wireless Module
WIRELESS MODULE Power Harness The optional module WAD‑PDP1 is made for Color Function wireless control by Alpine Sound Lab for Battery + PDP‑E802DSP and for the Alpine remote app (available in appstores for Android and IOS). You Brown Ground - can also stream audio files from your smartphone to the amplifier.
Page 15: Pc Connection
Software Installation: You can download the Alpine Sound Lab for PDP‑E802DSP software and the device driver from your local Alpine website. The file can be found in the support section. The website will also contain short video clips explaining the process step‑by‑step.
Page 16: Factory Settings
Connect your PC to the PDP-E802DSP: FACTORY SETTINGS • Connect your PC with the supplied micro USB cable. • Input = RCA • No parallel mode, 8 straight channels WIFI OPT IN PROT • Input channels 1+2 linked to all output channels...
Page 17: Alpine Sound Lab For Pdp-E802Dsp
ALPINE SOUND LAB FOR PDP-E802DSP Tuning Tab 1 Status Bar 7 Connection Bar 2 Preset Bar 8 Crossover Settings 3 Source Selection 9 Master/ Sub Volume Settings 4 Graphical Representation of Settings 0 Channel Gain and Time Correction Settings 5 Channel Bar...
Page 18 channels will only be valid during the 3 Source Selection current session. RCA (Analogue) Optical (Digital) Standard output: The channel is linked to the master volume controller. 4 Graphical Representation of Settings Sub output: The channel is linked to the subwoofer volume controller.
Page 19 8 Crossover ! Equalizer Settings 30 Band Parametric EQ for the selected channel. Selection of crossover frequency Gain Setting + 10dB/ ‑30dB Slope selection (0 up to ‑30 dB/Oct. possible) Filter characteristics (Butterworth, Bessel, Center Frequency Setting Chebyshev) Slider bar for quick crossover selection Crossover on/ off Q Factor Setting...
Page 20 1. Don’t connect any amplifiers or loudspeakers 4 Analogue Routing to the outputs of the ALPINE PDP‑E802DSP With this matrix you can setup which input channel is routed to which output channel in during this setup.
Page 21 Headunit Connection Input Configuration Yellow Jumper Input Gain Pre Out 2V plugged Pre Out 4V plugged ‑6dB Headphone out 500mV plugged +12dB BTL Speaker Out (25W@4 Ohms) High plugged Single Ended Speaker Out (6W@4 Ohms) High plugged +6dB Line driver mode (for driving OEM amplifier) High removed +6dB...
Page 22 Overview Tab This screen visualizes the response curve(s) of the selected user adjustments of crossover, EQ, TCR and No channel information selected. level for each output channel. All settings are shown in the graphic The parameters and channels to be reflected in the display (EQ, crossover, level).
Page 23 Amplifier Setting Tab 1 Channel Status outputs (ex. a connected 2Ω load would appear The status of each channel is shown by the three as 4Ω to each of the two paralleled outputs). indicators below. See page 10 for details. Red: Short circuit on an output line 4 System Monitor This section allows to check the battery voltage...
Page 24 Application Setting Tab 1 DSP Status This section shows the serial number of the amplifier and the firmware version. It is possible to delay switching on and off the amplifier between 1s and 10s. The Autoremote feature allows to switch on the amplifier by detection Time ON: of an audio signal.
Page 25 1+2. Tech Tip: The wired remote line is also working in parallel to the DC detection. 2 Alpine Sound Lab for PDP-E802DSP Status Here you can find information regarding software and build versions. Depending on the environment the Alpine Sound Lab for PDP‑E802DSP is used in, you can choose between a day and a night theme.
Page 26: Alpine Remote Control App For Pdp-E802Dsp
PDP‑E802DSP. The selection of day To initiate communication between the ALPINE and night theme is also possible. Status information Sound Lab or the ALPINE Remote app, push the will be shown in real time. power button in the app.
Page 27: Usb Connection For Music Playback
Procedure and settings may differ depending on device and Android version. WIFI OPT IN PROT STAT LINK In all cases above, the source of the PDP‑E802DSP needs to be set to USB using the ALPINE Sound Lab or the ALPINE Remote app.
Page 28: System Examples
SYSTEM EXAMPLES 3-way Front System + 2 Subwoofer...
Page 29 3-way Front System + 2 Subwoofer Possible routing for this setup Output Connections SPEAKER OUTPUT Input/ Output Assignments: Input Assignment Output Assignment CH 1 Front Left CH 1 Tweeter Front Left CH 2 Front Right CH 2 Tweeter Front Right CH 3 Rear Left CH 3...
Page 30 3-way Front System + Center + Subwoofer...
Page 31 3-way Front System + Center + Subwoofer Possible routing for this setup Output Connections SPEAKER OUTPUT Input/ Output Assignments: Input Assignment Output Assignment CH 1 Front Left CH 1 Tweeter Front Left CH 2 Front Right CH 2 Tweeter Front Right CH 3 Rear Left CH 3...
Page 32 3-way Front System + Center + Mono Amplifier + Subwoofer Note: We do recommend connecting high quality amplifiers with differential RCA input/s (ground isolated) in order to avoid unwanted noise.
Page 33 3-way Front System + Center + Mono Amplifier + Subwoofer Possible routing for this setup Output Connections SPEAKER OUTPUT MONO AMPLIFIER Input/ Output Assignments: Input Assignment Output Assignment CH 1 Front Left CH 1 Tweeter Front Left CH 2 Front Right CH 2 Tweeter Front Right CH 3...
Page 34 2-way Front System + 2-way Passive Rear System + 2 Subwoofer...
Page 35 2-way Front System + 2-way Passive Rear System + 2 Subwoofer Possible routing for this setup Output Connections SPEAKER OUTPUT Input/ Output Assignments: Input Assignment Output Assignment CH 1 Front Left CH 1 Tweeter Front Left CH 2 Front Right CH 2 Tweeter Front Right CH 3...
Page 36: Troubleshooting
Check DSP harness for a secure and low • Data connection to DSP amp is active only resistance ground point. when ALPINE Sound Lab is active. Data • Check Autoremote status in the app. The status connection is terminated on Android devices should be set to “off”...
Page 37: Firmware Update
FIRMWARE UPDATE Firmware update procedure 8. Drag and drop the new Firmware file to the ALPINE AMP folder. 1. Download the latest Firmware file from your local Alpine homepage. 2. Check the support area. For latest software. 3. Extract the firmware file.
Page 38: Specifications
SPECIFICATIONS PDP-E802DSP Performance Per Channel, Ref.: 4Ω, 14.4 V, <1% THD 100W RMS Power Output Per Channel, Ref.: 2Ω, 14.4 V, <1% THD+N 120W RMS Frequency Response 20 Hz ‑ 22 kHz Damping Factor >100 Inputs RCA (Low Level) Analogue...
